Related Manuals for Onwa KR-1968-H
Summary of Contents for Onwa KR-1968-H
- Page 22 knob thirty-two Turn knob 4) Slide the trackball up and down to select “BACKGROUND COLOR” or “ECHO COLOR” press [ENTER] key; 5) Slide the trackball up and down to select desired and press [ENTER] key; 6) Press [ENTER] key to close the menu. 3.Using the [0 BRILL] key, you can switch the default background color and echo color to display mode: day, dusk, night.
- Page 25 A/C AUTO...
- Page 30 1. Operate the trackball to set cursor where desired. 2. Press the [4 OFF CENTER] key, “OFF-CNET” appears at the top right corner of the display when the picture is shifted. Press and hold down the [4 OFF CENTER] key about three seconds.
- Page 32 2. Operate the trackball to select the Item and press the [ENTER] key. For example, select RINGS. A message appears at the right of the menu window. 3. Operate the trackball and press the [ENTER] key.
- Page 34 trackball.
- Page 36 trackball. Single Short Manual Wide Full Clear trackball...
- Page 49 Request service. there is no change in sensitivity...
- Page 54 Conti Targer under auto tracking but not select for cursor data reading Target selected Target full mark for data reading AUTO O F F O F F TUNE heading line 234.5° GAIN O F F O F F TRAIL A/C Auto OWN SHIP RAIN BRILL...
- Page 62 2. Select [AIS MENU] & press [ENTER] key, Select “DISPLAY”, select “ON” & press [MENU] key to return. NOW if “AIS” word appears on the upper screen of the display. The AIS symbol is shown in the radar echo area. Shortcuts: Press and hold down the [3 TARGET LIST] key.
- Page 63 From the list of AIS information, select the direction key and press [ENTER], ON Figure 3, the detailed date of the current selected ship information shall be display. When the cursor is moved to the target ship and press [TARGET DATA] key, the seleted ship will appear as shown in Figure 4 and the AIS data shall appear as show in Figure 5.
- Page 64 Enter AIS menu, select “VECTOR LENGTH” and press [ENTER] key, then use the direction key choose corresponding time, and press the [ENTER] key.
- Page 70 n in...
- Page 71 Only one signal cable runs from the display unit to the antenna unit. Make the hole for passing the cable through the bulkhead or deck at least 20 millimeters diameter. In order to minimize the chance of picking up electrical interference, avoid routing the signal cable near other onboard electrical equipment.
- Page 76 °C Rotate 47.2 28.7...
Need help?
Do you have a question about the KR-1968-H and is the answer not in the manual?
Questions and answers
Need assistance on how to operate KR-1968-H
To operate the Onwa KR-1968-H:
1. Use the trackball to move the cursor and select menu items.
2. Press the [ENTER] key to confirm selections.
3. Press and hold the [4 OFF CENTER] key for about three seconds to shift the display picture; “OFF-CNET” appears at the top right.
4. Use the [0 BRILL] key to switch display modes between day, dusk, and night.
5. To change background or echo color:
- Slide the trackball to select “BACKGROUND COLOR” or “ECHO COLOR.”
- Press [ENTER], choose the desired color, and press [ENTER] again.
6. For AIS operation:
- Select [AIS MENU], then “DISPLAY,” choose “ON,” and press [MENU] to return.
- The AIS symbol appears on the radar screen.
- Press and hold the [3 TARGET LIST] key to view AIS targets.
- Move the cursor to a target and press [TARGET DATA] to view detailed information.
For installation:
- Apply sealing compound for waterproofing.
- Run the signal cable through a waterproof gland.
- Unfasten bolts at the scanner tail to access the cable gland.
- Pass the cable through the fastening bolt, washer, waterproof apron, and mounting hole into the antenna base.
This answer is automatically generated
