- Page 1 User guide | GB | 891073D DVB-S/S2 module - 492020 TRIAX - your ultimate connection TRIAX - your ultimate connection...
-
Page 2: Table Of Contents
Contents Contents Disposal ..........................3 Box content ..........................3 DVB-S module ........................3 Labels ............................. 4 Cover removal........................4 Module installation ........................ 5 Module removal ........................6 Input cable installation ......................6 Status LED’s ........................... 7 Log in ............................8 Input window ......................... -
Page 3: Disposal
Service Tool to configure the module DVB-S module The DVB-S module is one of the input modules that you can install in the in- put section of your TDX headend unit. Below you can see an illustrated description of a DVB-S module. -
Page 4: Labels
Cover removal Before you can install a DVB-S module in the input section you have to re- move the cover that protects the module slot. You do not need tools to remove the covers, just use your fingers. -
Page 5: Module Installation
Basics Module instal- It is optional in which slots you place the individual input modules in the input lation section. For convenience each slot has been given a number, and an over- view of the slot numbers has been placed on the inside of the door of each unit. -
Page 6: Module Removal
Basics Module It is possible to remove an input module from a module slot without using removal any tools, just use your fingers to press the fastener downwards and then pull the module outwards to remove it from the module slot.. Input cable When all the required input modules have been installed you can connect the installation... -
Page 7: Status Led's
Basics Status LED’s There is a status LED on the front of each module. The LED indicates wheth- er the module has locked on to a frequency or needs to be configured. Green - flashing The module has not been configured yet. Green No errors and the module is locked to the frequency. -
Page 8: Log In
TDX Service Tool Log in When you have loaded the TDX Service Tool from the TDX headend system to your laptop/computer the Login window of TDX Service Tool is displayed. When you have pressed the Log in button the System window is displayed. -
Page 9: Input Window
You have to configure the input modules individually. To display the Configuration window, click the Setup button of the DVB-S in- put module you want to configure. -
Page 10: Configuration Of Input Module
“ 0V Off”. Symbol rate Enter the desired symbol rate in this field. If you have connected a Digital Sequence Equipment Control (DiSEqC) switch to the DVB-S module in question you have to select which satellite position you want to use. - Page 11 TDX Service Tool DiSEqC button Click the DiSEqC settings button to open the DiSEqC settings window. As default the DiSEqC switch is disabled. In the DiSEqC settings window click the Enable DiS- EqC version 1.0 radio button to access the DiSEqC switch.
- Page 12 TDX Service Tool To select the required satellite position, click the ar- row to the right of the Satellite position field to open the drop-down list with the satellite positions you can choose from. Select the satellite position you want to use. In case your DiSEqC switch does not support vertical (13 volts) / horizontal (18 volts) polarisation and High Band / Low Band frequencies, click the Use extended...
- Page 13 TDX Service Tool Click the Update button to enter the information into the headend system. As a result a list of available services is displayed in the services list area.
- Page 14 TDX Service Tool To select services you can either select all services in the service list area by clicking the All button at the top of the list or select the services one by one clicking the square to the right of the services you want to make available in your TDX service pool.
-
Page 15: Status Information
Status informa- Status information is placed at the bottom of the Configuration window. The information displayed in the configuration window of a DVB-S module in- tion cludes the status of the module, bit error rate, locked frequency, TS symbol rate and revision of software. -
Page 16: Delete Setup
Delete button of the module in question in the Input window. Click the Delete button of the DVB-S input module you want to remove. A message window is displayed asking you to confirm that you want to re- move the input module. -
Page 17: Save Configuration
TDX Service Tool Save configu- An important button when you change your configuration of the headend system is the Apply button placed in the upper right-hand corner of the TDX ration Service Tool window. Apply Whenever you have made changes in your configuration, “Apply”... -
Page 18: Manufacturer
Manufacturer Manufacturer Dear Customer, Should you require technical assistance in the event that your expert dealer is unable to help you, please contact us at: Triax A/S Bjørnkærvej 3 8783 Hornsyld Denmark Tel.: +45 76 82 22 00 triax@triax.dk www.triax.dk... -
Page 19: Your Notes
Your notes Your notes... - Page 20 891073D 01 - 2012 TRIAX - your ultimate connection TRIAX - your ultimate connection...
