NexSens Technology X2-CB User Manual

Buoy-mounted data logger
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X2-CB Buoy-Mounted Data Logger
User Guide
Last Revision: 26 September 2022
Date Generated: 28 September 2022
Copyright © 2022 NexSens Technology, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X2-CB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NexSens Technology X2-CB

Summary of Contents for NexSens Technology X2-CB

  • Page 1 X2-CB Buoy-Mounted Data Logger User Guide Last Revision: 26 September 2022 Date Generated: 28 September 2022 Copyright © 2022 NexSens Technology, Inc.

  • Page 2: Table Of Contents

    Radio to PC Cellular Set up a 4G Cellular Account for an X2 Data Logger Install a SIM Card into an X2-CB/X2-CBMC Cellular Logger Set an APN on an X2 Data Logger Using CONNECT Iridium Setup Gmail Account to Allow WQData LIVE Access (Iridium)
  • Page 3 Replace a Battery in a CB-Series Data Buoy Battery Removal New Battery Installation Remove an X2/iSIC-CB for repair Replace Desiccant Check an Antenna Connection on an X2-CB Component Overview Verify a Connection is Tight Inspect the RF Connectors for Moisture Access a SD Card...

  • Page 4: System Power

    CB-Series solar towers have a special UW-6 plug with a jumper built in that completes the circuit for the battery to supply power to the X2-CB data logger. The X2-CB will not receive power unless the solar panel is connected to the COM/SOLAR port. Alternatively, a UW-JUMPER plug may be connected to the COM/SOLAR port to complete the connection.

  • Page 5: Basic Requirements

    The below table and diagram show the proper connections for the X2-CB’s UW-6R port. X2-CB UW6 Power Port Pinout...

  • Page 6: Power & Communications Accessories

    The schematic below shows the CB-Series buoy wiring from top to bottom. X2-CB power schematic. Power & Communications Accessories Please visit the accessories tab on the X2-CB product page to purchase power/comms accessories. CB-PW-AC-30W: CB-Series battery float charger, 30W CB-PW-AC-60W: CB-Series battery float charger, 60W...

  • Page 7: Universal Pinout

    UW-6 Universal Pinout The schematics and table below details the 6-pin plug and receptacle universal pinout for all 6-pin NexSens cables excluding the 6-pin AC adapter. Figure 1: NexSens UW-6 receptacle pinout Figure 2: NexSens UW-6 plug pinout Figure 3: X2-CBMC/SDLMC MCIL-6-FS 6-pin power Figure 4: NexSens MCIL-6 plug pinout port...
  • Page 8 Note: For instruments shown below, all signals in the table refer to their 6-pin receptacle port. Plug Pin Receptacle Pin Wire Color G2-Series Signal X2 Signal X2-CB Buoy Solar Signal** Ext. Power Input Main Power Input X2 PCB Power In Yellow —...

  • Page 9: Buzzer Indicator

    Buzzer Indicator X2-SDL & X2-CB data loggers are equipped with an onboard buzzer to provide audible system status feedback to the user. X2-SDL/X2-CB Buzzer Indicator Status Lookup Event Beep Type Status When power is applied Short beep System boot successful...

  • Page 10: Performing A Measurement System Power Budget

    Performing a Measurement System Power Budget Analyzing a measurement system power budget is a useful practice to help ensure that a proposed system design will meet the monitoring objectives and reliably deliver data. To aid with this, NexSens has developed a power budget tool which can quickly estimate the expected power performance of systems using the most common NexSens buoy platforms, data logger configurations, and commonly integrated NexSens and third-party sensors for deployment locations throughout the world.
  • Page 11 Select sensors from drop-down list.
  • Page 12 b. While the pre-populated sensor list is fairly extensive and frequently updated, there may be cases where a sensor is not listed. In such cases, it is possible to enter up to four devices manually by selecting Custom 1/2/3/4 from the drop-down list. Custom sensor entry.
  • Page 13 c. Once selected, proceed to the Custom User Entry tab of the spreadsheet. Navigate to the Sensor Details section and fill in the prompted information either using data from the device manufacturer or measured data during device testing. Custom sensor data entry.
  • Page 14 d. Note that some instrument types have a number of different configurations which may affect power performance. The predefined sensors in the drop-down list are set up based on a typical configuration and information provided by the manufacturer or NexSens bench testing where applicable. These therefore represent a best approximation based on available information.

