    Introduction The Lippert 3000 Series Patio Rail Kit has been designed for easy installation and use. The Lippert 3000 Series Patio Rail Kit is pre-installed onto the ramp door, it can be used in a 90 degree angle as a patio, or fold the front of the patio rail kit to the sides and lower the ramp door to the ground to load toy vehicles into the trailer.

  • Page 3: Safety

    Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system.
  • Page 4 NOTE: Ensure door cables are attached before starting the following steps. To open the ramp door, first verify the compression latch is unlocked (Fig. 1A). Raise the handle of the compression latch (Fig. 1B) so that it is parallel with the ground. Twist the compression latch handle 90°...
  • Page 5 NOTE: On alternate versions of the Lippert 3000 series patio rail kit, there will NOT be two front and rear bungees. An alternate version of the Lippert 3000 Series will have a J-bolt (Fig. 3A) located at both side patio railing front bases (Fig. 4A). Pull the yellow lanyard (Fig. 3B) and turn the J-bolt a quarter turn (Fig.
  • Page 6 Ramp Position NOTE: On alternate versions of the Lippert 3000 series patio rail kit, there will NOT be two front and rear bungees. An alternate version of the Lippert 3000 Series will have a J-bolt (Fig. 3A) located at both side patio railing front bases (Fig.
  • Page 7 Raise a side patio panel assembly up into a 90 degree position (Fig. 7A). Fig. 7 If applicable, locate the bungee on either side of the patio railing (Figs. 6B, 6C or 8A), on the outside rear of the patio railing closest to the door jamb. 10.
  • Page 8 12. The Lippert 3000 Series patio rail kit and ramp door are now open, fully extended in the ramp position and ready to load/unload. (Fig. 9). Fig. 9 Do NOT attempt to stow the ramp door from ramp position without first completing all steps to put the ramp door back into the closed patio position ( Fig.

  • Page 9: Ramp Position To Stowed Position

    Ramp Position to Stowed Position If the Lippert 3000 series ramp door is in the ramp position and the ramp door needs to be stowed, use the following procedure. • Do not operate the ramp door on uneven ground. • Always lower ramp door onto level ground.
  • Page 10 If applicable, release the rear bungee (Fig. 12A) attached to the footman loop (Fig. 12B) on the door jamb (Fig. 12C) for both sides of the patio rail kit and gently lower the patio railings to the surface of the door (Fig.
  • Page 11 A method of support, or the assistance of another person, to support the ramp door when removing or attaching the door cables to extend the door to the ramp position is recommended. Raise the ramp door and attach the door cables (Fig. 14A) to the door cable brackets (Fig. 14B) with the retainer pins (Fig.

  • Page 12: Ramp Position To Extended Patio Position

    Ramp Position to Extended Patio Position If the Lippert 3000 series ramp door is in the ramp position and now the open patio position is desired, use the following procedure. • Do not operate the ramp door on uneven ground.
  • Page 13 If applicable, release the rear bungee (Fig. 18A) attached to the footman loop (Fig. 18B) on the door jamb (Fig. 18C) for both sides of the patio rail kit and gently lower the patio railings to the surface of the door (Fig.
  • Page 14 Release the two snaps holding the front panel and gate to the driver's side railing (Fig. 20A) and one snap on the curbside railing (Fig. 20B). NOTE: An alternate version of the patio rail kit has a "no-gate" option, with only one snap on each side holding the two front panels to the side panels.
  • Page 15 (Fig. 24B) by pushing the compression latch lever (Fig. 24C) towards the trailer, slide the leg into place and release the lever. NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 25A). Turn the lever (Fig. 25B) towards the trailer, and insert and secure the curbside patio rail leg.
  • Page 16 (Fig. 29C) by pushing the compression latch lever (Fig. 29A) towards the trailer, slide the leg into place and release the lever. NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 30A). Turn the lever (Fig. 30B) towards the trailer, insert and secure the curbside patio rail leg.
  • Page 17 17. The Lippert 3000 Series ramp door and patio rail kit are now open and fully deployed, with a gate (Fig. 35) or without a gate (Fig. 36). Fig. 35 Fig. 36 Page 17 Rev: 08.18.21 CCD-0004099...

