Blocklychain MD-104 Manual

Motion detector
Hide thumbs Also See for MD-104:
Table of Contents

Advertisement

Quick Links

Download this manual
MOTION
DETECTOR
MD-104

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-104 and is the answer not in the manual?

Questions and answers

Related Manuals for Blocklychain MD-104

Summary of Contents for Blocklychain MD-104

  • Page 1 MOTION DETECTOR MD-104...
  • Page 2 HELLO Thank you for purchasing Motion Detector. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Wi-Fi Connectivity Motion Detector connects to the Internet via Wi-Fi. Rechargable Battery Using a last-longing rechargable battery, Motion Detector works for a long time.
  • Page 3 How to Install Download Blocklychain App Product Installation Guide Create a New Account: Click on Create Account Type your e-mail address Type your password Re-type your password Click on Create Account Check your e-mail to verify your account , then click on I'm Already Verified...
  • Page 4 Sign In: Click on Sign In Type your e-mail address Type your password Click on Sign In...
  • Page 5 To install a new device in Android, make sure the mobile Bluetooth is turned on and allowing the app to "access device's location / Bluetooth"...
  • Page 6 How to Install Device Connect Motion Detector to a USB Type-C charger. Before continuing installation process, let's device battery get fully charged. * A solid green indicator light shows the battery is fully charged. Connect the device to a charger then click on the button on your device...
  • Page 7 Find your device from the list, then click on Connect Click on Search Wi-Fi Searching for available Wi-Fi networks Choose your Wi-Fi SSID Type your Wi-Fi password Click on Set Device Wi-Fi...
  • Page 8 If the device installation process finishes successfully, the message be displayed. Otherwise, the message will be displayed. It indicates that something went wrong and you will need to redo the installation process again.
  • Page 9 How to Monitor Your Device Back to home in app. Then, go to the BKC control Panel. Click on BKC Control Panel icon Click on Devices This is Device Card...
  • Page 10 Name of the Motion Detector Device modes Last activity time Battery indicator Device dashboard Device connection indicator...

  • Page 11: Device Modes

    Device modes Detected Motion Detecter is detected a motion. Also, a blue line blinks around the card and the last time activity is updated. Update device Connect the device to a charger. Click two times on the button on your de- vice.

  • Page 12: Device Dashboard

    Device Dashboard Clicking on the gear icon on the Motion Detector card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about power consumption. David Room Motion Detector Monitor Data Graph Config State Battery Detected Data Graph In Data Graph tab, a bar chart represent power consumption during time.
  • Page 13 Config In Config tab, you can update firmware, rename device, and remove your device from BKC Control Panel. David Room Motion Detector Monitor Data Graph Config FC:F5:C4:A5:0D:E2 Device Details Type MOTION_DETECTOR Firmware Version 1.2.0 Install Time 2 August 2021 Su 5:23 Hardware Version Rename Device New Version Available...

  • Page 14: Led's Status

    LED's Status Status Indicator Description Connection 4 seconds 4 seconds Problem connecting to server 2 seconds 2 seconds Ready to install 0.2 second 0.2 second Connecting to Wi-Fi 0.1 second 0.1 second App connected to device Solid Orange Connecting to server Battery 0.2 second 0.2 second...
  • Page 15 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion. Do not heat, open, puncture, mutilate, or dispose of your device or its battery in fire.

  • Page 16: Specification

    Specification Device Product Name Motion Detector Model MD-104 Angle Detection 60 degrees Distance Detection 8 meters Size 7x2x2.5 cm Weight 22 g Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V Lithium rechargeable Charger USB Type-C...

  • Page 17: Package Content

    Package Content 1x Motion Detector For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
