USER GUIDE
Crystal® Designer Baby Gate - Hardware Mount
Inside Opening
Outside Opening
Height
Min 29.5" (75 cm)
Min 26.4" (67 cm)
30.7" (78 cm)
Max 40.5" (103 cm)*
Max 36.6" (93 cm)
*Using included spacers
IMPORTANT:
Qdos wants to keep your children safe
and for that we need you to do your part by carefully
reading and following the instructions below. Please read
through the instructions before starting the installation.
For installation videos and FAQ go to: QdosSafety.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Crystal and is the answer not in the manual?

Questions and answers

Related Manuals for Qdos Crystal

Summary of Contents for Qdos Crystal

  • Page 1 USER GUIDE Crystal® Designer Baby Gate - Hardware Mount Inside Opening Outside Opening Height Min 29.5" (75 cm) Min 26.4" (67 cm) 30.7" (78 cm) Max 40.5" (103 cm)* Max 36.6" (93 cm) *Using included spacers IMPORTANT: Qdos wants to keep your children safe and for that we need you to do your part by carefully reading and following the instructions below.
  • Page 2 IMPORTANT! PLEASE READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE When installed between two strong and rigid surfaces and according to these instructions, this gate has been tested to meet or exceed the following Safety Standards, US- ASTM F-1004, Canada- SOR/90-39, and European- EN 1930.

  • Page 3: Maintenance And Cleaning

    1 year from date of purchase, when used under normal conditions and in compliance with these instructions. Qdos will either repair, or at its own option replace, free of charge, any parts necessary to correct any defect in material or workmanship during the warranty period.
  • Page 4 OPENING SIZE AND ANGLE MOUNTING The Crystal® will fit inside openings from 29.5-40.5" (75- 103 cm)* and in front of openings 26.4-36.6" (67-93 cm). The size of the gate is adjustable by sliding the two gate panels, adjustments in handle and hinges.
  • Page 5 Qdos Universal Baseboard Kit - If the baseboard is more than 4.25” tall you will need to use the Qdos Baseboard Kit in order to create a vertical mounting surface. Works for baseboards up to 7/8” (22 mm) thick and up to 7” (18 cm) tall.

  • Page 6: Parts List

    PARTS LIST: Top Lock Bottom Lock A/B FastMount® LOCKING Rail (One screw hole) Top Hinge Bottom Hinge C/D FastMount® HINGE Rail (Two screw holes) 2x One-Way Stop Extra Long Barrel Nut (Right and Left side) for One-Way Stop...
  • Page 7 3x Short 2" 3x Medium 2.75" 3x Long 3.25" (50 mm) Screws (70 mm) Screws (85 mm) Screws 1x Shorter screw 1x Shorter screw 1x Shorter screw SecureTrack® 2x Top Baseboard 2x Bottom Gate Panels, pre-assembled Spacers Baseboard Spacers 2x Allen Installation Level Gate Removal Wrenches...
  • Page 8 Step 1 Identify the rail with only one hole in it. With the hole towards the bottom, push the Top Lock into the top of the FastMount® Locking Rail (A/B) until the plastic tab snaps into place on the back of the rail (A).
  • Page 9 IMPORTANT: REGARDING THE INCLUDED MOUNTING SCREWS! Before marking where to attach the gate, make sure you have a solid surface for mounting the gate to. *If using at top of stairs install gate a minimum 1” (2.5 cm) from top step! The included screws are intended for the following locations:...
  • Page 10 Step 3 With the C/D FastMount® Hinge Rail resting on the floor in the desired location, use the provided Installation Level to make sure it is vertical. Remove the protective liner from the adhesive tape on the level so that the level can be attached to the rail.
  • Page 11 Step 6 If the gate is mounted at any angle within 180 degrees, make sure to reinstall the Main Lock, so it points directly toward the Hinge rail. Install the Top Cover and insert the screws to hold it in place. Step 7 Gently hang the gate on the hinges.

  • Page 12: Gate Operation

    Step 9 With the gate in the locked position, lift up on the panels to make sure they are level, then use the Allen Wrenches to tighten the four clamps. GATE OPERATION To open the gate slide back the locking latch, while at the same time, lifting the gate and open the door.
  • Page 13 Hinge and Locking FastMount® Rails. • If the height is more than 4.25" (10.8 cm) tall, you will need the Qdos Baseboard Kit in order to create a vertical mounting surface. This kit can accommodate baseboards up to 7" (18 cm) tall and up to 7/8” (2.2 cm) thick.
  • Page 14 ONE WAY STOP The One-Way Stop must always be used when the gate is used at the top of stairs to prevent the gate from swinging out over the stairs. It can also be used in any other location where you want to restrict the opening direction.
  • Page 15 TEMPORARY OR PERMANENT REMOVAL OF GATE If you need to temporarily or permanently remove the gate, you can do so by using the provided Removal Tool. Slide the Removal Tool into the underside of the Top Hinge. The Removal Tool will compress the locking tabs and be held in place.
  • Page 16 Distributed by Regal Lager, Inc. 1100 Cobb Place Blvd. Suite 100 Kennesaw, GA 30144 USA 1-800-593-5522 • www.QdosSafety.com support@qdos.zendesk.com ©2021 Qdos All rights reserved. Qdos is a trademark of Regal Lager, Inc. Made in China 12/2021...
