Plafondmontage
Ceiling mount
Deckenhalterung
Montage au plafond
1
6
2
3
4
5
Audipack, Industriestraat 2 Moerkapelle The Netherlands, Tel: +31 (0)795931671
Onderdelen/Parts/Teile/Pi ces CMP-4:
2
Hex Bolt - M8x80
(4X)
1 (1X) CMP-4
3
Spring Washer 8 mm
(4X)
4
Washer 8,4 mm
(4X)
5
Hex Nut M8
(4X)
6
370018 Cover
(4X)
Afwerkring
Finishing ring
Deckenrosette
Rosette de finition
Telescopische instelling
Telescopic adjustment
Teleskopische Einstellung
R glage de t l scopique
Lock
Quatro-Fix
Audipack
Max.
20 kg.
installatie handleiding
installation guide
installationhandbuch
guide d'installation
Max.
10 kg.
Copyright Audipack
2011 07
-