  • Page 15: Advanced Custom User Entry

    a. Reserve Days refers to how long the system could operate if starting with near 100% battery charge during an extended period without solar charging, or how long a system without any solar charging can be expected to operate. For solar-charged systems, a rule of thumb is to target at least two weeks (14 days) of reserve power.

  • Page 16: Establish Communication

    2. Establish Communication X2 Data Flow The X2 is designed to provide real-time data to users. The diagrams below outline how the data travels from sensor to user. Wi-Fi X2 to WQData LIVE.

  • Page 17: Cellular

    Cellular X2-C to WQData LIVE.

  • Page 18: Iridium

    Iridium X2-I to WQData LIVE.

  • Page 19: Radio To Cellular

    Radio to Cellular X2-RC to WQData LIVE.

  • Page 20: Radio To Pc

    Radio to PC X2-R to WQData LIVE. Notes: Data is posted to WQData LIVE’s secure MySQL database using HTTP POST protocol Data is transmitted in XML format...

  • Page 21: Cellular

    A Static IP and Unrestricted Access are not required. Step 4) Mail SIM card to NexSens Technology for installation and X2 testing It is required that the SIM card for the X2 telemetry be sent to NexSens for pre-shipment installation and testing.

  • Page 22: Install A Sim Card Into An X2-Cb/X2-Cbmc Cellular Logger

    Caution!!!- Be sure to statically ground yourself prior to touching any of the electronics inside the X2 logger! Tools Required 9/16″ socket wrench Phillips head screwdriver Instructions 1. Disconnect the 6-pin solar panel or UW-6 USB cable from the X2-CB/X2-CBMC SOLAR/COM port to remove power from the data logger. X2-CB port configuration. X2-CBMC port configuration.
  • Page 23 2. [For CB-150/250/450 buoys only] Use a 9/16″ socket wrench to remove the (6) bolts holding the buoy’s solar tower to access the data well. Remove solar tower from CB-150/250/450 buoys. 3. Remove the (8) bolts from the X2-CB/X2-CBMC using a 9/16″ socket wrench. X2-CB removal from CB-150/250/450 buoys. X2-CB removal from CB-650/950/1250 buoys.
  • Page 24 Gently lift the enclosure to expose the RTU PCB of the X2. Statically ground yourself prior to touching any of the electronics inside the X2 logger. Remove the X2-CB/X2-CBMC housing screws. 6. Disconnect the 4-pin Molex connector between the enclosure and the X2 data logger. Disconnect the Molex power connector.
  • Page 25 AT&T, Verizon, & NA4G modem schematic. CAT-M modem schematic. 8. For each modem model, orient the modems as shown below and follow the arrows to unlock and open the SIM card tray. Open the AT&T, Verizon, or NA4G modem SIM card Open the CAT-M modem SIM card tray.
  • Page 26 Place the desiccant on the RTU board next to the modem. b. Orient the X2-CB/X2-CBMC enclosure such that the power cable feeding up through the bottom of the base lies flat when closed and is not above the cellular modem.
  • Page 27 If the SIM card ID is not read, open the logger enclosure and re-position the SIM card. 14. Place the re-assembled X2-CB/X2-CBMC back on top of the data well. a. Make sure the primary O-ring is clear of debris and centered in the groove.
  • Page 28 Ensure there are no substantial gaps between the data logger plate and the metal frame of the buoy data well. Bolt down the X2-CB/X2-CBMC. Bolt down the logger in a crisscross pattern. 16. Re-install the solar tower and move the buoy outside. Power on the logger using the solar tower plug and gather multiple hours of readings to ensure the primary power is increasing while the buoy is in direct sunlight.

