LIT-239 SUNOPTIC SURGICAL
Rev. A
HDC-300C
Titan HD Camera
Instructions for Use
Version 1.0
Sunoptic Technologies
6018 Bowdendale Avenue
Jacksonville, FL 32216 USA
Customer Service: 904 737 7611
Toll Free 877 677 2832
EC|REP
AJW Technology Consulting GmbH
Königsallee 106
40215 Düsseldorf, Germany
+49 (0) 211 3013 2232
®
Page 1 of 21
®
(English)
Advertisement
Table of Contents
Related Manuals for Sunoptic Surgical HDC-300C
Summary of Contents for Sunoptic Surgical HDC-300C
- Page 1 Jacksonville, FL 32216 USA Customer Service: 904 737 7611 Toll Free 877 677 2832 EC|REP AJW Technology Consulting GmbH Königsallee 106 40215 Düsseldorf, Germany +49 (0) 211 3013 2232 ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 1 of 21...
-
Page 2: Table Of Contents
5.7 KEYBOARD CONTROLS 5.8 FOOTSWITCH 5.9 FAULT DISPLAYS CLEANING AND DISINFECTION MAINTENANCE, SERVICING & REPAIR, WARRANTY 7.1 USER SERVICE AND MAINTENANCE 7.2 LIMITED WARRANTY 7.3 REPAIR END OF PRODUCT LIFE SYMBOLOGY ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 2 of 21... -
Page 3: Introduction
Displayed images and videos may be captured and stored internally or transferred or transmitted via a variety of means, controlled through the device’s integrated touch panel. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 3 of 21... -
Page 4: Specifications
According to the degree of Equipment is NOT suitable for use in the presence of safety in the presence of flammable anesthetics. Flammable Anesthetics According to the mode of Continuous operation ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 4 of 21... -
Page 5: General Warnings
(where the power cord attaches to the equipment) so that it is readily accessible. 9. Use only the provided medical grade power cord and replacement fuses specified by the manufacturer to reduce risk of harm resulting from fire or interruption of ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 5 of 21... - Page 6 Do not remove the cover. Return the device to the manufacturer for service. NOTE: The warranty is void if any of these warnings or cautions are disregarded. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 6 of 21...
-
Page 7: Product Overview
Controls all aspects of Camera Console On Button Turns the unit on or off USB Storage Port For external flash drives to store video and pictures Camera Port Accepts the camera cable ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 7 of 21... - Page 8 Allows user to connect to recorder via Ethernet Stabilizer Ethernet Port Allows user to connect to stabilizer via Ethernet Foot Pedal Port Accepts the 2.5mm plug from foot pedal ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 8 of 21...
-
Page 9: The Camera Head
COMPATIBLE ACCESSORIES Figure 4 - Compatible Accessories for the Camera System Name Function Fiber Optic Cables Transmit light from external light source Headband Adjustable headband system Camera Head Record video ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 9 of 21... -
Page 10: Setup And Interconnection
DVI 1 Unstabilized Video DVI 2 Unstabilized Video Follow the instructions for setting up the monitor(s) and connect to the Sunoptic HDC-300 Camera Console using either HDMI or DVI cables. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 10 of 21... -
Page 11: Connecting Ac Power
Please allow approximately 30 seconds for the system to shut down completely ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 11 of 21... -
Page 12: Operation
This menu option will detail instructions on how to access the Patient Data entry form within the camera system. Add information using the external keyboard. Press Enter to return to begin recording video or Esc to stop data entry. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 12 of 21... -
Page 13: Review/Play Cases
Copies the selected file to the USB drive inserted into USB Port 1. USB1 Back Exits Record menu to main menu, video recording will continue. Close file and Exit Exits Recording file to Home Screen, video recording will stop. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 13 of 21... -
Page 14: Settings
HAVE TO BE COMPLETELY RESET AT THE FACTORY. Auto File Division Set the size for automatic file division at either 4 GB or 1 GB. 1 GB is standard to make file transfer easier. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 14 of 21... - Page 15 See "Copy to (from Internal HDD)". Contact Sunoptic Technologies for additional information. IP Address Choose between automatic and manual IP Address. Current IP Shows all current IP Address information. Address Exit Exits Main Menu. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 15 of 21...
-
Page 16: Keyboard Controls
Press F12 or access Record > Close File and Exit to stop recording. Same functionality as F3. Closes file and exits recording for any video playing or being recorded. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 16 of 21... -
Page 17: Footswitch
Figure 5 - TASCAM Footswitch Name Function Stop Stops video recording or playback. Video/Pause Starts new video or new file, pauses video that is playing or recording. Photo Take photo of current screen. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 17 of 21... -
Page 18: Fault Displays
If the internal air temperature exceeds preset limits this screen will display. The fan will run to reduce the temperature. If acceptable reduction is achieved within ten seconds, the system will turn back on to resume normal operation. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 18 of 21... -
Page 19: Cleaning And Disinfection
Follow all applicable blood borne pathogen procedures as required by OSHA and/or your hospital, when cleaning and disinfecting the product. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 19 of 21... -
Page 20: Maintenance, Servicing & Repair, Warranty
The HD camera system must be disposed of according to local laws and hospital practices. Warning: The camera console contains a lithium coin cell battery. This battery must be disposed of properly according to local regulations. ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 20 of 21... -
Page 21: Symbology
Not for disposal in general waste Caution: Hot Surface Caution: Dangerous Voltage Product Safety Mark Do not use if package is damaged. AC Current Equipotentiality Power on Power off Type BF Protective Earth (Ground) ® LIT-239 SUNOPTIC SURGICAL Rev. A (English) Page 21 of 21...
