Linksys WMP300N Quick Installation

Package Contents
• Wireless-N PCI Adapter
• External Antenna
• Setup Wizard CD-ROM
• User Guide on CD-ROM
• Quick Installation
24 .
GHz
Wireless-N
PCI Adapter
Wireless Quick Installation
Model No. WMP300N
Model No.
1 Begin Installation
IMPORTANT: Do not install the Adapter in your PC until
you are instructed to do so in Step 2; otherwise, the
Adapter will not install correctly.
The Adapter is installed and set up
using the Setup Wizard that
comes on the enclosed CD.
A
Insert the Setup Wizard CD-
ROM into your CD-ROM
drive. The Setup Wizard
should run automatically,
and the Welcome screen
should appear.
B
To install the Adapter, click
Click Here to Start on the
Welcome screen.
B
C
After reading the License
Agreement, click Next to
continue the installation.
D
Windows will begin copying
the files onto your PC.
E
The Setup Wizard will now
prompt you to install the
Adapter into your PC.
C
Proceed to Step 2.
2
Install the Adapter
Go to the section for your
Windows operating system.
Windows XP
A
If the Software Installation
screen appears, click
Continue Anyway.
B
Click Next and power off
your PC. After installing the
Adapter and restarting your
PC, the Setup Wizard will
continue.
C
Open your PC case and
A
locate an available PCI slot
on the motherboard.
D
Slide the Adapter into the
PCI slot. Make sure that all of
its pins are touching the
slot's contacts. Secure its
fastening tab to your PC's
chassis with a mounting
screw. Then close your PC.
E
B
Connect the antenna
stand's cables to the PCI
card of the Adapter. Plug
the cable with the blue
connector into the blue
CENTER ANT port. Then
attach the remaining
cables to the other ports.
F
Power on your desktop PC.
G
If you have Windows XP with
Service Pack 2, the
Welcome to the Found
New Hardware Wizard
screen will appear. Click
Next.
G
H
On the Found New
Hardware Wizard screen,
make sure that Install the
software automatically
(Recommended) is
selected, then click Next.
I H
On the Hardware
Installation screen, click
Continue Anyway.
I
J
When the wizard has
finished installing the
software, click Finish.
Proceed to Step 3.
J
