Congratulations for having chosen an alarm system from the HOME alarm
division of MetaSystem.
These instructions are designed to help the owner of a Meta System
HOME ALARM to use the system correctly by carefully following the step-
by-step explanations on the following pages.
W H A T Y O U R A L A R M S Y S T E M I N C L U D E S W H A T Y O U R A L A R M S Y S T E M I N C L U D E S
R E M O T E C O N T R O L T R A N S M I T T E R R E M O T E C O N T R O L T R A N S M I T T E R
This transmitter makes it possible to switch the alarm system on and off.
E M E R G E N C Y K E Y E M E R G E N C Y K E Y
With these keys it is possible to fully isolate the C11 unit and therefore
deactivate the alarm system.
Caution: store these keys in a safe place.
A D H E S I V E L A B E L S A D H E S I V E L A B E L S
Stick the adhesive labels on the entrance door or on windows where they
can easily be seen from the outside, as an additional deterrent.
W H A T Y O U R A L A R M S Y S T E M D O E S W H A T Y O U R A L A R M S Y S T E M D O E S
O P E R A T I O N O P E R A T I O N
In the case of an attempted break-in detected by the system's infrared
sensor, the unit will emit a number of beeps at low volume as a pre-
alarm (for 3 seconds), then it will activate its powerful siren for one alarm
cycle of 50 seconds.
S Y S T E M D I S A R M E D S Y S T E M D I S A R M E D
When the system is disarmed, the status is reported by different LED
signals:
-The Green LED present on the central unit indicates, "Power on". If this
LED is off (i.e. no power), the central unit is still operative and functions
thanks to the rechargeable internal back up batteries.
- Every time something moves within the range of the infrared sensor on
the C e n t r a l u n i t , C e n t r a l u n i t , a Yellow LED indicates that the object has been
detected. However, if objects pass in front of the sensor very frequently,
the sensor may not indicate all of them since it will enter immunity mode
for a few moments.
S Y S T E M A R M E D S Y S T E M A R M E D
- - The flashing Red LED on the central unit indicates that the system is
armed. However, it will only be able to generate an alarm 25 seconds
after being armed, if there is an intrusion.
U S E R I N S T R U C T I O N S U S E R I N S T R U C T I O N S
A R M I N G A R M I N G
Press and release the remote control button to activate the alarm
system. The unit will emit two low-volume signals (BEEPS) and the red
light will flash. After 25 seconds, the system is active and ready to go into
operation in the event of a break-in.
D I S A R M I N G D I S A R M I N G
Press and release the remote control button to deactivate the alarm
system. The unit will emit a single long BEEP and the red light will go out.
If the Red light does not go out and the unit emits 10 beeps close
together after approximately 18 seconds, it means that during your
absence there has been at least one alarm (see the section ALARM
MEMORY for a full explanation).
P A N I C A L A R M P A N I C A L A R M
Keep the remote control button pressed for approximately 6 seconds. An
alarm cycle lasting 15 seconds will be generated that, once activated,
cannot be stopped so it is necessary to wait for the end of the cycle.
S I G N A L S S I G N A L S
C E N T R A L U N I T C E N T R A L U N I T
- Red LED: During the first 25 seconds after switching on, this light will
flash in inverted mode (short PAUSES). After this time it will flash
C 1 1 C 1 1
regularly (short FLASHES) every 0.8 seconds to signal that the system is
ready to trigger an alarm.
- Green LED: This light i s on when there is an external power supply
(mains voltage or 12V).
- Yellow LED: This light comes on briefly every time the central unit
infrared sensor detects a movement, both when the alarm system is
armed or disarmed.
C E N T R A L U N I T A L A R M M E M O R Y C E N T R A L U N I T A L A R M M E M O R Y
The central unit has an alarm memory that signals any alarms occurring
during your absence.
If the Red LED remains on after disarming the central unit and 18
seconds has elapsed, an alarm has been triggered and the Red LED will
flash accordingly.
The signals continue until the unit is switched on again.
If no alarms have been triggered, the red LED on the central unit will go
out when the system is disarmed.
O P E R A T I N G I N S T R U C T I O N S O P E R A T I N G I N S T R U C T I O N S
A D D I T I O N A L R E M O T E C O N T R O L S A D D I T I O N A L R E M O T E C O N T R O L S
After purchasing a new remote control from the centre that supplied you
with the alarm system, carry out the following procedures to make it
operative.
1) Using the remote control supplied, arm and disarm the central unit
several times (press the button consecutively 16 times, waiting a few
seconds between one operation and the next) until the central unit emits
3 consecutive BEEPS.
2) Press the button on the new transmitter within 8 seconds until the
central unit confirms reception by emitting 3 BEEPS.
3) Repeat step 2 for each further transmitter to be memorised, including
those, which were already memorised.
4) Once all the remote controls have been memorised, wait about 8 sec.
for the central unit to exit the remote control memorising mode. From
this moment onwards, only the transmitters memorised in the above
phase will be able to command the central unit.
E X C L U D I N G R E M O T E C O N T R O L S E X C L U D I N G R E M O T E C O N T R O L S
It is possible to block operation of any remote control that has been lost
or stolen: in this way the safety of your alarm system is ensured, since
only you can turn it off. T o disable any lost transmitters, repeat the
operation from point 1 to point 4 in the previous section, using all the
transmitters remaining.
Any transmitters that have been lost or that will not be used in this phase
will be automatically inhibited.
C A U T I O N C A U T I O N
Due to the normal discharge of the rechargeable batteries in the parts
with battery back up, the battery charge may be low at the time of
installation. Therefore keep the product powered for at least 24 hours
before testing the back up.
T E C H N I C A L S E R V I C E S T E C H N I C A L S E R V I C E S
W H O T O C A L L W H O T O C A L L
For any clarification on using the system, please do not hesitate to call
your area dealer who should affix his stamp below and/or give the
particulars of the person to contact:
