HD7825/74 /75 /79 DISASSEMBLY- AND RE-ASSEMBLY ADVISE Before you start dismantling! To remove the brew chamber head assy, follow below steps: For your safety be sure the plug is disconnected - Remove the back cover. from the mains! - Place the appliance in front of you in such a way that you The product is designed for easy access to the internal are facing the rear side of the appliance.
HD7825/74 /75 /79 REPAIR INSTRUCTION Note: Volume adjustment Please note after replacing the boiler the appliance has to be The PCB circuit board makes it possible to adjust the volume restored to factory default. The fi lling procedure (cold fl ush), output by means of pushing the one-cup and two-cup user known from the predecessor Senseo’s is no longer available controls.
Page 4
HD7825/74 /75 /79 REPAIR INSTRUCTION Filling procedure: Please note, the software of the Senseo Viva Café has changed, compared to predecessor Senseo’s! The fi lling procedure known from predecessor Senseo’s is no longer available. The command originally used to initiate the fi lling procedure (cold fl...
HD7825/74 /75 /79 PARTS LIST Service code Description Remark 4222 259 44211 Pad holder assy 1-cup Deep black 4222 259 44221 Pad holder assy 2-cup Deep black 4222 247 42550 Collector 4222 259 45072 Spout cover Metal 4222 259 48241 Spout assy Black 4222 240 00522...