  • Page 18: Stowed Position To Extended Patio Position

    Stowed Position to Extended Patio Position If the Lippert 3000 series ramp door is in the stowed position and the extended patio position is desired, use the following procedure. • Do not operate the ramp door on uneven ground. • Always lower ramp door onto level ground.
  • Page 19 Fig. 38 NOTE: On alternate versions of the Lippert 3000 series patio rail kit, there will NOT be two front and rear bungees. An alternate version of the Lippert 3000 Series will have a J-bolt (Fig. 39A) located at both side patio railing front bases (Fig.
  • Page 20 Release the two snaps holding the front panel and gate to the driver's side railing (Fig. 41A) and one snap on the curbside railing (Fig. 41B). NOTE: An alternate version of the patio rail kit has a "no-gate" option which there will only be one snap on each side holding the two front panels to the side panels.
  • Page 21 (Fig. 45B) by pushing the compression latch lever (Fig. 45C) towards the trailer, slide the leg into place and release the lever. NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 46A). Turn the lever (Fig. 46B) towards the trailer, insert and secure the curbside patio rail leg.
  • Page 22 (Fig. 50C) by pushing the compression latch lever (Fig. 50A) towards the trailer, slide the leg into place and release the lever. NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 51A). Turn the lever (Fig. 51B) towards the trailer, and insert and secure the curbside patio rail leg.
  • Page 23 20. The Lippert 3000 Series ramp door and patio rail kit are now open and fully deployed, with a gate (Fig. 56) or with out a gate (Fig. 57). Fig. 56 Fig. 57 Page 23 Rev: 08.18.21 CCD-0004099...

  • Page 24: Extended Patio Position To Ramp Position

    Extended Patio Position to Ramp Position If the Lippert 3000 series ramp door is in the extended patio position and the ramp door is desired, use the following procedure. • Do not operate the ramp door on uneven ground. • Always lower ramp door onto level ground.
  • Page 25 (Fig. 62C) by pushing the compression latch lever (Fig. 62A) towards the trailer, slide the leg out of the keeper and release the lever. NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 63A). Turn the lever (Fig. 63B) towards the trailer, and release the driver's side patio rail leg.
  • Page 26 If applicable, disengage the J-bolt (Fig. 66) on the driver's side of the patio railing. NOTE: On alternate versions of the Lippert 3000 Series it will have a J-bolt (Fig. 66A) located at both side patio railing front bases (Fig. 67A). Pull the yellow lanyard (Fig. 66B) and turn the J-bolt a quarter turn (Fig.
  • Page 27 (Fig. 71B) by pushing the compression latch lever (Fig. 71C) towards the trailer, slide the leg out of the keeper and release the lever. NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 72A). Turn the lever (Fig. 72B) towards the trailer, and release the curbside patio rail leg.
  • Page 28 14. Lower the curbside patio railing assembly (Fig. 75A) approximately 45 degrees down towards the center of the ramp door. 15. Fold the front panel (Fig. 75B) over the top of the side patio railing (Fig. 76A) and let the patio railing return to the 90 degree position (Fig.
  • Page 29 Fig. 78 19. Gently lower the ramp door to the ground. The Lippert 3000 Series patio rail kit and ramp door are now open, fully extended in the ramp position (Fig. 79). Fig. 79 Page 29 Rev: 08.18.21...

  • Page 30: Extended Patio Position To Stowed Position

    Extended Patio Position to Stowed Position If the Lippert 30000 series ramp door is in the extended patio position and the ramp door needs to be stowed, use the following procedure. • Do not operate the ramp door on uneven ground.
  • Page 31 Fig. 85 NOTE: On alternate versions of the Lippert 3000 series patio rail kit, there will NOT be two rear and front bungees. An alternate version of the Lippert 3000 Series will have a J-bolt (Fig. 86A) located at both side patio railing front bases (Fig.
  • Page 32 NOTE: Alternate versions of the Lippert 3000 series will have a spring plunger (Fig. 92A). Turn the lever (Fig. 92B) towards the trailer, and release the curbside patio rail leg.
  • Page 33 If applicable, disengage the J-bolt(Fig. 86) on the curbside of the patio railing. For the curbside patio railing (Fig. 93A), swing the front panel (Fig. 93B) out in-line with the side patio railing (Fig. 93A). 10. Lower the side and front patio panels (Fig. 94B) down towards the surface of the ramp door (Fig. 94A) and flip the front patio panel (Fig.
  • Page 34 12. Attach the bungee (Fig. 97A) onto the front driver's side and curbside brackets (Fig. 97B), holding the patio railings to the ramp door. Fig. 97 13. Make sure the ramp door and support wire cables on both sides of the door are clear of any obstructions. 14.

  • Page 35: Maintenance

    Maintenance In order to clean the ramp door, use only an alcohol-based cleaner. Other chemicals and cleaners may result in the degradation of the seal and cause delamination to the door. Notes Page 35 Rev: 08.18.21 CCD-0004099...
  • Page 36 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided.  Any unauthorized use shall void any applicable warranty. ...
