Analog Video Connector, X32

The development board provides an Analog Video connector. This connector is a 15-pin
female connector, labeled X32. The Analog Video interface is connected to the Display 1
interface of the i.MX51 CPU.
The table below shows the pinout of the Analog Video connector.
© 2011 Digi International, Inc.
Downloaded from Elcodis.com electronic components distributor
Pin Signal
1 VGA_RED
2 VGA_GREEN
3 VGA_BLUE
4 NC
5 GND
6 RED_RETURN
7 GREEN_RETURN
8 BLUE_RETURN
9 NC
10 GND
11 NC
12 NC
13 HSYNC#
14 VSYNC#
15 NC
