Nikon NIKKOR Z 24mm f/1.85 S Manual

Before using this product, please read these instructions carefully. You will also need to consult the camera manual.

• This lens is intended exclusively for use with mirrorless cameras featuring a Nikon Z mount.

For Your Safety

To prevent damage to property or injury to yourself or to others, read "For Your Safety" in its entirety before using this product.

Keep these safety instructions where all those who use this product will read them.

• Do not disassemble or modify this product.
  Do not touch internal parts that become exposed as the result of a fall or other accident.
  Failure to observe these precautions could result in electric shock or other injury.
• Should you notice any abnormalities such as the product producing smoke, heat, or unusual odors, immediately disconnect the camera power source.
  Continued operation could result in fi re, burns or other injury.
• Keep dry.
  Do not handle with wet hands.
  Failure to observe these precautions could result in fi re or electric shock.
• Do not use this product in the presence of fl ammable dust or gas such as propane, gasoline or aerosols.
  Failure to observe this precaution could result in explosion or fire.
• Do not directly view the sun or other bright light source through the lens.
  Failure to observe this precaution could result in visual impairment.
• Keep this product out of reach of children.
  Failure to observe this precaution could result in injury or product malfunction. In addition, note that small parts constitute a choking hazard. Should a child swallow any part of this product, seek immediate medical attention.
• Do not handle with bare hands in locations exposed to extremely high or low temperatures.
  Failure to observe this precaution could result in burns or frostbite.

• Do not leave the lens pointed at the sun or other strong light sources.
  Light focused by the lens could cause fi re or damage to product's internal parts. When shooting backlit subjects, keep the sun well out of the frame. Sunlight focused into the camera when the sun is close to the frame could cause fire.
• Do not leave the product where it will be exposed to extremely high temperatures, for an extended period such as in an enclosed automobile or in direct sunlight.
  Failure to observe this precaution could result in fi re or product malfunction.
• Do not transport cameras or lenses with tripods or similar accessories attached.
  Failure to observe this precaution could result in injury or product malfunction.

Notices for Customers in Europe

This symbol indicates that electrical and electronic equipment is to be collected separately.
The following apply only to users in European countries:

• This product is designated for separate collection at an appropriate collec-tion point. Do not dispose of as household waste.
• Separate collection and recycling helps conserve natural resources and prevent nega-tive consequences for human health and the environment that might result from incorrect disposal.
• For more information, contact the retailer or the local authorities in charge of waste management.

Using the Lens

Parts of the Lens: Names and Functions

Refer to the diagram on the left edge of this sheet.

1	Lens hood mounting mark	Use when attaching the lens hood.	See
2	Control ring	Autofocus mode selected: In autofocus mode, rotate the ring to adjust a setting such as [Focus (M/A)] or [Aperture] assigned using the camera. For more information, see the description of [Custom control assignment]/[Custom controls (shooting)] in the camera manual.	—
		Manual focus mode selected: Rotate the ring to focus.
3	Lens mounting mark	Use when mounting the lens on the camera.	See
4	Rubber lens-mount gasket	—	—
5	CPU contacts	Used to transfer data to and from the camera.	—
6	Focus-mode switch	Choose A for autofocus, M for manual focus. Note that regardless of the setting chosen, focus must be adjusted manually when manual focus mode is selected using camera controls.	—
7	Lens hood	Lens hoods block stray light that would otherwise cause fl are or ghosting. They also serve to protect the lens.	See
8	Lens hood lock mark	Use when attaching the lens hood.
9	Lens hood alignment mark
10	Lens cap (front cap)	—	—
11	Lens cap (rear cap)	—	—

Attachment and Removal

Attaching the Lens

1. Turn the camera off, remove the body cap, and detach the rear lens cap.
2. Position the lens on the camera body, keeping the mounting mark on the lens aligned with the mounting mark on the camera body, and then rotate the lens counterclockwise until it clicks into place.

Removing the Lens

1. Turn the camera off.
2. Press and hold the lens release button while turning the lens clockwise.

Attaching and Removing the Lens Hood

Align the lens hood mounting mark with the lens hood alignment mark () and then rotate the hood () until the mounting mark is aligned with the lens hood lock mark ().

To remove the hood, reverse the above steps.

When attaching or removing the hood, hold it near the lens hood alignment mark () and avoid gripping the front of the hood too tightly. The hood can be reversed and mounted on the lens when not in use.

When the Lens Is Attached

The focus position may change if you turn the camera off and then on again after focusing. If you have focused on a pre-selected location while waiting for your subject to appear, we recommend that you do not turn the camera off until the picture is taken.

Precautions for Use

• Do not pick up or hold the lens or camera using only the lens hood.
• Keep the CPU contacts clean.
• Should the rubber lens-mount gasket be damaged, cease use immediately and take the lens to a Nikon-authorized service center for repair.
• Replace the lens caps when the lens is not in use.
• To protect the interior of the lens, store it out of direct sunlight.
• Do not leave the lens in humid locations or in locations in which it may be exposed to moisture. Rusting of the internal mechanism can cause irreparable damage.
• Do not leave the lens next to open fl ames or in other extremely hot locations. Ex-treme heat could damage or warp exterior parts made from reinforced plastic.
• Rapid changes in temperature may cause damaging condensation inside and outside the lens. Before taking the lens from a warm to a cold environment or vice versa, place it in a bag or plastic case to slow the change in temperature.
• We recommend that you place the lens in its case to protect it from scratches during transport.

Lens Care

• Removing dust is normally suffi cient to clean the glass surfaces of the lens.
• Smudges, fi ngerprints, and other oily stains can be removed from the lens surface using a soft, clean cotton cloth or lens cleaning tissue lightly dampened with a small amount of ethanol or lens cleaner. Wipe gently from the center outwards in a circular motion, taking care not to leave smears or touch the lens with your fi ngers.
• Never use organic solvents such as paint thinner or benzene to clean the lens.
• Neutral Color (NC) fi lters (available separately) and the like can be used to protect the front lens element.
• If the lens will not be used for an extended period, store it in a cool, dry location to prevent mold and rust. Do not store in direct sunlight or with naphtha or camphor moth balls.

Accessories

Supplied Accessories

• LC-72B Lens Cap (front cap)
• LF-N1 Lens Cap (rear cap)
• HB-88 Lens Hood
• CL-C1 Lens Case

Using the Lens Case

• The case is intended to protect the lens from scratches, not from falls or other physical shocks.
• The case is not water resistant.
• The material used in the case may fade, bleed, stretch, shrink, or change color when rubbed or wet.
• Remove dust with a soft brush.
• Water and stains can be removed from the surface with a soft, dry cloth. Do not use alcohol, benzene, thinner, or other volatile chemicals.
• Do not store in locations exposed to direct sunlight or high temperatures or humidity.
• Do not use the case to clean the monitor or lens elements.
• Be careful that the lens does not fall from the case during transport.

Material: Polyester

Compatible Accessories

72 mm screw-on fi lters

Filters

• Use only one fi lter at a time.
• Remove the lens hood before attaching fi lters or rotating circular polarizing fi lters.

Specifications

Nikon reserves the right to change the appearance, specifi cations, and performance of this product at any time and without prior notice.

Printed in Japan