  • Page 29: Set An Apn On An X2 Data Logger Using Connect

    Set an APN on an X2 Data Logger Using CONNECT Users who have sourced their own mobile data accounts and installed the SIM card may need to configure the associated APN in the X2 logger using CONNECT software. Power Up RTU Connect the X2 logger to a PC and launch the CONNECT software.
  • Page 30 3. Select Turn Power ON to startup the X2’s RTU. a. Note that this process may take up to 30 seconds to complete (15-sec typical). b. The RTU will power down every 10 minutes and will require the RTU power to be turned on again. c.
  • Page 31 Modem Firmware Switch Command (For LE910C1-NF Modems) The LE910C1-NF modem has the ability to switch between Verizon and AT&T modes with a single command. Toggle by entering the following commands in the Direct Command section: 1. Send the AT#CGMM to return the model name of the installed modem. a.
  • Page 32 4. Resend the AT#FWSWITCH? to ensure a successful change. Confirm successful mode change. Verify Current APN Settings 1. To confirm the active APN settings, select and send the AT+CGDCONT? command from the Direct Command list. Response to AT+CGDCONT? command displaying the modem’s currently configured APN profiles. 2.
  • Page 33 Configure New APN Settings 1. In the PDP Context field of the menu, enter the following information: a. CID. Select if the system has an AT&T or International-type modem installed. Select if the system is using a Verizon modem. For model ME90G1-WW, the cid must be confirmed by the service provider. Options range from 0 to 6 for this worldwide modem.
  • Page 34 Test Network Connection After the modem APN settings have been configured, test the modem’s network connection. 1. Send the AT+CMEE=2 Direct AT command to turn on extended error codes. Turn on extended error code responses in the modem. 2. Read the Signal Quality of the system to verify it is within the -51 dBm to -90 dBm range. Verify the signal strength is adequate.
  • Page 35 4. [Optional] After the modem has returned an IP address successfully, test the system’s ability to contact the WQData LIVE Data Center via the AT#PING=wqdatalive.com direct command. Modem successfully pinged WQData LIVE. Change the active SIM card holder on ME90G1-WW The ME90G1-WW worldwide modem contains two SIM card holders.
  • Page 36 3. To switch from SIM holder 0 to SIM holder 1, send: AT#GPIO=8,1,1,1 The SIM holder slot 1 is now the active slot. 4. Enable the active SIM card holder by sending: AT#SIMDET=1 SIM holder 1 is enabled. 5. To save the settings in volatile memory, send: AT&W Check that the active SIM holder slot has changed by reading the SIM ID in the Modem Info area, which should show a new SIM ID.

  • Page 37: Iridium

    Iridium Setup Gmail Account to Allow WQData LIVE Access (Iridium) X2 Iridium satellite data loggers transmit data messages via the Iridium network to an email server. The data messages can then be downloaded from the email server to the WQData LIVE web datacenter. In order to facilitate this process, NexSens hosts a secure Gmail account as a medium to store and upload data to WQData LIVE.
  • Page 38 4. Use the keypad icon at the top right of the screen to open the Google account settings. Click on Account. Google account. 5. Choose Security. Google security tab. 6. Scroll down to Signing in to Google. Change the 2-step verification to on.
  • Page 39 Enable 2-step verification. 7. Select App Passwords and under Select app choose Other (custom name). In the space provided enter wqdatalive. Enter wqdatalive and click Generate. 8. Click Generate. A new app password should appear. Ensure to copy this password to a separate location.
  • Page 40 Generated app password. 9. Insert this app password into the iridium account information on WQData LIVE while configuring the iridium X2 logger. a. Note: Do not include the spaces shown in the password. b. If this iridium system was setup previously, all iridium information entered previously should remain the same, while the password will now be entered as the new generated app password.

