  • Page 1 UPER ® UPER ERVER ® 7048R-TR 7048R-TRT USER’S MANUAL...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
  • Page 3 It provides information for the installation and use of the SuperServer 7048R- TR/7048R-TRT. Installation and maintainance should be performed by experienced technicians only. The SuperServer 7048R-TR/7048R-TRT is a high-end server based on the SC- 745TQ-R920B 4U tower/rackmountable chassis and the X10DRi/X10DRi-T dual processor serverboard.
  • Page 4 UPER ERVER 7048R-TR/7048R-TRT User's Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X10DRi/X10DRi-T serverboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfiguring the serverboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SATA ......................1-2 PCI Expansion Slots ..................1-2 I/O Ports ......................1-2 Graphics Controller ..................1-2 Server Chassis Features ................
  • Page 7 Table of Contents Control Panel Buttons ..................3-1 Power ......................3-1 Reset ....................... 3-1 Control Panel LEDs ..................3-2 Power ......................3-2 HDD ......................... 3-2 NIC1 ........................ 3-2 NIC2 ........................ 3-2 Information LED ....................3-3 Power Fail ....................... 3-3 Drive Carrier LEDs ..................3-4 Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements ............
  • Page 8 UPER ERVER 7048R-TR/7048R-TRT User's Manual Removing the Heatsink ................... 5-7 Installing Memory .................... 5-8 Memory Support ....................5-8 DIMM Installation .................... 5-8 Processor & Memory Module Population Configuration ......5-9 Adding PCI Add-On Cards ................5-10 Serverboard Details ..................5-11 X10DRi/X10DRi-T Quick Reference ............. 5-12 Connector Definitions ...................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 7048R-TR/7048R-TRT is a high-end server comprised of two main subsystems: the SC745TQ-920B 4U server chassis and the X10DRi/X10DRi-T dual processor serverboard. Please refer to our web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 10: Serverboard Features

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Serverboard Features The SuperServer 7048R-TR/7048R-TRT is built around the X10DRi/X10DRi-T, a dual processor serverboard based on the Intel® PCH C612 chipset and designed to provide maximum performance. Below are the main features of the X10DRi/ X10DRi-T.

  • Page 11: Server Chassis Features

    Front Control Panel The control panel on the SuperServer 7048R-TR/7048R-TRT provides you with system monitoring and control. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included.
  • Page 12 UPER ERVER 7048R-TR/7048R-TRT User's Manual Figure 1-1. Chipset Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. #1-8 #2-8 #1-7 VCCP0 12v VCCP1 12v #2-7 VR12.5 #1-6 VR12.5 #2-6 5 PHASE 5 PHASE #1-5 #2-5 145W 145W...

  • Page 13: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 14 UPER ERVER 7048R-TR/7048R-TRT User's Manual Notes...

  • Page 15: Chapter 2 Server Installation

    If the server itself shows damage you should file a damage claim with the carrier who delivered it. Decide on a suitable location for the SuperServer 7048R-TR/7048R-TRT. It should be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and electromagnetic fields are generated.

  • Page 16: Warnings And Precautions

    UPER ERVER 7048R-TR/7048R-TRT User's Manual • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them.

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Installing The System Into A Rack

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Installing the System into a Rack This section provides information on installing the system into a rack unit. Rack installation requires the use of the optional rackmount kit. If the system has already been mounted into a rack or if you are using it as a tower, you can skip ahead to Sections 2-5 and 2-6.

  • Page 19: Installing The Chassis Rails

    Chapter 2: Server Installation Installing the Chassis Rails You will need to remove the top cover and the feet to add rack rails to the chassis. First, remove the top and right covers (top and left covers when standing as a tower chassis) by first removing the screws that secure them to the chassis.

