Xenon Illuminator with Manual Dimming
LIT-259 Sunoptic Surgical
Rev. B
Titan X400
(US Patent 9,772,094 and 7,510,313)
Control Operator Manual
Sunoptic Technologies
6018 Bowdendale Avenue
Jacksonville, FL 32216 USA
Customer Service: 904 737 7611
Toll Free 877 677 2832
AJW Technology Consulting GmbH
Breite Straße 3
40213 Düsseldorf, Germany
Telephone: +49 211 54059 6030
®
Page 1 of 100
®
English)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sunoptic Surgical Titan X400
Summary of Contents for Sunoptic Surgical Titan X400
- Page 1 Titan X400 (US Patent 9,772,094 and 7,510,313) Xenon Illuminator with Manual Dimming Control Operator Manual Sunoptic Technologies ® 6018 Bowdendale Avenue Jacksonville, FL 32216 USA Customer Service: 904 737 7611 Toll Free 877 677 2832 AJW Technology Consulting GmbH Breite Straße 3 40213 Düsseldorf, Germany...
-
Page 2: Table Of Contents
6.2 Operation 7. CLEANING AND DISINFECTION 8. MAINTENANCE, SERVICING, REPAIR & WARRANTY 8.1 Lamp Replacement 8.2 Limited Warranty 8.3 Repair 8.4 Troubleshooting 9. END OF PRODUCT LIFE 10. SYMBOLOGY ® LIT-259 Sunoptic Surgical Rev. B English) Page 2 of 100... -
Page 3: Introduction
1. INTRODUCTION Congratulations on the purchase of your new Titan X400 Xenon Illuminator! This user-friendly Xenon Illuminator is a high efficiency light source utilizing state-of-the-art illumination technology. It offers a variety of features such as: • 5600 K daylight brightness for perfect color definition •... -
Page 4: Warnings And Cautions
Use only the power cord supplied with illuminator or medically approved power cords with less than 200mΩ of ground impedance and less than 16ft (<5m) of length. If unauthorized ® LIT-259 Sunoptic Surgical Rev. B English) Page 4 of 100... -
Page 5: Cautions
Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user and/or patient is established. ® LIT-259 Sunoptic Surgical Rev. B English) Page 5 of 100... -
Page 6: Specifications
Degree of safety in the Equipment is NOT suitable for use in the presence of presence of Flammable flammable anesthetics. Anesthetics Mode of operation Continuous ® LIT-259 Sunoptic Surgical Rev. B English) Page 6 of 100... -
Page 7: Overview
Turns illuminator ON and OFF. Illuminates blue when ON. Intensity Control Mechanically adjusts light intensity Turret Auto Shutter turret accepts end tip of fiber optic cable. Light is shuttered when no cable is present ® LIT-259 Sunoptic Surgical Rev. B English) Page 7 of 100... - Page 8 Ground Stud For potential equalization AC Mains Inlet and Accepts AC Power cord and switches on AC power Switch Circuit Breaker Over current protection ® LIT-259 Sunoptic Surgical Rev. B English) Page 8 of 100...
-
Page 9: Setup And Operation
The hour meter located on the rear of the unit shows the total elapsed running time of the unit. When the lamp is replaced, reset the hour meter to track total lamp usage hours on the replacement lamp. ® LIT-259 Sunoptic Surgical Rev. B English) Page 9 of 100... -
Page 10: Cleaning And Disinfection
Only handle lamps with protective covers in place. WARNING: Do not change lamp while touching patient. NOTE: This illuminator is designed for exclusive use with the Sunoptic Surgical P/N: SSX0400 lamp module. Failure to use this lamp could void warranty. -
Page 11: Repair
Please contact customer service to issue a return authorization to return product to manufacturer at the end of product life. 10. SYMBOLOGY Manufacturer Date of manufacture (YYYY-MM-DD) Symbol for Authorized Representative in the European Community ® LIT-259 Sunoptic Surgical Rev. B English) Page 11 of 100... - Page 12 Caution: Dangerous Voltage Storage / Shipping Humidity Barometric Pressure Unique Device Identifier Keep Dry AC Current Product Safety Mark Equipotentiality Power on Power off Type BF Protective Earth (Ground) ® LIT-259 Sunoptic Surgical Rev. B English) Page 12 of 100...