  • Page 41: Setup Iridium (Sbd) Data Account

    All Iridium-enabled X2 data loggers must have an active SBD (short-burst data) account in order to send measurement data to WQData LIVE. While NexSens Technology can configure and manage Iridium data service plans, users may prefer to set up their own data services.
  • Page 42 2. Select the desired provider from the list. a. Note that every provider will have different SBD plan capacities and pricing. b. It is advisable to check with multiple providers to find the most competitively priced options for the required data amount. Iridium data service provider listing, based on selected region and country.
  • Page 43 c. Having the data sent to a second mailbox address is recommended. 5. If asked, the following features are not required for the account: a. Ring Alerts b. Geo Data Flag c. MO Ack Flag...

  • Page 44: Setup Iridium Logger Through Connect

    Setup Iridium Logger Through CONNECT Satellite/iridium transmission is more expensive than other traditional forms of communication (e.g., cellular, radio, Wifi). Therefore, it is imperative that the end-user only transmit the most useful diagnostic and sensor parameters. The CONNECT software can set these parameters and their log/transmission interval before the data logger transfers data to the web.
  • Page 45 3. Re-apply 12VDC power and listen for the audible beeps or view the LEDs on the appropriate X2 logger model. X2 Pole Mount LED Indicators X2-CB/X2-SDL Buzzer Pattern Indicator If receiving insufficient signal strength, move the logger into an area devoid of overhead obstructions.
  • Page 46 ADMIN | Settings tab. 3. Click on the Advanced Device Remote Configuration drop-down menu and choose the logger. Enter code ‘nexsens’ when prompted. Advanced device remote configuration drop-down menu. 4. Click the UPDATE button underneath Update Binary Format. A prompt should display showing the command was sent successfully. 5.

  • Page 47: Iridium Transmission Delay

    Iridium Transmission Delay Compared to data loggers utilizing cellular, radio, or Wi-Fi telemetry, Iridium systems have an additional step in the data upload process which may cause a delay in the time it takes from the logger recording a measurement to data being posted on WQData LIVE.
  • Page 48 Iridium X2 data flow.

  • Page 49: Radio

    Radio Set Up a NexSens Radio Network Each XBEE radio module that ships with a NexSens radio X2 has a unique identifier. Both the base and field nodes use this identifier to establish connections throughout the radio network. All field radios in the network must have the identifier information for the base station as a destination for their logged data.
  • Page 50 Add the base radio module. 5. The Digi Base Radio station should appear in the Radio Modules list. Establish Connection with the X2 Base Station...
  • Page 51 1. Power on the NexSens base station and click the Link icon next to the Digi Base Radio module to search for the NexSens base station. Digi base radio search for NexSens base station. 2. Once the NexSens base station is found, select Add selected devices at the bottom of the interface.
  • Page 52 NexSens base station found. 3. Open the NexSens base radio settings by selecting the NexSens base station (Example: X2-RC-DG-01300) under the list of radio modules.
  • Page 53 NexSens X2 base radio station. 4. Scroll down to the Addressing section and copy the SH Serial Number High and SL Serial Number Low. a. This is the identifier that will be written into the settings of each field node. NexSens base radio unique serial number.
  • Page 54 Field devices found. 2. A new list of radio modules will appear below the base station. Select one of the new modules to open the module settings. Read the field radio settings. 3. After the settings are completely loaded, scroll down to the Addressing section and insert the identifier copied previously into the DH Destination Address High and DL Destination Address Low.
  • Page 55 4. Complete this process for all of the field radio nodes. Detect Field Radios 1. Power down the entire network, including the base station. 2. On WQData LIVE, Access the Advanced Device Remote Configuration Tool. 3. Scroll to Radio Settings at the bottom of the interface and choose Yes for the New Value. a.

  • Page 56: Connect Sensors

    X2 Environmental Data Logger X2-SDL X2-CB X2 Environmental Data Logger X2-SDL Submersible Data X2-CB Buoy-Mounted Data Logger Logger Tier 1 Sensors These sensors will be automatically detected by the X2. If multiple sensors are connected to the same logger, they must be addressed uniquely.
  • Page 57 RS-485 or SDI-12 RS-232 RS-485 SDI-12 or RS-232 SDI-12 In-Situ RDO PRO-X Optical MaxiMet GMX600 Weather NexSens T-Node FR/TS210 Sea-Bird Scientific Seametrics CT2X Dissolved Oxygen Station Temperature String HydroCAT CTD Conductivity Loggers SDI-12 SDI-12 SDI-12 SDI-12 RS-485 Seametrics PT12 Level Sequoia Sequoia LISST-AOBS Stevens Hydraprobe II Soil...