  • Page 20: Installing The Rack Rails

    Figure 2-3. Installing the Rails to the Chassis Installing the Rack Rails Determine where you want to place the SuperServer 7048R-TR/7048R-TRT in the rack. (See Rack and Server Precautions in Section 2-3.) Position the fixed rack rail/ sliding rail guide assemblies at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack.

  • Page 21: Installing The Server Into The Rack

    Chapter 2: Server Installation Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. You should have two brackets in the rack mount kit.
  • Page 22 UPER ERVER 7048R-TR/7048R-TRT User's Manual Notes...

  • Page 23: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview The control panel on the 7048R-TR/7048R-TRT has several LEDs and two but- tons. There are also two LEDs on each hard drive carrier. These LEDs keep you constantly informed of the overall status of the system and the activity and health of specific components.

  • Page 24: Control Panel Leds

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Control Panel LEDs The control panel located on the front of the SC745 chassis has six LEDs that provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective ac- tion you may need to take.

  • Page 25: Information Led

    Chapter 3: System Interface Information LED This LED will be solid blue when the UID function has been activated. When this LED flashes red, it indicates a fan failure. When red continuously it indicates an overheat condition, which may be caused by cables obstructing the airflow in the system or the ambient room temperature being too warm.

  • Page 26: 3-4 Drive Carrier Leds

    UPER ERVER 7048R-TR/7048R-TRT User's Manual 3-4 Drive Carrier LEDs • Green: Each hard drive carrier has a green LED. When illuminated, this green LED (on the front of the hard drive carrier) indicates drive activity. A connec- tion to the backplane enables this LED to blink on and off when that particular drive is being accessed.

  • Page 27: About Standardized Warning Statements

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 28 UPER ERVER 7048R-TR/7048R-TRT User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 29 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 30: Installation Instructions

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 31: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 32: Power Disconnection Warning

    UPER ERVER 7048R-TR/7048R-TRT User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 33 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 34: Equipment Installation

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 35: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 36: Battery Handling

    UPER ERVER 7048R-TR/7048R-TRT User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬...
  • Page 37 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 38: Redundant Power Supplies

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 39: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 40: Comply With Local And National Electrical Codes

    UPER ERVER 7048R-TR/7048R-TRT User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 41: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 42: Hot Swap Fan Warning

    UPER ERVER 7048R-TR/7048R-TRT User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 43 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 44: Power Cable And Ac Adapter

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 45 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 46 UPER ERVER 7048R-TR/7048R-TRT User's Manual Notes 4-20...

  • Page 47: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference. Remember to completely close the chassis when you have finished working with the serverboard to better cool and protect the system.

  • Page 48: Unpacking

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Unpacking The serverboard is shipped in antistatic packaging to avoid electrical static dis- charge. When unpacking the board, make sure the person handling it is static protected. Connecting Cables The cables listed below should already be connected to the serverboard. These include the data cables for the peripherals and control panel and the power cables.

  • Page 49: I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground 3.3 V FP PWRLED HDD LED UID Switch NIC1 Link LED NIC1 Activity LED NIC2 Activity LED NIC2 Link LED OH/Fan Fail/ UID LED PWR Fail LED) Power Fail LED 3.3V Reset Reset Button...

  • Page 50: Installing The Processor And Heatsink

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Installing the Processor and Heatsink Warning: When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components.
  • Page 51 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate finger, remove the 'WARNING'...
  • Page 52 UPER ERVER 7048R-TR/7048R-TRT User's Manual Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the load plate again and double-check that the CPU is aligned properly.

  • Page 53: Installing A Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a CPU Heatsink 1. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism. 2. Screw in two diagonal screws (i.e. the #1 and the #2 screws) until just snug (do not over-tighten the screws, which may damage the CPU.) 3.

  • Page 54: Installing Memory

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Installing Memory Warning: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X10DRi/X10DRi-T supports up to 1 TB of DDR4-2133/1866/1600/1333 RDIMM ECC memory (or 2 TB of LRDIMMs). Use memory modules of the same type and speed.

