Assembly Instructions
Tate Series
Product Code
TATE-RODT-BLACK Dining Table
TATE-RODT-NATURAL Dining Table
Dimensions
W x D x H
(
1800x900x750mm
)
Important
Please read through instruction carefully
Before assembly and keep for future reference.
For our full catalogue of assembly instructions,
Visit: lifely.com.au/assembly.
Advertisement
Related Manuals for Lifely Tate Series
Summary of Contents for Lifely Tate Series
- Page 1 Assembly Instructions Tate Series Product Code Important TATE-RODT-BLACK Dining Table Please read through instruction carefully TATE-RODT-NATURAL Dining Table Before assembly and keep for future reference. Dimensions W x D x H For our full catalogue of assembly instructions, 1800x900x750mm Visit: lifely.com.au/assembly.
- Page 2 Important Tips and Maintenance Never place liquids or anything Never use ammonia based To avoid fading, keep furniture Keep children and animals away from working area as cleaning products as it will damp upon furniture as it out of direct sunlight. smaller parts may cause chok- will mark.
- Page 3 So your relationship is strong.But is it flat-pack furniture strong? Unless you're an aerospace engineer,assembling furniture can be slightly stressful.We recommend meditating quietly,pouring yourself a herbal tea (or slightly less herbal wine) and tackling things one step at a time.If you feel a passive aggressive remark coming on,try a compliment instead.E.g.“You’re so...
-
Page 4: Before Assembly
Before Assembly Tips Before Your Start: - Remove all wrapping material, including staples & packing straps before you start to assemble. - DO NOT tighten all screws and bolts until completely assembled. - Keep all hardware parts out of reach of children. QUICKFIT Shoulder Panel... -
Page 5: Component Hardware
Component Hardware Please check you have all the fittings part or tools are listed in below. No. A No. B No. C No. D No. E Quantity:2Pcs Quantity:32Pcs Quantity:64Pcs Quantity:32Pcs Quantity:32Pcs Cam Lock Dowel Dowel Screw Allen Key Cam Lock 8*28mm φ15mm M6*50... - Page 6 Component Panels part List Please check you have all the panels are listed below. Table Top CTN 1/2 Top Panel of Base CTN 1/2 Bottom Panel of Base CTN 1/2 Side Panel of Base CTN 2/2 Corner Rail of Base CTN 2/2 TATE-RODT-BLACK...
- Page 7 STEP 1 No. A No. B Quantity:32 Pcs Quantity:48 Pcs Cam Lock Dowel Dowel 8*28mm 8*30mm STEP 2 No. C Quantity:16Pcs Cam Lock TATE-RODT-BLACK...
- Page 8 STEP 3 No. C Quantity:16Pc Cam Lock STEP 4 No. B No. D No. E Quantity:8 Pcs Quantity:16 Pcs Quantity:2 Pcs Dowel Screw Allen Key 8*30mm M6*50mm TATE-RODT-BLACK...
- Page 9 STEP 5 No. B No. D Quantity:8 Pcs Quantity:16 Pcs Screw Dowel 8*30mm M6*50mm STEP 6 No. F No. H No. I No. G Quantity:8 Pcs Quantity:8 Pcs Quantity:1 Pc Quantity:8 Pcs Screw Screw Washer Allen Key Foot Pad M8*35mm φ18mm φ20mm TATE-RODT-BLACK...
- Page 10 STEP 7 TATE-RODT-BLACK...
- Page 11 Great job. You're done! Don't forget to share how it looks in your space and tag us on lnstagram. @lifelyhome#homewithlifely!