  • Page 58: Tier 2 Sensors

    Tier 2 Sensors These sensors require limited setup prior to connection. The scope of this varies by sensor type but typically includes setting up a template, configuring the device or selecting the parameter output. These tasks are often done with a separate PC program provided by the sensor manufacturer. RS 232 RS-485 RS-485...

  • Page 59: Tier 3 Sensors

    Tier 3 Sensors These sensors are not commonly supported by the X2, but can be added through the creation of a user-defined script. The script is written in Lua and utilizes NexSens-created functions to simplify programming. As long as the sensor communicates using SDI-12, RS-485, or RS-232 and can be powered from a 12V supply, it should be compatible with the X2.

  • Page 60: Connect Software

    CONNECT Software User-generated generic scripts are possible to create using the CONNECT software; however, it is recommended to contact NexSens before creating a script. Click the logo below to link to the CONNECT software section of the NexSens Knowledge Base to download and learn about CONNECT.

  • Page 61: Uw Connectors

    UW Connectors UW-8 Sensor Port Pinout NexSens X2 and G2-Series data loggers incorporate UW-8 receptacles for connection of sensor cables with UW-8 plug connectors. The pinout for the UW-8 data logger sensor ports is as follows: NexSens X2/G2 data logger 8-pin (UW-8) sensor port pinout. Pin # SensorBUS Signal Wire Color...

  • Page 62: Plug Pinout

    While this is critical for use on buoys (X2-CB, X2-SDL data loggers) and in other wet environments, users may in some cases choose to install UW Field Wireable Plugs (part number UW-FWP).

  • Page 63: X2 Sensor Detection

    X2 Sensor Detection Traditionally, programming software is required to indicate the communication protocols, sensor addresses, measurement commands, data format, and power requirements of all sensors connected to an environmental data logger. X2 data loggers are designed to simplify the programming and setup process for users by automatically scanning each of its sensor ports for sensors connected to the logger.

  • Page 64: Setup In Wqdata Live

    Setup in WQData LIVE Creating a Project on WQData LIVE Data loggers and measurement data are organized into Projects on WQData LIVE. Projects may contain one or more Sites for further organization, and each Site may contain one or more data loggers. To create a Project: 1.
  • Page 65 4. Fill out the fields in the corresponding menu to title the project and click CREATE PROJECT. Create Project interface. 5. The main V3 project dashboard will appear. Create and name a site within the new project as desired by going to Admin | Settings at the top and then to the Project/Site tab and selecting New Site.

  • Page 66: Adding A Data Logger To A Project On Wqdata Live

    Adding a Data Logger to a Project on WQData LIVE During first-time configuration, data loggers are added to WQData LIVE projects using a Claim Code supplied with each data logger. To assign a data logger using a Claim Code: 1. Log in to WQData LIVE and find the username in the top right hand corner of the page. Mouse over the username to reveal a drop down menu and click PROJECTS.
  • Page 67 3. Once a project is selected or created, click on the ADMIN tab and then Settings located at the top of the dashboard. Navigate to ADMIN | Settings at the top of the project dashboard. 4. Click on the gray bar that says Project/Site to open a drop-down menu. Choose Sites to open a second drop-down menu.
  • Page 68 6. Add a new logger by entering the Claim Code in the field near the bottom of the Sites menu. Then click Add Device. a. The Claim Code can be found on the serial label attached to the data logger’s Quick Start Guide. Data logger serial label.

  • Page 69: Changing Sensor Logging Intervals

    Changing Sensor Logging Intervals Independent Log Intervals can be configured for each sensor connected to an X2 or G2-Series data logger through the Device Remote Device Configuration tool. To update sensor log intervals in WQData LIVE: 1. Navigate to the Device Remote Configuration tool within the administrator settings.

