Summary of Contents for Blocklychain DS-104
- Page 1 DOOR SENSOR DS-104 628942042942...
- Page 2 HELLO Thank you for purchasing Door Sensor. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Wi-Fi Connectivity Door Sensor connects to the Internet via Wi-Fi.
- Page 3 How to Mount Door Sensor To mount the Door Sensor, stick the big part on the frame of the door or window. Then, place the small part on the surface opposite the big part. Maximum recommended gap between the big and the small parts is 2 cm.
- Page 4 How to Install Download Blocklychain App Product Installation Guide Create a New Account: Click on Create Account Type your e-mail address Type your password Re-type your password Click on Create Account Check your e-mail to verify your account , then...
- Page 5 Sign In: Click on Sign In Type your e-mail address Type your password Click on Sign In...
- Page 6 To install a new device in Android, make sure the mobile Bluetooth is turned on and allowing the app to "access device's location / Bluetooth"...
- Page 7 How to Install Device Connect Thermometer Hygrometer to a USB Type-C charger. Before continuing installation process, let's device battery get fully charged. * A solid green indicator light shows the battery is fully charged. Connect the device to a charger then click on the button on your device...
- Page 8 Door Sensor New Device Device: CONNECTED Door: Open Battery: 85 % The latest data received at: 2022-12-14 05:25:34,000 Click on Add Device Choose device type Turn on your bluetooth, then click on Next Find your device from the list, then click on Connect Click on Search Wi-Fi Searching for available Wi-Fi networks...
- Page 9 Choose your Wi-Fi SSID Type your Wi-Fi password Click on Set Device Wi-Fi If the device installation process finishes successfully, the message be displayed. Otherwise, the message will be displayed. It indicates that something went wrong and you will need to redo the installation process...
- Page 10 How to Monitor Your Device Door Sensor New Device Device: CONNECTED Door: Open Battery: 85 % The latest data received at: 2022-12-14 05:25:34,000 Click on menue icon Click on Devices This is Device Card...
- Page 11 Door Sensor New Device Device: CONNECTED Door: Open Battery: 85 % The latest data received at: 2022-12-14 05:25:34,000 Name of the Door Sensor Device modes Device status Battery indicator Last activity time Click on the device card and go to the config card.
- Page 12 Device modes Open The small part got far from the big part, so door/window is opened. Close The small part is close to the big part, so door/window is closed.
- Page 13 Config Card In Config tab, you can update firmware, rename device, and remove your device from Blocklychain App. Door Sensor New Device Device information Rename your device Update device firmware Remove your device Device installation date...
-
Page 14: Led's Status
LED's Status Status Indicator Description Connection 4 seconds 4 seconds Problem connecting to server 2 seconds 2 seconds Ready to install 0.2 second 0.2 second Connecting to Wi-Fi 0.1 second 0.1 second App connected to device Solid Orange Connecting to server Battery 0.2 second 0.2 second... - Page 15 How to Reset Your Device Reset Device Try to connect your battery-powered devices to a charger and then disconnect it. It might resolve the problem. If the problem continues, use a small jumper wire or tweezers to shorten the metal contact on the back of your device. Reset Factory On your Door Sensor Click and release the button, then press and...
- Page 16 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion. Do not heat, open, puncture, mutilate, or dispose of your device or its battery in fire.
- Page 17 6. Parts of your device are magnetic and may attract metallic items. Do not place magnetically sensitive devices, credit cards, other magnetic storage media near your device.
-
Page 18: Specification
Specification Device Product Name Door Sensor Model DS-104 Size (big part) 7x2x2 cm Size (small part) 5x1x1 cm Weight (big part) 22 g Weight (small part) Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V Lithium rechargeable Charging Port USB Type-C... -
Page 19: Package Content
Package Content 1x Door Sensor 1x Big Part 1x Small Part For further help or inquiries: Email support@blocklychain-iot.com All right reserved. Copyright © 2022 Blocklychain...
