User Manual SL-216-36G-P150 Version 1.0 May 2021...
Page 2
SL-216-36G-P150 Installation manual introduction The Product installation manual mainly describes SL-216-36G-P150 PoE switch hardware features, installation methods, and precautions during the installation This manual includes the following chapters: Chapter 1: Product Introduction. Briefly describes the basic features, Detailed hardware &...
SL-216-36G-P150 Chapter 1: Product Introduction 1.1 Products description SL-216-36G-P150 is managed PoE switch for security transmission and WIFI coverage, meet the need of PoE power supply for WIFI AP, IP-camera, WIFI bridge, IP phones and other types of equipment. New generation of high-performance hardware and software platforms are used, providing flexible, cost-effective full Gigabit access and uplink ports, complete security mechanisms, improved ACL / QoS strategy and rich VLAN capabilities.
Page 4
SL-216-36G-P150 1.3 Product Software and Hardware Specifications Hardware specification Performance Port • Forward mode: store and forward 16 10/100/1000Mbps RJ45 ports • • Backplane bandwidth: 36 Gbps • 2 SFP fiber ports • Packet forwarding rate: 26.76 Mpps • 1 RJ45 Console port Support 8 K MAC address table •...
Page 5
SL-216-36G-P150 Software features Shortcut function Protocol standard • One key VLAN • IEEE 802.3: Ethernet media access • One key Exnted (1-8 port 250meters PoE control (MAC) protocol distance) IEEE 802.3i:10BASE-T Ethernet • • One key QoS (Video priority) •...
Page 6
SL-216-36G-P150 Safety features Multicast • Password protection • Support IGMP v1/v2 Snooping Support user access based on port number, • • Support static multicast IP address, and MAC address restrictions on • Support for multicast VLAN user access • Supports...
Page 7
1. 4 product appearance ◼ front panel Contains indicator light, RJ45 port, SFP Port, DIP switch, RST button, Console port, as shown below ◼ indicator The SL-216-36G-P150 indicator works as shown in the following table. Work Indicators Title Color Description...
Page 8
When the switch mode of operation is CCTV mode, 1-8 port can support 250 meters power supply with 10Mbps speed rate ❖ SFP Port SL-216-36G-P150 provide two Gigabit SFP optical ports expansion slots (25, 26), can be inserted into the Gigabit SFP module. ❖ RST Button When the switch is powered on, press the button with the needle to release the device and enter the restarting state.
Page 9
SL-216-36G-P150 Back Panel Including: power socket, power switch, ground terminal ❖ Power socket A 100-240VAC 50/60 Hz power receptacle for accommodating the supplied power cord ❖ Power switch Turn on/off the power switch, control the power switch ❖ Ground terminal Please use the grounding wire to prevent lightning.
SL-216-36G-P150 Chapter 2 Installation 2.1 Installation Precautions Note: To avoid improper use of equipment damage and personal injury, please observe the following precautions ◼ Installation safety precautions • The power should be kept off during the installation, while wearing anti-static wrist, and to ensure well touch between anti-static wrist and skin to avoid potential safety hazard;...
Page 11
SL-216-36G-P150 ◼ Altitude Products with this logo are only for safe use in areas below 2000m altitude ◼ Dust-proof Dust on the switch surface will cause electrostatic adsorption, poor contact of the metal contacts. Although the device itself has done some measures in anti-static, but when the static electricity exceeds a certain intensity, it will still cause fatal damage to the electronic components on the internal circuit board.
Page 12
2.2 Product installation 19-inch standard rack installation SL-216-36G-P150 is designed according to the standard 19-inch rack size, you can easily install to the rack, the specific installation steps are as follows: First, Check rack grounding and stability;...
Page 13
SL-216-36G-P150 Third, place the switch in an appropriate place in the rack and be supported by the bracket. Screw the L-shaped bracket to the guide groove fixed on both ends of the rack to ensure that the switch is stable and horizontally installed on the rack Note:...
Page 14
SL-216-36G-P150 Step 2: Manually changed the computer IP address to 192.248.254.X (X is 2 ~ 254), subnet mask is 255.255.255.0 Step3: Open computer's browser, type 192.248.254.1 in the address box, hit the Enter key Step4: Enter the default username and password “admin” and then click Login...
SL-216-36G-P150 Chapter 3: Hardware connection 3.1 RJ45 port connection Connect the RJ45 port of the switch and the corresponding network device via cables, the POE power supply function of the switch is default enabled on the downlink port of the switch, which can be used for IEEE802.3af or IEEE802.3at standards powered devices such as APs,...
Page 16
SL-216-36G-P150 3.2 SFP Port connection SL-216-36G-P150 SFP port only support Gigabit fiber module. Recommended use of standard SFP module products The process of installing a fiber module on a switch is as follows: First, grasp the optic fiber module from the side, insert it smoothly along the SFP port slot until the optic fiber module and switch are in close contact;...
SL-216-36G-P150 Step3: Open computer's browser, type 192.248.254.1 in the address box, hit the Enter key Step4: Enter the default username and password “admin” and then click Login Step5: Entered the switch web management interface successfully when you see picture as...
Page 18
SL-216-36G-P150 It is recommended to use the switch indoors. It is recommended to add a waterproof box when using it outdoors. Note: The pictures in the manual are for reference only, whichever is subject to the actual product. Www.techs.is , Sales@techs.is...