  • Page 70: Changing Data Logger Transmission Interval

    Changing Data Logger Transmission Interval The Transmit Interval in the Device Remote Configuration Tool determines how often a data logger will power up its telemetry to contact the WQData LIVE Web Datacenter. On each transmission, the data logger will: Upload all newly logged data. Process all settings changes listed in the Command Queue.

  • Page 71: Run Remote Sensor Detection

    Run Remote Sensor Detection A new sensor detection can be administered on an X2 data logger from WQData LIVE. Before proceeding, reference the X2 Sensor Detection overview and the Auto-Detection Troubleshooting guide. The detection process will permanently alter the X2 data logger programming and should only be attempted when a new sensor is being added to the system or changes are being made to existing sensor configurations.
  • Page 72 4. Click SAVE and complete the confirmation prompt to submit the command for processing. a. Prior to submitting the sensor detection command, double-check that all considerations laid out in the Sensor Detection Troubleshooting guide have been met. Sensor detection confirmation prompt. 5.

  • Page 73: X2 Logger Diagnostic Readings

    To avoid data logging interruptions, it is recommended an X2 be sent to NexSens Technology to replace the RTC battery when it falls to 2.7V or below. 3. Primary Power – Each X2 is capable of utilizing two independent power inputs for redundancy. Power provided in the following instances will be registered as Primary Power: a.
  • Page 74 4. Secondary Power – Any power supplied to an X2 through the secondary pins on a UW-6 plug connector will be registered as Secondary Power. Secondary power is typically only utilized by X2-SDL systems running on internal D-cell batteries. All other systems will return ~0V (as shown), indicating that no secondary power input is present.
  • Page 75 Acceptable values will range from a slight negative percentage (effectively zero) up to ~50%. If humidity is reported to be greater than 50%, the desiccant bag inside the X2-CB should be replaced and the enclosure seal inspected. High humidity can contribute to telemetry problems and, in more extreme cases, damage the logger circuitry.
  • Page 76 As with cell signal strength, the cell status parameter applies to all telemetry types including cellular, radio, Iridium satellite, and Wi-Fi. Values of zero indicate that no errors were observed. If status errors appear frequently and data transmissions are affected, contact NexSens Technology and supply the status error code for troubleshooting.

  • Page 77: Troubleshooting And Maintenance

    Old SLA-type batteries, or those that have fallen to a voltage that is too low, may be unable to output the system current required for detection. Once all of the above have been verified, re-run sensor detection. Contact NexSens Technology for further assistance if the sensor still is not identified.

  • Page 78: Verify Battery Voltage Of A Cb-Series Buoy

    Measure the voltage between pins 3 (V+) and 4 (GND) on the SOLAR port. Healthy SLA battery voltage is 12.0- 14.9V. UW-6 SOLAR port receptacle pinout for X2-CB data loggers and CB- PTL pass-through lids. SLA batteries which have fallen below ~10V...

  • Page 79: Replace A Battery In A Cb-Series Data Buoy

    New desiccant (recommended) Battery Removal 1. Disconnect the 6-pin solar panel cable from the X2-CB’s SOLAR port to remove power to the data logger. Cover the plug and receptacle to prevent moisture and debris from the port pins and O-rings.
  • Page 80 4. Lift the buoy plate off of the data well. Disconnect the 6-pin UW-plug running between the solar regulator and the X2-CB and protect the connectors. This will expose the data well where the battery and solar regulator are installed.

  • Page 81: New Battery Installation

    5. Remove the foam coverings to expose the battery harness. Top-view of the solar regulator and battery assembly with protective foam removed. 6. Remove the two nut, lock washer and flat washer pairs securing the regulator bracket to the battery mount posts (threaded rod).
  • Page 82 2. [Only for systems with 2 or more batteries] a. Discard any pre-installed hardware on the new battery terminals. Using the original battery terminal bolts and a 10mm socket wrench, tighten the ring terminal cables to the new battery. b. Make sure that the cables point toward the corners of the battery. Always insulate the detached cable leads to prevent short-circuiting the battery during installation.
  • Page 83 1. Reconnect the solar plug to the receptacle at the bottom of the X2-CB. 2. Align the X2-CB or pass-through plate with the mounting holes on the buoy and verify that the large O-ring is in good condition, clear of debris and lightly greased.
  • Page 84 UW-6 SOLAR port receptacle pinout for X2-CB data loggers and CB-PTL pass-through lids. 6. Connect the 6-pin solar panel plug to the buoy’s SOLAR port to reapply power to the data logger.

