Linksys WPG11 Quick Installation

This Quick Installation is meant to help you install this product quickly and easily. For detailed instructions on installa-
tion and configuration and further setup options, please consult the User Guide
Instant Wireless™ Series
W W i i r r e e l l e e s s s s
P P r r e e s s e e n n t t a a t t i i o o n n
G G a a t t e e w w a a y y
Package Contents
• One Instant Wireless
System Requirements
Presentation Gateway (2)
• Two Removable Antennas
• One Windows 98, Millennium, 2000, or XP
• One Power Adapter (3)
PC with:
• One Setup CD-ROM with User Guide (1)
- 802.11b-compliant Wireless Adapter
• Registration
- 200 MHz Pentium CPU
Installation (not shown)
- 64 MB RAM
- CD-ROM drive
Connecting the
Wireless Presentation Gateway
A. Connect the serial cable, connected to your monitor or projector, to the Wireless
Presentation Gateway's "TO Monitor/Projector" console port.
B. Plug the supplied power adapter into the jack on the Wireless Presentation Gateway's
back panel. Then, plug the other end into a power outlet.
C. Proceed to Step Two: Installing the Wireless Presentation Gateway's Player.
Installing the Wireless
Presentation Gateway's Player
A. To install the Player, insert the Setup CD-ROM into your CD-ROM drive. The CD's
autorun program should start automatically, bringing up the screen shown in Figure A.
If the autorun does not start automatically, click the Start button, select Run, and type
d:\setup.exe in the Open field to start the autorun program. You will then see the screen
in Figure A.
TM
Wireless
Card and Quick
The installation is complete.
B. Click the Install tab on the
autorun screen (as shown in
Figure A) and you will
begin the installation pro-
cedure, bringing up a
screen like that shown in
Figure B. Click the Next
button to continue the
installation procedure.
C. The next screen, like that
shown in Figure C, will
allow you to choose where
the Player will be installed.
By default, the destination
folder is C:\Program
Files\WPG11 Player. You
can change this, if you
wish, by clicking the
Browse button and select-
ing another destination
where it will be installed.
Once the destination has
been selected, click the
Next button to continue.
D. The Player will now install.
When you see the final
installation screen, like that
shown in Figure D, click
the Finish button.
The Wireless Presentation
Gateway's Player is now suc-
cessfully installed For fur-
ther information about the
Wireless Presentation
Gateway, please refer to the
User Guide or the Linksys
website at www.linksys.com.
W W W . L I N K S Y S . C O M
QI-WPG11NC-051302NC KL
