Connectivity guide

Windows instructions for a locally attached printer

Note: When installing a locally attached printer, if the operating system is not supported by the Software and
Documentation CD, the Add Printer Wizard must be used.
Updates for the printer software may be available on the Lexmark Web site at www.lexmark.com.
What is local printing?
Local printing is printing to a locally attached printer (a printer that is connected directly to your computer with a USB
or parallel cable). When setting up this type of printer with a USB cable, you should install the printer software
before connecting the USB cable. For more information, see the setup documentation.
The Software and Documentation CD can be used to install the necessary printer software on most Windows operating
systems.

Installing software using the CD

Using the Software and Documentation CD, you can install printer software for the following operating systems:
•
Windows Vista
•
Windows Server 2003 and Windows Server 2003 x64
•
Windows XP and Windows XP x64 bit Edition
•
Windows 2000
•
Windows Me
•
Windows NT 4.0
•
Windows 98 Second Edition (USB not supported)
1
Insert the Software and Documentation CD.
If the install screen does not appear, click Start
your CD-ROM drive.
2
Select Install Printer and Software.
3
Select Suggested, and then click Next.
4
Select Local Attach, and then click Next. The printer software is copied to your computer.
5
Connect the USB or parallel cable, and then turn on the printer.
The Plug and Play screen appears, and a printer object is created in the Printers folder.

Installing software using the Add Printer Wizard

You can install printer software for the following operating systems:
•
Windows 98 First Edition (USB not supported)
•
Windows 95 (USB not supported)
1
Insert the Software and Documentation CD.
If the CD automatically starts, click Exit.
2
Click Start
Settings
3
When prompted, select to install a local printer, and then click Have Disk.
Run, and then type D:\setup.exe, where D is the letter of
Printers, and then click Add Printer to start the Add Printer Wizard.
Connectivity guide
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C935 and is the answer not in the manual?

Questions and answers

Related Manuals for Lexmark C935

Summary of Contents for Lexmark C935

  • Page 1 What is local printing? Local printing is printing to a locally attached printer (a printer that is connected directly to your computer with a USB or parallel cable). When setting up this type of printer with a USB cable, you should install the printer software before connecting the USB cable.
  • Page 2 From the list of discovered printers, select the one you want to print to. Note: If the printer does not appear in the list, click Add Port, and then follow the instructions on the screen. Click Finish to complete the installation.
  • Page 3 Select to install a network printer. Enter the printer name or URL if you are on the Internet or an intranet, and then click Next. If the printer name or URL is unknown, leave the text box empty, and then click Next.

  • Page 4: Installing Optional Printer Software

    USB cable. For more information, see the setup documentation. The Software and Documentation CD can be used to install the necessary printer software. Note: A PPD for the printer is also available in a downloadable software package on the Lexmark Web site at www.lexmark.com.
  • Page 5 If the USB-attached printer does not appear in the Printer list, make sure the USB cable is properly connected and the printer is turned on. After the printer appears in the Printer list, quit the Print Center or Printer Setup Utility.
  • Page 6 From the list, select the AppleTalk zone. For information about which zone or printer to select, see the network setup page under the AppleTalk heading. For information about printing a network setup page, see the User's Guide. From the list, select the new printer, and then click Add.
