Lorex CVC6973HRP Quick Setup Manual

4. Camera Specifications
Specifications:
Image Sensor 1/3" Color CCD
Horizontal Res. 480 TV lines
# Effective Pixels 752 (H) x 582 (V) (440K)
Sync. System Internal Sync.
S/N Ratio 45dB (AGC Off)
Electronic Shutter 1/50 ~ 10,000 Sec.
Illumination 0 Lux (LED on)
IR Distance 35 ft. / 10 m.
Lens 6 mm / F2.0
Video Output 1.0Vp-p @ 75 ohms
LED 12 LED
Power Supply DC 12V ± 10% 300mA
with 230V input
14°F ~ 122°F
Operating Temp
(-10°~ 50°C)
Storage Temp -4°F ~ 140°F
(-20°~ 60°C)
Dimension 3.9" (H) x 3.2" (D)
100mm (H) x 80mm (D)
Dimensions:
It's all on the web
Specification Sheets
Product Information
Software Upgrades
User Manuals
Firmware Upgrades
Quick Start Guides
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2007 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
H O M E & B U S I N E S S S E C U R I T Y
HI-RES COLOR DAY/NIGHT
IR CAMERA
Model: CVC6973HRP
Quick Set-up Guide