  • Page 85: Remove An X2/Isic-Cb For Repair

    Remove an X2/iSIC-CB for repair Should an X2-CB or iSIC-CB need to be sent in for evaluation or repair, please reference the following steps for removal: X2-CB data logger. Tools Required 9/16″ Socket Wrench Instructions 1. Disconnect the 6-pin solar panel cable from the X2/iSIC-CB SOLAR port to remove power from the data logger.
  • Page 86 3. Remove the (8) bolts with lock washers from the X2/iSIC-CB or data well pass-through plate using a 9/16″ socket wrench, loosening them in a cross pattern. Loosen X2/iSIC-CB bolts in a cross-pattern. 4. Lift the X2/iSIC-CB plate off of the data well. Disconnect the 6-pin UW-plug running between the solar regulator and the X2/iSIC-CB.
  • Page 87 b. Re-install the (8) bolts with lock washers from the X2/iSIC-CB or data well pass-through plate using a 9/16″ socket wrench, tightening them evenly in a cross pattern to ensure an even O-ring seal. Tighten bolts in a cross pattern to ensure even load distribution on the O-ring seal.

  • Page 88: Replace Desiccant

    A71 desiccant kit. Desiccant Replacement Process 1. Disconnect the 6-pin solar panel or UW-6 USB cable from the X2-CB SOLAR/COM port to remove power from the data logger. 2. Remove the buoy solar tower to gain access to the data well [CB-150/250/450 buoys only].
  • Page 89 3. Remove the (8) bolts with lock washers from the X2-CB using a 9/16″ socket wrench, loosening them in a cross pattern. Loosen X2-CB plate. 4. Pick up the plate to reveal the 6-pin plug connecting the battery harness in the data well to the bottom cable of the X2 logger.
  • Page 90 7. Remove the spent bag of desiccant and place a fresh bag in its place. Replace desiccant bag. 8. Carefully set the enclosure base back on to the logger plate, aligning the threaded inserts of the plate with the screw holes in the base. a.
  • Page 91 Replace the housing screws, tightening evenly in a cross- pattern. 10. Set the re-assembled X2-CB back on top of the data well, placing desiccant in the well first. Install desiccant and reattach data well plate. a. It is recommended at this time, particularly if the X2 has reported high moisture readings, to replace the bag of desiccant inside the data well also.

  • Page 92: Check An Antenna Connection On An X2-Cb

    Check an Antenna Connection on an X2-CB The telemetry antenna for cellular or radio X2-CB loggers threads onto a dedicated RF connector port on top of the CB-plate. It may be necessary to inspect the condition of the RF connection if signal strength or connection reliability issues are encountered in the field.

  • Page 93: Inspect The Rf Connectors For Moisture

    Tighten antenna bushing to plate port. Inspect the RF Connectors for Moisture 1. Grab the bushing of the antenna and turn the assembly counterclockwise to remove it.
  • Page 94 Rotate the antenna bushing counterclockwise to remove the antenna.
  • Page 95 Antenna and bushing removed from CB-plate. 2. Un-thread the antenna from the bushing and inspect the O-ring at the antenna base. a. Verify it is properly aligned in the groove and there are no signs of tears or other damage.
  • Page 96 Verify Antenna O-ring is intact and seated properly. 3. Inspect the RF connector of the antenna and verify there are no signs of moisture, corrosion or coaxial contact damage. a. If moisture is visible, use canned air to dry it out.
  • Page 97 Verify the antenna’s RF connector is free from moisture, corrosion, or coaxial socket damage. 4. Inspect the RF port on the CB-plate for signs of moisture intrusion or damage in a like-manner. a. Also check that the small exterior O-ring near the top of the port is seated in its groove properly.
  • Page 98 Verify the CB-plate RF port is dry and clean. 5. Rethread the bushing back on the antenna, double-checking the antenna O-ring stays seated. Verify the connection is hand-tight. Thread the bushing back onto the antenna. Turn the bushing-to-antenna connection until hand-tight. 6.
  • Page 99 Push down on the antenna assembly and turn the bushing clockwise to securely re-install the antenna.

