Altech CB Series Instruction Manual page 3

No. 4, 5 Signal Ports (Output Isolated):
Connections for,
No. 5: MAINS OR BACKUP: Input Mains On/Off. Contact: 5,6,7
No. 4: LOW BATTERY, BATTERY REPLACEMENT, FAULT BATTERY or FAULT SYSTEM Contact: 8,9,10
Relay Contact Rating:
Max.DC1: 30 Vdc 1 A; AC1: 60 Vac 1A : Resistive load (EN 60947-4-1)
Min.1mA at 5 Vdc: Min. permissive load
Signal Output port
true table:
Mains Input Vac
The battery in
BackUP it is less than
30% cap?
Battery or system
Fault?
Note:
(1) For better efficiency of the system, filter relay Mains/Back up with a delay of at least 5 seconds before give alarm
Main Lost, example: connection to PLC.
(2) See Diagnosis Led
No. 6, 7 and 8 Display Signals
No.6: Led Mains/Back Up: Input Mains On/Off
No.7: Led Low Battery(capacity less than 30%), Fault connections systems, Battery replacement.
No.8: Led DIAGNOSIS: Battery charge mode,
Led Diagnosis. Diagnosis of the system through "blinking code" signal Light
State of Charge
Monitoring
Control State
Chart:
Float
Charging
Absorption
Type
Boost
Recovery
Fault Battery / Fault System
Reverse polarity or high battery Voltage
(over 32.5Vdc for CB 24xxA)
Battery No connected
Element in Short Circuit
Over Load or short circuit on the load
Bad battery; Internal impedance Bad or Bad battery wire
connection
Life test not possible
System Auto
Diagnosis Boost condition; battery discharge after 4 min. of overload.
Internal fault
Low battery (under 18.5Vdc for CB 24xxA) Only if started
from battery, no Mains input, from Jumper N°5 or Push
Bottom
MODBUS error
Life test not possible; Parallel mode on Slave Device
Bad battery wire connection; Parallel mode on Slave Device 13 Blink/pause
Boost condition; battery discharge after 4 min. of overload;
Parallel mode on Slave Device