  • Page 55: Processor & Memory Module Population Configuration

    Chapter 5: Advanced Serverboard Setup Processor & Memory Module Population Configuration For memory to work properly, follow the tables below for memory installation. Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU 1 DIMMA1 DIMMB1 DIMMC1 DIMMD1 DIMMA2 DIMMB2 DIMMC2 DIMMD2...

  • Page 56: Adding Pci Add-On Cards

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Adding PCI Add-On Cards The 7048R-TR/7048R-TRT can accommodate six full-height, full-length PCI add- on cards. Installing an Add-on Card 1. Begin by removing the shield for the PCI slot you wish to populate. 2. Fully seat the card into the slot, pushing down with your thumbs evenly on both sides of the card.

  • Page 57: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-4. X10DRi/X10DRi-T Layout (not drawn to scale) USB0/1(3.0) USB0/1 (2.0) COM1 USB12/13 LAN CTRL Fan5 (USB 2.0) LEDM1 IPMI_LAN LAN1 LAN2 BIOS CLOSE 1st CPU2 OPEN 1st JPME2 X10DRi-(T) Rev. 1.01 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery...

  • Page 58: X10Dri/X10Dri-T Quick Reference

    UPER ERVER 7048R-TR/7048R-TRT User's Manual X10DRi/X10DRi-T Quick Reference Jumper Description Default Setting JBR1 BIOS Recovery Enable/Disable Pins 1-2 (Normal) JBT1 Clear CMOS See Section 5-9 C1/JI SMB to PCI-E Slots Enable/Disable Off (Disabled) JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1...
  • Page 59 Chapter 5: Advanced Serverboard Setup (CPU2) Slot5 PCI-Express 3.0 x8 Slot from CPU2 (CPU2) Slot6 PCI-Express 3.0 x16 Slot from CPU2 (T-)SGPIO1/2/3 Serial Link General Purpose I/O Headers Internal Speaker/Buzzer (BP) USB 0/1 Backpanel USB 2.0 Ports 0/1 (BP) USB 12/13 Backpanel USB 2.0 Ports 12/13, or USB 3.0 Ports 0/1 (FP) USB 2/3, 4/5 Front Accessible USB 2.0 Connection Headers 2/3, 4/5...

  • Page 60: Connector Definitions

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Connector Definitions ATX Power 24-pin Connector Pin Definitions Pin# Definition Pin # Definition Power Connectors +3.3V +3.3V -12V +3.3V A 24-pin main power supply connector (J24) and two 8-pin power connectors (JPWR1/JPWR2) are provided on the PS_ON serverboard.
  • Page 61 Chapter 5: Advanced Serverboard Setup Power Fail LED PWR Fail LED Pin Definitions (JF1) The Power Fail LED connection is Pin# Definition located on pins 5 and 6 of JF1. Refer 3.3V to the table on the right for pin defini- tions.
  • Page 62 UPER ERVER 7048R-TR/7048R-TRT User's Manual Power LED Power LED Pin Definitions (JF1) The Power LED connection is located Pin# Definition on pins 15 and 16 of JF1. Refer to the 3.3V table on the right for pin definitions. PWR LED Fan Headers There are eight fan headers on the serverboard (Fan 1-Fan 6, Fan A, Fan...
  • Page 63 Chapter 5: Advanced Serverboard Setup Internal Buzzer (SP1) Pin Definition Pin# Definitions Internal Speaker Pin 1 Pos. (+) Beep In The Internal Speaker, located at SP1, Pin 2 Neg. (-) Alarm can be used to provide audible indica- Speaker tions for various beep codes. See the table on the right for pin definitions.
  • Page 64 UPER ERVER 7048R-TR/7048R-TRT User's Manual Standby Power Standby Power Pin Definitions Pin# Definition The Standby Power header is located +5V Standby at JSTBY1 on the serverboard. See Ground the table on the right for pin defini- Wake-up tions. (You must also have a cable to use this feature.) PWR SMB Pin Definitions...
  • Page 65 Chapter 5: Advanced Serverboard Setup Universal Serial Bus (USB) Backplane USB FP USB (4/5, 6) (USB 0/1, 2/3) Pin Definitions Two USB 2.0 ports (USB 0/1) and two Pin Definitions USB 4, 6 USB 5 USB 2.0/3.0 ports (USB12/13) are lo- Pin # Definition Pin # Definition Pin# Definition...