  • Page 100: Access A Sd Card

    Remove the X2-CB Housing X2-CB 1. Disconnect the 6-pin solar panel or UW-6 USB cable from the X2-CB SOLAR/COM port to remove power from the data logger. 2. [For CB-150, 450 buoys only] Remove the (6) 3/8-16×3/4 bolts and 3/8 lock washers holding the solar tower to the buoy using a 9/16 socket wrench.
  • Page 101 Unbolt X2-CB plate from the buoy. 4. Lift up the plate to disconnect the 6-pin plug connecting the battery harness in the data well to the bottom cable of the X2 logger. Disconnect UW6 Battery Harness cable. 5. Invert the logger to access and remove the (8) Phillips-head screws holding the X2 housing to the CB-plate.
  • Page 102 Remove X2-CB Housing Screws. Caution!!!- Be sure to statically ground yourself prior to touching any of the electronics inside the X2 logger 6. Gently lift the housing off of the plate to expose the data logger electronics.

  • Page 103: Access Rtu Sd Card

    Gently lift the housing cover off of the CB-plate. 7. Disconnect the molex power cable connecting the electronics to the battery harness. Disconnect the battery harness cable from the X2. Access RTU SD Card...
  • Page 104 8. Locate the Buoy P2-B JST port on the X2-CB expansion PCB. The SD card slot for the RTU is located directly above it on the underside of the topmost-facing PCB. RTU SD Card Slot location. 9. Press the SD card inward towards its mount to unlock it. After successful disengagement, remove the card...

  • Page 105: Access Main Sd Card

    RTU SD Card removed. Access Main SD Card 10. Locate the side of the circuit board that has (5) white JST cable connectors visible.
  • Page 106 Locate the side of the X2 that has (5) white JST connectors in view. 11. Gently disconnect the UW8-P2 cable from the X2 by depressing the JST connector clip and pulling back on the connector.
  • Page 107 Remove the UW8 P2 cable from the X2 for easier access to the Main SD card. 12. Use tweezers to press inwards on the SD card to unlock it.
  • Page 108 Main SD Card Location. 13. Remove the Main SD Card.

  • Page 109: Reassemble The X2-Cb Housing

    Main SD Card Removed. Reassemble the X2-CB Housing 14. Reconnect the molex power connector such that the latch and hook (as well as the primary wire colors) align.
  • Page 110 Molex power cable reconnection alignment. 15. Align the enclosure with the threaded inserts of the CB plate. Ensure the large exterior O-ring is securely seated in the enclosure channel and will make proper contact with the CB plate.
  • Page 111 Align the enclosure with the threaded inserts of the CB-plate. 16. Orient the X2-CB plate such that the power cable feeding up through the bottom of the base lies flat when closed.
  • Page 112 Ensure the power cable is not pinched. 17. Align the CB plate threads with the top plate and thread the (8) 8-32 x 1/2 screws in halfway, before tightening in a cross pattern with a Phillips Screwdriver.
  • Page 113 Evenly tighten the enclosure back to the CB-plate. 18. Place the re-assembled X2-CB back on top of the data well. a. Make sure the primary data well O-ring is clear of debris and centered in the groove. Verify the data well O-ring is present and clear of debris.

  • Page 114: X2 Storage Requirements

    X2 Storage Requirements The following practices should be carried out when storing an X2 data logger for an extended period of time: Disconnect the 6-pin SP-series solar power pack UW6-PW AC power adapter cable from the center port at the bottom of the X2. This removes power from the data logger and all connected sensors.
