- Page 1 Lippert 3500 Series Patio Rail Kit OWNER'S MANUAL...
- Page 2 Introduction The Lippert 3500 Series Patio Rail Kit has been designed for easy installation and use. It creates a safe barrier around the perimeter of the ramp door while in the patio position, opens to allow the door to be utilized as a ramp, and easily collapses and is stowed in the door cavity during travel while the door is closed.
- Page 3 • Failure to heed WARNING may result in serious bodily injury or component and/or property damage. Note: Although the product is water resistant, Lippert recommends storing the door in the closed position during periods of rain to reduce the risk of water intrusion, which may result in delamination.
- Page 4 operation Opening the Rail Kit to the Patio Position Unfasten the snap strap securing the gate side and off-gate side rail assemblies together. With the ramp door open and secured in the patio position, swing the gate side rail assembly open (Fig.
- Page 5 Swing the off-gate side rail assembly open (Fig. 6) and insert the compression foot into the keeper base. Lock the rail into place by turning the compression latch on the foot clockwise. Fig. 6 Release the rail panels by unsnapping the locking straps on each rail assembly. Open the secondary side panel (Fig.
- Page 6 Closing the Rail Kit to the Stowed Position Lift the gate latch (Fig. 9A). Be sure to open the latch past 90° so that the rubber sleeves catch on the metal of the gate assembly (Fig. 9B) and secure the latch snugly in the open position. Jiggle or attempt to displace the latch to ensure it is tight an will not dislodge.
- Page 7 Close the off-gate side front panel (Fig. 13A) and secondary side panel (Fig. 13B) by moving them inwards to the main side panel (Fig. 13C). Note: Always lift the rail assemblies/sections upwards while moving or positioning any part of them to assist the caster springs and avoid scratching the ramp door surface with the compression latch feet.
- Page 8 11. Release the gate side compression latch on the foot of the rail by turning it counterclockwise to the open position (Fig. 16A). 12. Close the gate side rail assembly by swinging it 90° into the door cavity, covering the off-gate side assembly (Fig.
- Page 9 Opening the Rails for Ramp Door Operation Position the gate side rail assembly (Fig. 18A) and the off-gate side rail assembly (Fig. 18B) so that they are in the open position as depicted in Figure 18. The front rail sections should be closed and secured against the main rail sections by straps at the top of each section.
- Page 10 Disconnect all applicable cables, release and remove any installed steps. Open the door to the ramp position according the instructions for the specific door installed on the unit (Fig. 21). Fig. 21 Secure the off-gate side rail assembly (Fig. 22A) in the open position by stretching the bungee cord (Fig.
- Page 11 Notes Page 11 Rev: 06.07.24 CCD-0006220...
- Page 12 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
