- Page 1 Instant Wireless Series Wireless PCI Card Use this guide to install: WMP11 ver. 2.7 User Guide...
- Page 2 COPYRIGHT & TRADEMARKS Copyright © 2002 Linksys, All Rights Reserved. Instant Wireless is a trademark of Linksys. Linksys is a registered trademark of Linksys. Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation. All other trademarks and brand names are the property of their respective proprietors.
-
Page 3: Table Of Contents
• Linksys Group™ déclare que la carte PC Instant Wireless IEEE 802.11 est conforme aux conditions essentielles et aux dispositions relatives à la directive 1999/5/EC, la directive 89/336/EEC, et à la directive 73/23/EEC. -
Page 4: Chapter 1: Introduction
Chapter 7: Using the WLAN Monitor for Windows 98, Me, and 2000 Overview Starting the WLAN Monitor Link Information Site Survey Profiles Creating a New Profile Using the Expert Mode Appendix A: Troubleshooting Common Problems and Solutions Frequently Asked Questions Appendix B: Glossary Appendix C: Specifications Environmental... -
Page 5: Package Contents
Package Contents Figure 1-1 • One Wireless PCI Card • One Setup Wizard CD-ROM with User Guide • One Quick Installation guide • One Registration Card System Requirements One PC with the following: • 200MHz or Higher CPU • 64MB RAM •... -
Page 6: Chapter 3: Getting To Know The Wireless Pci Card
If the wireless network is relatively small and needs to share resources only with the other computers on the wireless network, then the ad-hoc mode can be used. (See Figure 2-2.) Ad-hoc mode allows computers equipped with wire- less transmitters and receivers to communicate directly with each other, elimi- nating the need for an access point. -
Page 7: Chapter 4: Software Installation And Configuration For Windows 98, Me, And 2000
• User Guide - Click the User Guide button to open the PDF file of this User Guide. • LINKSYS Web - Click the LINKSYS Web button to access the Linksys website through an active Internet connection. • Exit - Click the Exit button to exit the Setup Wizard. - Page 8 In the SSID field, enter the SSID of your wireless network. The SSID must be identical for all devices in the network. The default setting is linksys (all lowercase). Click the Next button. Figure 4-3...
-
Page 9: Chapter 5: Hardware Installation
5. After the files have been successfully copied, the screen in Figure 4-6 will appear. Click the Finish button. Figure 4-6 Proceed to “Chapter 5: Hardware Installation.” Instant Wireless Series Wireless PCI Card ™ Chapter 5: Hardware Installation 1. Remove any CDs or disks from their drives, and turn off your desktop PC. 2. -
Page 10: Hardware Detection For Windows 98, Me, And 2000
5. Attach the external antenna to the Card’s antenna port. Figure 5-2 Important: Make sure the antenna is positioned straight up into the air, at a 90º angle from the Card (see Figure 5-2). This will ensure optimum wireless operating range and performance. 6. -
Page 11: Windows Xp Wireless Zero Configuration
2. After Windows has finished installing the driver, click the Finish button. Figure 6-2 You have now completed the driver installation for the Wireless PCI Card. To configure the Card, proceed to the next sec- tion, “Windows XP Wireless Zero Configuration.” Instant Wireless ™... -
Page 12: Chapter 7: Using The Wlan Monitor For Windows 98, Me, And 2000
For more information about WEP, refer to your access point’s user guide, or visit www.linksys.com. For more information about wireless networking on a Windows XP computer, click Start and then Help and Support. Enter the keyword wireless in the field provided, and press the Enter key. -
Page 13: Link Information
Link Information The Link Information screen shows you the settings of your current connection. Figure 7-3 TCP/IP Setting IP Address - The IP Address of the Card. Subnet Mask - The Subnet Mask of the Card. Default Gateway - The Default Gateway address of the Card. DNS - The DNS address of the Card. -
Page 14: Profiles
Connect - To connect to one of the networks on the list, select the wireless net- work, and click the Connect button to connect. If the wireless network has WEP encryption enabled, you will see the screen shown in Figure 7-5. Figure 7-5 In the WEP drop-down box, select the type of WEP encryption used by the wireless network: 64-bit or 128-bit WEP. - Page 15 Connect - To connect to a wireless network using a specific profile, select the profile, and click the Connect button. If the wireless network has WEP encryp- tion enabled, you will see the screen shown in Figure 7-7. Figure 7-7 In the WEP drop-down box, select the type of WEP encryption used by the wireless network: 64-bit or 128-bit WEP.
