- Page 1 S t e a m i n g W a t e r Ta p I n s t r u c t i o n M a n u a l FOS/4IN1/SS, FOS/4IN1/BS, FOS/4IN1/CO, FOS/4IN1/GD, FOS/4IN1/GM Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk...
-
Page 2: Table Of Contents
Safety Instructions Environmental Protection Accessories Supplied Installing the Fosso 4IN1 Fosso 4IN1 Installation Operation Boiler Heating Time Tap Dimensions Boiler Technical Specification Care and Maintenance Troubleshooting Notes Caple Contact Details Instruction manual FOS/4IN1 Please keep this instruction manual for future reference... -
Page 3: Safety Instructions
› Bed and breakfast type environments. To avoid all risk, if the plug or power cable is damaged, it must only be replaced by a Caple appointed engineer. Do not wash children, hair or any pets in a sink within reach of this steaming water tap. - Page 4 This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazard involved. Cleaning and user maintenance must not be made by children unless they are older than 8 and supervised.
- Page 5 Do not use any accessories or attachments not recommended by Caple as this may result in fire, electric shock or injury. To protect against fire, electrical shock and injury to persons, do not immerse cord or plugs in water or any other liquid.
- Page 6 I M P O R T A N T Caple cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that Caple reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance.
-
Page 7: Environmental Protection
Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. If you fail to show your warranty card you will incur all repair charges. -
Page 8: Accessories Supplied
A C C E S S O R I E S S U P P L I E D You will receive 3 separate boxes for this product: › Tap › BOILER3 – boiler tank › PURITI8 – Filter and fixings The contents of the boxes should be as follows: ›... -
Page 9: Installing The Fosso 4In1
When installing the dispenser, you should allow 10 to 15cm of space around it for ventilation. 4. You must never use a spare part which is not recommended by Caple. 5. The temperature adjustment controls the water temperature, not the water flow. -
Page 10: Fosso 4In1 Installation
F O S S O 4 I N 1 I N S T A L L A T I O N › The power outlet must be correctly earthed and also be able to be isolated by a switch. › Use a separate circuit for the boiler, which is also correctly earthed. ›... - Page 11 2. Screw the Hot & Cold flexi hoses into the base of the hot/cold handle. The red hose connects to the hot water, the blue hose connects to the cold water. The boiling water flexible hose and the filtered water flexible hose connect to the base of the spout. The handle then needs to be connected to the spout via the additional flexi hose, as shown in the diagram here: 3.
- Page 12 6. Attach the Boiler inlet flexi tail onto the valve on the side of the boiler. Connect the other end of the tail to one of the remaining blue tubes using the push fit to threaded adaptor. Connect the other end of the blue tube to one of the connections on the push fit splitter.
- Page 13 To fix the boiler to the cabinet, remove the hanging plate from the packaging: › Mark the fixing location of the hanging bracket on the inside of the cabinet and install the bracket fixing screws into the cabinet. › Using the nut and thread on the top of the boiler, fit the bracket. ›...
-
Page 14: Operation
O P E R A T I O N °C HEATING Turn on the boiler press the button. To adjust the water READY temperature, press the arrows on the control panel to increase and decrease the temperature. The temperature can be adjusted from approximately 25°C to 98°C. Once the required temperature has been selected, ‘HEATING’... - Page 15 In order to guarantee the performance and quality of your steaming water tap, do not stretch the tubes after installation, take extreme care not to touch any of the tubes or fixings. If the flow reduces this may be due to the filter needing replacement. The water filter must be replaced at least once every 6 months, failure to do this may invalidate the guarantee.
-
Page 16: Boiler Heating Time
B O I L E R H E A T I N G T I M E The below table shows the effect on the temperature of the water as water is drawn from the boiler. For example, if you take 1250ml of boiling water (enough for around 9 cups of tea) in one go, the remaining water in the boiler will drop to 96˚C and take around 245 seconds to heat back to 98˚C. -
Page 17: Tap Dimensions
T A P D I M E N S I O N S F O S / 4 I N 1 360˚ 202mm 347mm 204mm Ø40mm 65mm 100mm 10mm Ø40mm Wor k to p c u t -o u ts 35 m m re q u i r e d Instruction manual FOS/4IN1 Please keep this instruction manual for future reference... -
Page 18: Boiler Technical Specification
B O I L E R T E C H N I C A L S P E C I F I C A T I O N B O I L E R 3 D I M E N S I O N S 229mm 15mm 345mm... -
Page 19: Care And Maintenance
C A R E A N D M A I N T E N A N C E I M P O R TA N T: You must not perform any care or maintenance on this product without first switching off the power supply and disconnecting the boiler from the mains. - Page 20 3. Remove the new filter cartridge from its packaging and check for any damage. 4. Insert the filter cartridge into the filter head and turn the cartridge clockwise until it stops and end position is reached. The flow in the filter head is reopened and the system vented and flushed via the flush/ pressure release valve.
-
Page 21: Troubleshooting
If you have a problem which cannot be resolved by using the troubleshooting table please contact Caple Service, by telephone on 0117 938 7420 or by email at service@caple.co.uk Instruction manual FOS/4IN1 Please keep this instruction manual for future reference... -
Page 22: Notes
N O T E S Instruction manual FOS/4IN1 Please keep this instruction manual for future reference... - Page 23 Instruction manual FOS/4IN1 Please keep this instruction manual for future reference...
-
Page 24: Caple Contact Details
Caple Service Fourth Way T: 0117 938 1900 Avonmouth E: service@caple.co.uk Bristol www.caple.co.uk BS11 8DW...
