Summary of Contents for Total TT101116
- Page 1 GLUE GUN T T101116,UT T101116, T T101116-4,T T101116-6, T T101116-8,T T101116-9, T T101116S totaltoolsworld TOTAL TOOLS WORLD 100W...
- Page 2 Safety Regulations Warning! Do not open the casing! Dangerous voltage is found unprotected on some components inside the product's casing; contact with these may lead to electric shock. •The product may only be repaired by qualified service personnel. •The product may not be taken apart nor be changed.
- Page 3 The following safety precautions shall be followed to avoid the risk of fire: •Be careful when you use the Glue Gun in spaces with inflammable material. •Do not hold the Glue Gun over the same spot for a long time. •Do not use the Glue Gun in explosive environments.
- Page 4 Description 1. Trigger 2. Nozzle 4. Glue stick 3. Cable The Glue Gun is made for gluing wood, paper and cardboard as well as some plastic materials. Usage 1. Connect the plug to the wall socket. 2. Place a glue stick in the opening on the back of the gun as indicated in the picture.
- Page 5 Disposal Follow local ordinances when disposing of this product. If you are unsure about how to dispose of this product contact your municipality. Technical data TT101116-4 TT101116-6 TT101116 (IRAM Plug) (ISRAEL Plug) Model No. TT101116-8 TT101116S TT101116-9 (BS Plug) (SAA Plug)
- Page 6 T T101116,UT T101116, TT101116-4,TT101116-6,T T101116-8 T T101116-9,T T101116S Exploding view...
- Page 7 TT101116,UTT101116, TT101116-4,TT101116-6,TT101116-8 TT101116-9,TT101116S Spare part list Part Description glue gun shells cap of nozzle Aluminum parts of heater silicon sleeve fix ring plastic sleeve silicon Rear retaining ring Circlip plastic stand Silicon sleeve tablet compressing electric cable Insulating paper drag spring...
- Page 8 GLUE GUN www.totaltools.cn TOTAL TOOLS CO., PTE. LTD. MADE IN CHINA T0319.V03 100W...
