SPECIAL FUNCTIONS – CONFIGURATION
It is possible to set some alarm functions to adapt the alarm system to the motorcycle and its driver's needs. To set the functions,
which are described in the table below, proceed as follows:
1. arm the alarm system with the remote control
2. turn the ignition key ON within 10 seconds: the siren will make a BEEP sound to confirm selection
3. press the remote control's button A briefly 4 times: the siren will make 4 BOOP sounds to confirm reception of the signal
4. turn the motorcycle's ignition key OFF
5. turn the motorcycle's ignition key ON and then OFF the same number of times as the number of the special function to be set (see
EN
table). Leave the ignition key ON the last time: the LED is on
6. briefly press the button A of the remote control once if the settings described in the first column are required (see table - BEEP
column)
7. briefly press the button A of the remote control twice if the settings described in the second column are required (see table - BOOP
column)
8. turn the ignition key OFF and briefly press the button of the remote control to exit programming mode, otherwise repeat from step 5
to set another function.
TABLE SPECIAL FUNCTIONS – CONFIGURATION
1
Buzzer when arming and disarming
2
Direction indicators when arming and disarming
3 Horn/siren alarm output or control of activation
4
Control of alternate horn or continuous siren
5
Passive arming only of immoboliser or also alarm function
6 Passive arming with movement sensor enabled
7
Alarms of cyclical or single contacts
8
Enabling of automatic arming
28-07-2006 9:29 Pagina 14
(factory settings in bold type )
FUNCTION
14
BEEP BOOP
YES
NO
YES NO
Activation
Allarm
Alternated Continuous
Also alarm
Immobiliser
YES NO
Single
Cyclical
YES NO
