- Page 1 Standard rotating nozzles RGS │01.xxx HRH │02.xxx HRV │03.xxx KBR │04.xxx KBRV │04.xxxV Operating manual English November 20| Version 1.0 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 1 of 40...
-
Page 2: Table Of Contents
Preparatory work ..................30 Setting up the work area ................31 Operation....................... 32 How standard rotating nozzles work ............32 Operating a standard rotating nozzle ............33 Cleaning pipes with minor damage ............34 Page 2 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0... - Page 3 Maintenance ....................35 Replacing nozzle inserts ................35 Maintenance ....................36 Spare parts/accessories ................. 37 Jet inserts....................37 Maintenance ....................37 Index ......................39 Tables ......................39 Figures ......................39 Version Revision Datum Visum created September 20 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 3 of 40...
-
Page 4: Preface
It must be stored at an easily accessible location. If the operating instructions are lost or have been destroyed, a copy can be requested from your local dealer or direct from the manufacturer. Page 4 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0... -
Page 5: Safety
All other mainte- nance and repair work may only be carried out by qualified personnel of the manufac- turer. Observe the instructions in the chapter “Maintenance”! 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 5 of 40... -
Page 6: Meaning Of The General Safety Instructions
/ or invalidity! CAUTION! Designates dangers which, if disregarded, may result in injuries and significant property, financial or environmental damage! Information for the technically correct and efficient use of the product. Page 6 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0... -
Page 7: Intended Use
Secure hose lines in such a way that they cannot be damaged during operation. Only accessory parts provided and approved by enz® technik ag may be used. It is forbidden to carry out any conversions or modifications to the pipe cleaning tool. -
Page 8: Protective Equipment When Working In Shafts, Pits And Channels
Visually noticeable work clothing should make the employees more visible for road users. Suitable shoes The safety shoes should, in particular, offer good support as well as be anti-slip and leak proof (e.g. Rubber boots). Page 8 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0... - Page 9 If there is a danger from splitters, splashing of hazardous substances, etc. eyes must be protected. Network-independent lighting For example, a splash-proof torch or a lamp fixed to a hard hat must be carried. 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 9 of 40...
-
Page 10: General Safety Instructions
Channels may contain unknown, corrosive or other harmful sub- stances. Wear the respective protective clothing. Use the prescribed protective equipment. Chemical burns to skin and eyes as well as in- fections with pathogens may be the consequence. Page 10 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0... - Page 11 In the area where work is carried out with the product, lines and ob- jects are to be expected on the ground. Take care where you step. Keep the operating area clean and tidy. Falling caused by tripping may result in injury. 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 11 of 40...
-
Page 12: Rights
In line with our terms of sales and delivery, we issue a guarantee. However, the guar- antee is omitted: • When used under conditions stipulated otherwise by us. • When using replacement or accessory parts that are not original from enz® tech- nik ag. • In event of damage caused by: Incorrect handling... -
Page 13: Environment
Chemicals or other poisonous substances must never be released to the environment. Take care to avoid excessive use or water. In this way, you help to protect natural re- sources. 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 13 of 40... -
Page 14: Technical Data
Technical data Operating manual The enz® standard rotating nozzles stand out because of their versatility. These rotat- ing nozzles are available in five different jet angle variants. The two drive jets and the two brake jets keep the rotational speed constant. -
Page 15: Rgs → Radial Rotating Nozzle
Pipes of all sorts are fully cleaned, even if they have lateral junctions. The rotating part of the enz® RGS nozzle moves at a limited speed. These water jets hit the pipe wall directly with great impact, resulting in excellent cleaning capacity. - Page 16 26.0 3’600 01.100A BSPP 1” 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 BSPP 01.100B 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 1 1/4” Table 3: RGS specifications 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 16 of 40...
-
Page 17: Hrh → Rear Semi-Radial Nozzles
Figure 3: HRH Introduction enz® semi-radial rotating nozzles with 45° cutting jets provide the cleaning effect and simultaneously thrust the nozzle forward; this means rotation and thrust in one func- tion This minimizes water consumption. However, the tool can also be equipped to operate with thrust jets if there is enough water to do so. - Page 18 30-100 1.2-3.9 28x56 1.1x2.2 5’000 02.028B BSPP 1/4” 4xM4 30-100 1.2-3.9 28x56 1.1x2.2 5’000 02.028BN 1/4” NPT 4xM4 30-100 1.2-3.9 28x56 1.1x2.2 5’000 Table 4: Specifications for HRH 1/8″–1/4″ Page 18 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 19 BSPP 1” 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 BSPP 02.100B 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 1 1/4” Table 5: Specifications for HRH 1/2″– 1 1/4″ 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 19 of 40...