  • Page 66: Jumper Settings

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Unit Identifier Switch/UID LED Indicator A Unit Identifier (UID) switch and an LED indicator are provided on the motherboard. The rear UID switch is UID Switch located next to the VGA port on the Pin# Definition backplane.
  • Page 67 Chapter 5: Advanced Serverboard Setup CMOS Clear JBT1 is used to clear CMOS (which will also clear any passwords). Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To clear CMOS, 1. First power down the system and unplug the power cord(s). 2.
  • Page 68 UPER ERVER 7048R-TR/7048R-TRT User's Manual Manufacturer Mode Select Close pins 2 and 3 of jumper JPME2 to bypass SPI flash security and force ME Mode Select Jumper Settings the system to operate in the Manufac- Jumper Setting Definition turer Mode, which allows the user to Pins 1-2 Normal (Default) flash the system firmware from a host...

  • Page 69: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators LAN LEDs The Ethernet ports (located beside the JLAN1/2 LED VGA port) have two LEDs. On each (Connection Speed Indicator) port, one LED flashes to indicate activ- LED Color Definition ity while the other LED may be green, 10 Mb/s, 100 Mb/s or no connection amber or off to indicate the speed of...

  • Page 70: 5-11 Sata Ports

    UPER ERVER 7048R-TR/7048R-TRT User's Manual 5-11 SATA Ports SATA 3.0 Ports SATA Port There are ten Serial ATA Ports, which Pin Definitions include six SATA supported by the Pin# Definition Definition PCH C612 (I-SATA0 ~5) and four Ground SATA supported by the Intel SCU (S- Ground SATA0~3).

  • Page 71: 5-12 Installing Software

    Chapter 5: Advanced Serverboard Setup 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 72: Superdoctor® 5

    UPER ERVER 7048R-TR/7048R-TRT User's Manual SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program moni- tors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 73: 5-13 Onboard Battery

    Chapter 5: Advanced Serverboard Setup 5-13 Onboard Battery Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.
  • Page 74 UPER ERVER 7048R-TR/7048R-TRT User's Manual Notes 5-28...

  • Page 75: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform simple maintenance on the SC745TQ-R920B chassis. Following the component installation steps in the order given will eliminate most common problems. If some steps are unnecessary, skip ahead to the step that follows.
  • Page 76 UPER ERVER 7048R-TR/7048R-TRT User's Manual Figure 6-1. Chassis Front and Rear Views USB Ports Control Panel 5.25" Drive Bays (3) 8 Hard Drive Bays (behind locking bezel) Power Supplies Rear Fans Rear I/O Ports PCI Slots...

  • Page 77: Front Control Panel

    Chapter 6: Advanced Chassis Setup Front Control Panel The front control panel must be connected to the JF1 connector on the serverboard to provide you with system status and alarm indications. A ribbon cable has bundled these wires together to simplify this connection. Connect the cable from JF1 on the serverboard (making sure the red wire plugs into pin 1) to the appropriate comnnec- tor on the front control panel PCB (printed circuit board).

  • Page 78: System Fans

    UPER ERVER 7048R-TR/7048R-TRT User's Manual System Fans Three 8-cm chassis cooling fans (located in the center of the chassis) provide cool- ing airflow while two 8-cm exhaust fans expel hot air from the chassis. The chassis is also fitted with an air shroud to concentrate the flow of cooling air over the areas of highest generated heat.
  • Page 79 Chapter 6: Advanced Chassis Setup Removing the Air Shroud Under most circumstances you will not need to remove the air shroud to perform any service on the system. However, if you wish to temporarily remove it (the air shroud should always be in place when the system is operating), please follow this procedure.

