Blocklychain 102-MD Manual

Motion detector
Hide thumbs

Advertisement

Quick Links

Download this manual
MOTION
DETECTOR
MD-102

Advertisement

loading
Need help?

Need help?

Do you have a question about the 102-MD and is the answer not in the manual?

Questions and answers

Related Manuals for Blocklychain 102-MD

Summary of Contents for Blocklychain 102-MD

  • Page 1 MOTION DETECTOR MD-102...
  • Page 2 HELLO Thank you for purchasing Motion Detector. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from the Internet. Wi-Fi Connectivity Motion Detector provides Wi-Fi to conn- ect directly to the Internet.
  • Page 3 How to Install Motion Detector Connect Motion Detector to a Micro USB charger. Go to www.blocklychain.com www.blocklychain.com...
  • Page 4 Log into your account in BKC Control Panel. [or signup if you don’t have an account.] www.blocklychain.com Login Click on Devices on the menu. My Home My Home Today Devices Services Tuesday, 29 September 2021 Home 12:28 Home Europe/London Devices...
  • Page 5 Select Motion Detector from the list. My Home Add New Device Choose your device type Home Choose the type of your new device you want to install Devices Service Market Installed Services Motion Detector Door Sensor Smart Button Smart Plug Smart Speaker Activity Service Creator...
  • Page 6 Go to the Wi-Fi setting on yor laptop/mob- ile and switch it to Motion_Detector Wi-Fi. Motion_Detector HomeWi-Fi James ST1QTJ1 Tigerx 2:28 pm 12/6/2020 Go back to BKC Control Panel and click on Next. My Home Add New Device Change your Wi-Fi Home Go to Setting on your mobile and connect to the Wi-Fi name “Motion_Detector”.
  • Page 7 Choose your home Wi-Fi from the list and type the password. Then, click on Check Wi-Fi. My Home Add New Device Set your home Wi-Fi Home Choose your home Wi-Fi from the list below. Devices Manual Setting Available Wi-Fi list My Wi-Fi Service Market Wi-Fi X...
  • Page 8 How to Control Your Device Log into your account in BKC Control Panel. Then, go to the Devices page. Your Motion Detector card will be like below. Name of the Motion Detector Device modes Last activity time Battery indicator Device dashboard Device connection indicator...

  • Page 9: Device Modes

    Device modes Scanning Motion Detector is on and scaning the area. Movement Detected Motion Detecter is detected a motion. Note: after 5 seconds, the Movement Detected modes change to the Scaning mode. Update device Connect the device to a charger. Click two times on the button on your de- vice.
  • Page 10 BKC Control Panel In BKC Control Panel, you can register, monitor, and control your BKC devices. www.blocklychain.com...
  • Page 11 Installing BKC Control Panel On the phone Open the Google Chrome browser. Go to www.blocklychain.com Click on Login. Log into your account. On the pop-up page, click on Add to Home Screen. On the desktop Open the Google Chrome browser.
  • Page 12 Blocklychain Services In BKC Control Panel, BKC Services are mini apps that add new functionalities to smart devices. You can access hundreds of BKC Services in Service Market or easily develop new services on Service Creator to extend the functionality of your Motion Detector.
  • Page 13 Service Creator In BKC Control Panel, using Service Creator, you can develop new services. How to create Blocklychain Services There are two programming consoles in Service Creator: 1. Blockly Console 2. Coding Console My Home 8952 Created Service Published Service Installed Service...
  • Page 14 Play Emergency Alarm 1.mp3 Text Service Creator 2. Coding Console Coding Console enables professional devel- opers to program BKC services by JavaScript syntax for Blocklychain-enabled devices including Motion Detector. My Home *Describe this function... function cron() { Power1.SEND_COMMAND('TURN_OFF');} Home Devices if ((Shortcut1.PAYLOAD.state === 'pressed')) {...
  • Page 15 Status Indicator Description Connection Orange Connecting to Blocklychain (Blinking every 4 seconds) server on the Internet Orange Connecting to Wi-Fi (Blinking every 1seconds) Battery Blinking Red Very low battery Solid Red Low battery Solid Blue Charging Solid Green Full charge...
  • Page 16 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion. Do not heat, open, puncture, mutilate, or dispose of your device or its battery in fire.

  • Page 17: Specification

    Specification Product Name Motion Detector Model MD-102 Angle Detection 60 degrees Distance Detection 12 m Size 7x2x2 cm Weight 22 g Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V Lithium polymer rechargeable battery Charger micro USB 500mA...

  • Page 18: Package Content

    Package Content 1x Motion Detector For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
