- Page 1 BC182 Manual Eunorau-ebike.com User Manual BC182 Series Version: CH-V0.2...
-
Page 2: Table Of Contents
OTA upgrade (Bluetooth Version Only).............9 Advanced Menu ..................10 Enter Advanced Menu ................10 Wheel Diameter..................10 Speed Sensor ..................10 Battery Voltage Setting ................11 Exit ....................11 EUNORAU App Using Manual................12 Attentions ....................13 EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 3: Appearance And Size
Eunorau-ebike.com BC182 Manual Appearance and Size Display Appearance Drawing Size Specification Display Size Specification EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 4: Features Introduction
Cycling Ranking Riding Track Records Button Description Button Name Function 1、 Power on/off [Power] 2、 Function Confirmation 1、 Parameter Adjustment 2、 Light on/off 3、 Menu Operation 1、Parameter Adjustment 2、Push Assist Starts/Shuts 3、Menu Operation EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 5: Operation
Under power off status, long press [Power] to enter logo interface with power-on interface after 1s and cycling interface after 2s. In any working interfaces, long press [Power]to switch off. Cycling Interface The cycling interface supports multiple parameters display: EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 6: Gears Shifts
Reset Trip Range Long press [Power] and [+] synchronously to reset the trip range: 。Note: For the Bluetooth version, the max speed, average speed, the total trip time and calories can be reset synchronously. Error Display EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 7: User Menu
The speed limits, data unit, auto power-off time and backlight brightness can be set up. The Bluetooth connection can be set in menu with Bluetooth version. If the interface doesn’t operate for 60s, system will return Riding interface automatically. EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... - Page 8 Clicking on [Power] to confirm and save, then shift to “OK” interface, it returns to setting menu automatically after 2s standstill. 4、 Speed Limits Adjustment Selecting menu “Speed Limit”, click on [+] / [-] to adjust speed limiting, the range is 12- EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com...
-
Page 9: Ota Upgrade (Bluetooth Version Only)
2s standstill. 5、 Bluetooth connection setting User can search - “EUNORAU GO” in your App Store or Google Play, or scan the following QR code to download the mobile app. To connect the display for the first time, it need choose “Connect To APP” in menu, scan QR code by APP to bind E-bike. -
Page 10: Advanced Menu
Speed Sensor Select menu “Speed Sensor”, click on [+]/[-]to adjust digit, adjustment range: 1-12. Clicking on [Power] to confirm and save, then shift to “OK” interface, it returns to setting menu automatically after 2s standstill. EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 11: Battery Voltage Setting
36V/48V/52V, click on [Power]to confirm and save, then switch to next interface. Exit 1. If there’s no operation for 60s in any working interface, system enters Riding interface automatically. 2. Long press [Power] for one second in any working interface, system shuts down. EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... -
Page 12: Eunorau App Using Manual
Eunorau-ebike.com BC182 Manual EUNORAU APP USING MANUAL 1，After connecting by Bluetooth, choose the model you need to pair. 2，Enter this page, you can see the Bluetooth status. Also some function settings and the riding data show here. A. You can set some function, e.g. Headlights off/on, Unit Switch and Gear adjustment. - Page 13 3，Enter Riding Status page A. Click “Start” , start the riding B. Click “Pause”, pause the riding. If continue the riding, click “Continue”, otherwise touch “Destroy”, end the riding. EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com...
-
Page 14: Attentions
2. Please make sure to fix the inner hexagon screws with maximum torsion value less than 1Nm, otherwise it causes device damaged; 3. The device is not permitted to soak in water; EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com... - Page 15 Please do not discard device or any accessories as domestic garbage; 7. Improper installation, human damage and failure are not covered by the after-sale warranty; 8. Please contact info@eunorau-ebike.com for pre-sale and after-sale matters. EUNORAU E-MOBILITY USA CORP Eunorau-ebike.com...