  • Page 80: Drive Bay Installation

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Drive Bay Installation SATA Hard Drives A total of eight 3.5: SATA drives may be housed in the SC745 chassis. The drive IDs are preconfigured as 0 through 7 in order from bottom to top (or from left to right if rackmounted).

  • Page 81: Sata Backplane

    Chapter 6: Advanced Chassis Setup Figure 6-5. Removing a Drive Carrier Figure 6-6. Mounting a Drive in a Carrier Warning: Use extreme caution when working around the SATA backplane. Do not touch the backplane with any metal objects and make sure no cables touch the back- plane or obstruct the airflow holes.

  • Page 82: Storage Module

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Installing Components in the 5.25" Drive Bays The 7048R-TR/7048R-TRT has two 5.25" drive bays. DVD-ROM drives can be installed into these 5.25" drive bays. 1. First power down the system and then remove the top/left chassis cover to access the drive components.
  • Page 83 Chapter 6: Advanced Chassis Setup Figure 6-7. Rotating the Storage Module Storage Module Storage Module Release Lever...

  • Page 84: Power Supply

    ERVER 7048R-TR/7048R-TRT User's Manual Power Supply The SuperServer 7048R-TR/7048R-TRT has a redundant 920 watt power supply consisting of two power modules. Each power supply module has an auto-switching capability, which enables it to automatically sense and operate at a 100V - 240V input voltage.

  • Page 85: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS setup utility for the X10DRi/X10DRi-T. The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS setup utility screens. Note: For AMI BIOS recovery, please refer to the UEFI BIOS Recovery Instructions in Appendix C.

  • Page 86: Main Setup

    UPER ERVER 7048R-TR/7048R-TRT User's Manual How to Start the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS setup utility. From the main menu, you can access the other setup screens.
  • Page 87 Chapter 7: BIOS The following Main menu items will be displayed: System Date/System Time Use this option to change the system date and time. Highlight System Date or System Time using the arrow keys. Enter new values using the keyboard. Press the <Tab>...

