Lorex CVC7993 Quick Setup Manual

4. Removable Sunshade

Take Sunshade Off
1. Hold body of housing (rear of camera faces you)
2. Pull sunshade backwards (towards you)
Put Sunshade On
1. Hold body of housing (rear of camera faces you)
2. Push the sunshade forward (away from you)

Specifications

1/4" Interline transfer type color
CCD
Image Sensor
Effective Pixels NTSC 510H x 492V (250K)
Scanning System (NTSC) 525 Lines 2:1 Interlace
Scanning Frequency (NTSC) 15.734KHz (H),
59.94Hz (V)
Resolution Horizontal 350 TV Lines
Shutter Speed (NTSC) 1/60 – 1/100,000 sec.
S/N Ratio More than 48dB (AGC off)
Sync. System Internal/Line Lock Mode
Min. Illumination 1.0 (no LED) / 0.1 Lux (LED)
White Balance AWB
VBS 1.0 Vp-p (75 Ω load)
Video Output
Lens Varifocal Lens (4 - 9 mm)
Power Supply
DC12V ± 10% (Regulated)
Power Consumption 100mA (no LED)/200mA (LED)
Operating Temperature 14F to 113F (-10 ~ +50)
Operating Humidity 90% RH max
It's all on the web
Product Information
Specification Sheets
User Manuals Software Upgrades
Firmware Upgrades
Quick Start Guides
V I S I T
w w w . l o r e x c c t v . c o m
Strategic Vista International Inc.
Copyright © 2005 Strategic Vista International Inc
As our products are subject to continuous improvement, SVII and its
subsidiaries reserve the right to modify product design, specifications
and prices, without notice and without incurring any obligation. E&OE
B U S I N E S S & H O M E
¼ " C O L O R D A Y - N I G H T C A M E R A
W I T H V A R I F O C A L L E N S
Quick Set-up Guide
* This camera is not designed for direct exposure to water, rain or snow
Model CVC7993
