• When the battery is low, The LEDs (17) and (18) will blink together
rapidly.
！
Note:
Users need to charge the battery immediately if LEDs (17) and
(18) flash together.
Lines Switching
• Horizontal Line: After power on, short press
the horizontal line.
• Vertical Line: After power on, short press
Note:
！
• The line mode switches every time you press the V/H button in
self-leveling mode only.
• Lines switching function is disabled in slope function mode.

Self-leveling Mode

Turn on the laser unit, the automatic sensor is now activated and
the laser unit will level automatically.
• The indicator LED (17) flashes rapidly during the leveling adjustment;
• Once the leveling adjustment is completed, the indicator LED (17) will
be on constantly .
• Maximum accuracy is attained when self-leveling is completed.
to switch vertical lines.
-9-
to switch ON/OFF