-
Page 20: Hrv → Front Semi-Radial Nozzles
Figure 4: HRV Introduction enz® HRV nozzles with four 45° jets impacting forward onto the pipe wall, a front jet (if requested) and three rear thrust jets work like a corkscrew to penetrate a clogged pipe. As a result, the deposits are broken up, removed by the semi-radial nozzle’s rotor and pushed forward. - Page 21 26.0 3’600 03.100A BSPP 1” 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 BSPP 03.100B 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 1 1/4” Table 6: HRV specifications Page 21 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
-
Page 22: Kbr → Combination Nozzles
Figure 5: KBR Introduction enz® KBR nozzles are extremely suitable for pipe cleaning and cleaning lateral pipe connections. They can work at a low pump output, have two 90° radial jets for the pipe wall, and two semi-radial jets that can be aligned toward the rear at less than 45°. - Page 23 5’000 04.016AS07N 1/8” NPT 4x0.7 3x0.8 0.03 18-60 0.7-2.4 16x31 0.6x1.2 5’000 04.016AS08N 1/8” NPT 4x0.8 3x0.8 0.03 18-60 0.7-2.4 16x31 0.6x1.2 5’000 Table 7: Specifications for KBR 1/8″ Page 23 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 24 5’000 04.028B BSPP 3/8” 4xM4 0.20 30-100 1.2-3.9 28x56 1.1x2.2 5’000 04.028BN 3/8” NPT 4xM4 0.20 30-100 1.2-3.9 28x56 1.1x2.2 5’000 Table 8: Specifications for KBR 1/4″ and 3/8″ Page 24 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 25 BSPP 1” 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 BSPP 04.100B 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 1 1/4” Table 9: Specifications for KBR 1/2″– 1 1/4″ 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 25 of 40...
- Page 26 A large proportion of the deposits are flushed forward. Application range • Removing soft deposits • Cleaning heat exchangers • Removing grease deposits • Flushing the pipes from the building toward the main line Page 26 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 27 16x31 0.6x1.2 5’000 04.016AVS07N 1/8” NPT 4x0.7 3x0.8 18-60 0.7-2.4 16x31 0.6x1.2 5’000 04.016AVS08N 1/8” NPT 4x0.8 3x0.8 18-60 0.7-2.4 16x31 0.6x1.2 5’000 Table 10: Specifications for KBRV 1/8″ Page 27 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 28 16x31 0.6x1.2 5’000 04.028AV BSPP 1/4” 4xM4 0.20 30-100 1.2-3.9 28x56 1.1x2.2 5’000 04.028AVN 1/4” NPT 4xM4 0.20 30-100 1.2-3.9 28x56 1.1x2.2 5’000 Table 11: Specifications for KBRV 1/4″ Page 28 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 29 BSPP 1” 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 BSPP 04.100BV 4xM10 3xM10 200-600 7.9-24.0 100x180 3.9x7.1 53.0 3’600 1 1/4” Table 12: Specifications for KBRV 1/2″– 1 1/4″ 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 29 of 40...
-
Page 30: Installation
Installation Operating manual To set up the tool on the cleaning vehicle, enz® technik ag needs the following param- eters for each order: • Pump capacity: l/min US gpm • Pump pressure: • Hose size: inch • Hose length: feet •... -
Page 31: Setting Up The Work Area
This is to avoid the operating nozzle from emerging at a pipe end. Support personnel must be on hand to monitor possible emerging points. Have the liability waiver signed to protect against any possible damage claims. 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 31 of 40... -
Page 32: Operation
(4) ensure constant rotation. The three thrust jets (5) move the standard rotating nozzle through the pipe and transport the dis- lodged deposits back to the manhole. Figure 7: How standard rotating nozzles work Page 32 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0... -
Page 33: Operating A Standard Rotating Nozzle
Monitor the cleaning work with a camera at all times. If pipes are extremely dirty, it is recommended that you pull the tool back at regular intervals to prevent blockages due to fragments and dislodged material. 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 33 of 40... -
Page 34: Cleaning Pipes With Minor Damage
When working inside a slightly damaged pipe, you must use extreme caution. Use of the tool is always at your own risk. enz® technik ag accepts no liability. CAUTION! When cracks are washed out, pipe fragments can break off and the material surrounding the pipe may be washed out. - Page 35 M4 jet insert SW 3.5 C104 and C261 M4 jet insert SW 5.0 C101 and C49 M4 jet insert SW 7.0 C160 and C260 M10 jet insert SW 10.0 C131 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 35 of 40...
- Page 36 Spray the surface of the tool with Oil Spray Bio (Art. No. C191) after every use. If the tool is due to remain unused for an extended period, spray the nozzle holes and the connection threads as well. Page 36 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 37 Wiha socket wrench C104 3.5 mm Wiha socket wrench C101 5 mm Wiha socket wrench C160 7 mm Wiha socket wrench C131 10 mm Futuro socket wrench C261 3.5 mm 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 37 of 40...
- Page 38 Loctite 243 50 ml C192 Nozzle gauge with 20 pins C200 0.45-1.50 mm Nozzle gauge with 16 pins C201 1.50–3.00 mm Nozzle cleaning tool C202 Table 15: Maintenance accessories Page 38 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
- Page 39 Figure 1: Part names ....................14 Figure 2: RGS ........................15 Figure 3: HRH .......................17 Figure 4: HRV .......................20 Figure 5: KBR ........................22 Figure 6: KBRV ......................26 Figure 7: How standard rotating nozzles work ............32 04.11.2020 Version 1.0 ©2020 enz® technik ag Page 39 of 40...
- Page 40 Schwerzbachstrasse 10 CH-6074 Giswil / Switzerland Phone +41 41 676 77 66 Fax +41 41 676 77 67 info@enz.com www.enz.com Page 0 of 40 ©2020 enz® technik ag 04.11.2020 Version 1.0...