  • Page 88: Advanced Setup Configurations

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 89 Chapter 7: BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...
  • Page 90 UPER ERVER 7048R-TR/7048R-TRT User's Manual CPU Configuration  North Bridge This feature allows the user to configure the settings for the Intel North Bridge. IIO Configuration EV DFX (Device Function On-Hide) Features When this feature is set to Enable, the EV_DFX Lock Bits that are located on a processor will always remain clear during electric tuning.
  • Page 91 Chapter 7: BIOS The following items will be display: PCI-E Port Link Status PCI-E Port Link Max PCI-E Port Link Speed PCI-E Port L0s Exit Latency Use this feature to set the length of time required for the port specified by the user to complete the transition from L0s to L0.
  • Page 92 UPER ERVER 7048R-TR/7048R-TRT User's Manual No PCIe Port Active ECO Use this feature to select a workaround setting to implement the engineering- change order (ECO) on the system when PCI ports are not active. The options are PCU Squelch exit ignore option and Reset the SQ FLOP by CSR option. IOAT Configuration Enable I/OAT Select Enable to enable Intel I/OAT (I/O Acceleration Technology), which signifi-...
  • Page 93 Chapter 7: BIOS Coherency Support (Isoch) Select Enable for the Iscoh VT-d engine to pass through ATS to enhance system performance. The options are Enable and Disable. QPI (Quick Path Interconnect) Configuration The following QPI information will be displayed: • Number of CPU •...
  • Page 94 UPER ERVER 7048R-TR/7048R-TRT User's Manual Memory Configuration Enforce POR Select Enable to enforce POR restrictions on DDR4 frequency and voltage pro- gramming. The options are Auto, Enforce POR, Disabled and Enforce Stretch Goals. Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules.
  • Page 95 Chapter 7: BIOS Rank Interleaving Use this item to select a rank memory interleaving method. The options are Auto, 1-Way, 2-Way, 4-Way, and 8-Way. A7 Mode Select Enabled to support the A7 (Addressing) mode to improve memory per- formance. The options are Enable and Disable. DIMM Information This item displays the status of a DIMM module specified by the user.
  • Page 96 UPER ERVER 7048R-TR/7048R-TRT User's Manual write back one cache line every 16K cycles, if there is no delay caused by internal processing. By using this method, roughly 64 GB of memory behind the IO hub will be scrubbed every day. The options are Enable and Disable. Patrol Scrub Interval This feature allows you to decide how many hours the system should wait be- fore the next complete patrol scrub is performed.
  • Page 97 Chapter 7: BIOS XHCI Hand-Off This is a work-around solution for operating systems that do not support XHCI (Ex- tensible Host Controller Interface) hand-off. The XHCI ownership change should be claimed by the XHCI driver. The settings are Enabled and Disabled. EHCI Hand-Off This item is for operating systems that do not support Enhanced Host Controller Interface (EHCI) hand-off.
  • Page 98 UPER ERVER 7048R-TR/7048R-TRT User's Manual SATA Configuration  When this submenu is selected, AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the fol- lowing items: SATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
  • Page 99 Chapter 7: BIOS Port 0 ~ Port 5 SATA Device Type Use this item to specify if the SATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 100 UPER ERVER 7048R-TR/7048R-TRT User's Manual Port 0 ~ Port 5 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a SATA disk drive installed on this port without shutting down the system.
  • Page 101 Chapter 7: BIOS • Software Preserve Support sSATA Port 0~ Port 3 Select Enabled to enable an sSATA port specified by the user. The options are Disabled and Enabled. sSATA Port 0 ~ Port 3 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a sSATA disk drive installed on this port without shutting down the system.
  • Page 102 UPER ERVER 7048R-TR/7048R-TRT User's Manual sSATA RAID Option ROM/UEFI Driver Select EFI to load the EFI driver for system boot. Select Legacy to load a legacy driver for system boot. The options are Disabled, EFI, and Legacy. sSATA Port 0~ Port 3 This item displays the information detected on the installed sSATA drives on the particular sSATA port.
  • Page 103 Chapter 7: BIOS • ME Firmware Status #2 • Current State • Error Code Altitude This feature indicates the altitude of the platform this machine is located above the sea level. The value is shown in meters. If the value is unknown, enter the number "80000000".
  • Page 104 UPER ERVER 7048R-TR/7048R-TRT User's Manual Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Enabled and Disabled. SR-IOV (Available if the system supports Single-Root Virtualization) Select Enabled for Single-Root IO Virtualization support.
  • Page 105 Chapter 7: BIOS Onboard LAN Option ROM Type Select Enabled to enable Option ROM support to boot the computer using a device installed on the slot specified by the user. The options are Legacy and EFI. Onboard LAN1 Option ROM/Onboard LAN2 Option ROM Use this option to select the type of device installed in LAN Port1 or LAN Port2 used for system boot.
  • Page 106 UPER ERVER 7048R-TR/7048R-TRT User's Manual Device Mode Use this feature to configure SUART clock source settings. The options are 24MHz/13 and 24MHz. Serial Port 2 Attribute Select SOL to use COM Port 2 as a Serial_Over_LAN (SOL) port for console redi- rection.
  • Page 107 Chapter 7: BIOS is odd. Select None if you do not want to send a parity bit with your data bits in transmission. Select Mark to add a mark as a parity bit to be sent along with the data bits. Select Space to add a Space as a parity bit to be sent with your data bits.
  • Page 108 UPER ERVER 7048R-TR/7048R-TRT User's Manual SOL/COM2 Console Redirection Select Enabled to use the SOL port for Console Redirection. The options are Enabled and Disabled. *If the item above set to Enabled, the following items will become available for user's configuration: SOL/COM2 Console Redirection Settings Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.
  • Page 109 Chapter 7: BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start data-sending when the receiving buffer is empty.
  • Page 110 UPER ERVER 7048R-TR/7048R-TRT User's Manual *If the item above set to Enabled, the following items will become available for user's configuration: Out-of-Band Management Port The feature selects a serial port in a client server to be used by the Windows Emergency Management Services (EMS) to communicate with a remote host server.
  • Page 111 Chapter 7: BIOS Trusted Computing (Available when a TPM device is installed and detected by the BIOS) Configuration Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM support to enhance data integrity and network security.
  • Page 112 UPER ERVER 7048R-TR/7048R-TRT User's Manual ACPI Settings  WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) plat- form and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.

