MG-942-06
MG-FS942-06
© 2018 Johnson Health Tech. All Rights Reserved. Specifications subject to change without notice.
M AG NUM SERIES
MG-942-06 DIP / CHIN ASSIST
MG-FS942-06 DIP / CHIN ASSIST (FREE-STANDING)
PROPER USAGE
1 Do not exceed weight limits of the exercise
device.
2 If applicable, set safety stops to appropriate
height.
3 If applicable, adjust seat pads, leg pads, foot
pads, range of motion adjustment, or any
other type of adjustment mechanisms to a
comfortable start position. Make certain that the
adjusting mechanism is fully engaged to prevent
unintentional movement and to avoid injury.
4 Sit on bench (if applicable) and get into
appropriate position for exercise.
5 Exercise using no more weight than you can
safely lift and control.
6 In a controlled manner, perform exercise.
7 Return weight to its fully-supported start position.
WARRANTY
Valid in North America only
Frame (not coatings) * 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excludes upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
* Frame is defined as the welded metal base of the unit
and does not include removable parts.
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
Lubricate Guide Rods † As Needed
* Upholstery & Grips should be cleaned with a mild soap and
water or a non-ammonia based cleaner.
† Guide rods should be lubricated with Teflon based lubricant. Apply
the lubricant to a cotton cloth and then apply up and down the
guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum User Weight 159 kg / 350 lbs.
Maximum Training Weight 87.1 kg / 192 lbs.
Product Weight
MG-942-06 150 kg / 331 lbs.
MG-FS942-06 184 kg / 405 lbs.
Overall Dimensions (L x W x H)*
MG-942-06 91 x 72 x 234 cm /
36" x 28" x 92"
MG-FS942-06 120 x 119 x 234 cm /
47" x 47" x 92"
Weight Horn Diameter 47.63 mm / 1.875"
(Weight Plate Storage)
* Ensure a minimum clearance width of 914 mm / 36" for access
to and passage around MATRIX strength equipment.
Rev 1.2 / 2018.06.06
