Tecnosystemi smart clima GALILEO-SGL User Manual page 3

DIMENSIONI "GALILEO SGL ECO STAFFA "
/"GALILEO SGL ECO BRACKET" DIMENSIONS
800
A
CARATTERISTICHE TECNICHE "GALILEO SGL STAFFA" / "GALILEO SGL BRACKET" TECHNICAL FEATURES
• LAMIERA ELETTROZINCATA
• STAFFA CON BOLLA IN DOTAZIONE
• VERNICIATURA POLIESTERE DA ESTERNO
• BARRA A MURO DENTELLATA
• PREDISPOSTA PER BACINELLA CON CAVO SCALDANTE
• ANTIVIBRANTI "NO - SHOCK" IN DOTAZIONE
• TASSELLI DI FISSAGGIO
• PIEDINI POSTERIORI SNODATI REGOLABILI
CARATTERISTICHE TECNICHE "GALILEO SGL ECO STAFFA" / "GALILEO SGL ECO BRACKET" TECHNICAL FEATURES
• LAMIERA ELETTROZINCATA
• STAFFA CON BOLLA IN DOTAZIONE
• VERNICIATURA POLIESTERE DA ESTERNO
• BARRA A MURO DENTELLATA
• PREDISPOSTA PER BACINELLA CON CAVO SCALDANTE
• ANTIVIBRANTI A SCORRIMENTO
• TASSELLI DI FISSAGGIO
• PIEDINI POSTERIORI SNODATI REGOLABILI
CODICE
/ CODE
D
111000071X
11000090X
SCD500085
DIMENSIONI
/ DIMENSIONS
A [mm] B [mm] C [mm]
440/745 180/340
440/745 180/385
440/745 240/465
• ELECTRO-GALVANISED SHEET METAL
• BRACKET FITTED WITH SPIRIT LEVEL
• EXTERIOR-GRADE POLYESTER POWDER COATING
• WALL-MOUNTED NOTCHED CROSSBAR
• PREPARED FOR TRAY WITH HEATING CABLE
• SLIDING ANTI-VIBRATION PROVIDED
• ANCHOR BOLTS
• ADJUSTABLE ARTICULATED REAR FEET
• ELECTRO-GALVANISED SHEET METAL
• BRACKET FITTED WITH SPIRIT LEVEL
• EXTERIOR-GRADE POLYESTER POWDER COATING
• WALL-MOUNTED NOTCHED CROSSBAR
• PREPARED FOR TRAY WITH HEATING CABLE
• SLIDING ANTI-VIBRATION
• ANCHOR BOLTS
• ADJUSTABLE ARTICULATED REAR FEET
TESTATA FINO
210
A kg!
PORTATA
/ LOAD
CAPACITY
D [mm]
[kg]
400 430 100
400 475 140
400 625 100
3
