Lorex CVC7995 Quick Setup Manual

4. Camera Specifications

Specifications:
Image Sensor 1/4" Interline transfer
type Color CCD
Effective Pixels 512H x 492V (25K Pixels)
Scanning System 525 Lines 2:1 Interlace
Resolution Horizontal 350 TV Lines
Shutter Speed 1/60 ~ 1/10,000 sec.
S/N Ratio More than 48dB (AGC off)
Sync. System Internal
Min. Illumination 1.0Lux (without LED)
White Balance AWB
Video Output VBS 1.0Vp-p (75 ohms)
Lens Varifocal lens (4 - 9 mm)
±
Power Supply DC12V
100mA (without LED) /
Current Consumption
520mA (with LED)
°
Operating Temp 14 F ~ 113
°
(-10 ~45
Operating Humidity 90% RH max.
Dimensions:
It's all on the web
Product Information
User Manuals
Quick Start Guides
10% (regulated)
1
°
F
°C)
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2006 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
H O M E & B U S I N E S S S E C U R I T Y
LONG RANGE COLOR
DAY/NIGHT IR CAMERA
WITH VARIFOCAL LENS
Model CVC7995
Quick Set-up Guide