-
Page 16: Creating A New Profile
Creating a New Profile There are two ways to create a new profile. You will be asked if you want to use the Profile Wizard or Expert Mode. If you want to be guided through all the steps, choose the Profile Wizard, and proceed to step 1. If you are an advanced user knowledgeable about wireless networking, choose Expert Mode, and pro- ceed to the next section, “Using Expert Mode.”... - Page 17 5. The Basic Settings screen will now appear. Enter your wireless network’s SSID. Select the Transfer Rate to determine the speed(s) at which the Card will send and receive data. Select the Channel at which the network broad- casts its wireless signal (available only for Ad-Hoc Mode). Then click the Next button to continue or the Back button to return to the previous screen.
- Page 18 Address in this format: xxx.xxx.xxx.xxx (the x’s represent your actual IP Address). Subnet Mask - The Adapter’s Subnet Mask must be the same as your wired network’s Subnet Mask. Enter the Subnet Mask in this format: xxx.xxx.xxx.xxx (the x’s represent your actual Subnet Mask).
-
Page 19: Using The Expert Mode
9. The Confirm New Settings screen will appear next. The former and new set- tings are shown. To save the new settings, click the Yes button. To cancel the settings and return to the Profiles screen, click the No button. To edit the new settings, click the Back button. - Page 20 Transfer Rate - Select the Transfer Rate for your wireless connection. Choose from 1Mbps, 2Mbps, 1 or 2Mbps, 5.5Mbps, 11Mbps, or Auto. When you select Auto, the Adapter dynamically shifts to the fastest data transfer rate possible. Channel - Select the Channel at which the network broadcasts its wireless signal (available only for Ad-Hoc Mode).
- Page 21 WEP encryption, choose Disabled. To use WEP encryption, select 64-bit or 128-bit WEP from the drop-down menu. The Card’s WEP encryption is unique to Linksys and may conflict with other manufacturers’ WEP encryption. If you select 64-bit or 128-bit WEP, you have two ways to generate WEP key(s), entering a passphrase or entering manual WEP key(s).
-
Page 22: Appendix A: Troubleshooting
This chapter provides solutions to problems that may occur during the installa- tion and operation of the Wireless PCI Card. Read the descriptions below to solve your problems. If you can’t find an answer here, check the Linksys web- site at www.linksys.com. - Page 23 802.11b standard states a maximum data transfer rate of 11Mbps and an oper- ating frequency of 2.4GHz. What IEEE 802.11b features are supported? The product supports the following IEEE 802.11b functions: • CSMA/CA plus Acknowledge protocol • Multi-Channel Roaming • Automatic Rate Selection •...
-
Page 24: Appendix B: Glossary
Wi-Fi networks. Ad-hoc Network - An ad-hoc network is a group of computers, each with a wireless adapter, connected as an independent 802.11 wireless LAN. Ad-hoc wireless computers operate on a peer-to-peer basis, communicating directly with each other without the use of an access point. Ad-hoc mode is also referred to as an Independent Basic Service Set (IBSS) or as peer-to-peer mode, and is useful at a departmental scale or SOHO operation. - Page 25 IEEE Computer Society. Infrastructure Network - An infrastructure network is a group of computers or other devices, each with a wireless adapter, connected as an 802.11 wireless Instant Wireless Series Wireless PCI Card ™...
- Page 26 Roaming - In an infrastructure mode wireless network, this refers to the abili- ty to move out of one access point's range and into another and transparently reassociate and reauthenticate to the new access point. This reassociation and reauthentication should occur without user intervention and ideally without interruption to network connectivity.
-
Page 27: Appendix C: Specifications
Appendix C: Specifications Model Number WMP11 ver. 2.7 Standards IEEE 802.11b Channels 11 Channels (USA) 13 Channels (Europe) 14 Channels (Japan) Port One Antenna Transmit 15 dBm Receive Sensitivity -82 dBm Modulation BPSK, QPSK, CCK Network Protocols IPX/SPX, TCP/IP, NetBEUI... -
Page 28: Appendix D: Warranty Information
Wireless PCI Card ™ Appendix E: Contact Information For help with the installation or operation of the Wireless PCI Card, contact Linksys Technical Support at one of the phone numbers or Internet addresses below. Sales Information Technical Support RMA Issues... - Page 29 © Copyright 2002 Linksys, All Rights Reserved.