  • Page 113: Event Logs

    Chapter 7: BIOS Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 114 UPER ERVER 7048R-TR/7048R-TRT User's Manual Memory Correctable Error Threshold Use this item to enter the threshold value for correctable memory errors. The default setting is 10. Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup.

  • Page 115: Ipmi

    Chapter 7: BIOS IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system. System Event Log ...
  • Page 116 UPER ERVER 7048R-TR/7048R-TRT User's Manual When SEL is Full This feature allows the user to determine what the BIOS should do when the sys- tem event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 117 Chapter 7: BIOS Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). Router MAC Address This item displays the Router MAC address for this computer. 7-33...

  • Page 118: Security Settings

    UPER ERVER 7048R-TR/7048R-TRT User's Manual Security Settings This menu allows the user to configure the following security settings for the system. Administrator Password Use this feature to set the administrator password which is required before entering the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.

  • Page 119: Boot Settings

    Chapter 7: BIOS Boot Settings Use this feature to configure Boot Settings: Boot Mode Select Use this item to select the type of device to be used for system boot. The options are Legacy, UEFI, and Dual. The default setting is Dual. Fixed Boot Order Priorities This option prioritizes the order of bootable devices that the system to boot from.
  • Page 120 UPER ERVER 7048R-TR/7048R-TRT User's Manual • Dual Boot Order #10 • Dual Boot Order #11 • Dual Boot Order #12 • Dual Boot Order #13 • Dual Boot Order #14 • Dual Boot Order #15 Add New Boot Option This feature allows the user to add a new boot option to system boot features. Add Boot Option Use this item to specify the name of the driver that the new boot option is added to.

  • Page 121: Save & Exit

    Chapter 7: BIOS Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 122 UPER ERVER 7048R-TR/7048R-TRT User's Manual Restore Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter>. These are manufacture default settings designed for maximum system performance but not for maximum stability. Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <En- ter>.

  • Page 123: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 124 UPER ERVER 7048R-TR/7048R-TRT User's Manual Notes...

  • Page 125: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Single or dual Intel® E5-2600 Series (v3) Socket R3 processors in LGA 2011 sockets (both CPUs must be of the same type) Note: All PCI-E slots will not be enabled when using only a single processor. See the motherboard layout on page 5-11 for details.
  • Page 126 UPER ERVER 7048R-TR/7048R-TRT User's Manual Serverboard X10DRi/X10DRi-T Dimensions: 12.1 x 13.05 in (307 x 331 mm) Chassis SC745TQ-R920B, tower/4U rackmount Dimensions (as tower): (WxHxD) 7 x 19 x 27 in. (178 x 483 x 686 mm) Weight 70 lbs. (31.8 kg.) System Cooling Three 8-cm system cooling fans Two 8-cm rear exhaust fans...
  • Page 127 Appendix B: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 128 UPER ERVER 7048R-TR/7048R-TRT User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

Superserver 7048r-trt

Table of Contents
