Connections

Connect the cables based on the diagram below.
When the exacqVision System boots, exacqVision Server automatically starts as a background service
and begins recording. The operating system will then auto login to the user account. Both user and
admin accounts are configured to start exacqVision Client immediately upon login.
The video recording factory defaults are:
1) All cameras enabled for motion based recording
2) All cameras recording at 2CIF resolution and 15 images per second
3) Audio recording is disabled
To change any of these defaults, see the Setup Mode section of the user manual.
IP Video Surveillance Solutions
7/19/2010
exacqVision EL-S
Hybrid Linux NVR
Appliance
Quick Start Guide
11955 Exit 5 Pkwy
Building 3
Fishers, IN 46037-7939
USA
+1.317.845.5710 phone
+1.317.845.5720 fax
www.exacq.com
www.exacq.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL-S and is the answer not in the manual?

Questions and answers

Related Manuals for exacqVision EL-S

Summary of Contents for exacqVision EL-S

  • Page 1 Connections Connect the cables based on the diagram below. When the exacqVision System boots, exacqVision Server automatically starts as a background service and begins recording. The operating system will then auto login to the user account. Both user and admin accounts are configured to start exacqVision Client immediately upon login.
  • Page 2 5.) Under Set Password By Hand, enter the new password and confirm it. 6.) Click OK, and then click OK again. Once the exacqVision Server begins recording video, it will continue even if no user is logged in or no exacqVision Client is running. It will stop recording only if: ...
  • Page 3 User Setup The exacqVision Server can be accessed from multiple exacqVision Clients that can be run either on the exacqVision Server or from remotely networked computers. Each operating system account maintains separate settings for exacqVision Client. These settings include usernames, passwords, and network addresses required for the exacqVision Client to access exacqVision Servers.
