Summary of Contents for Raymarine DRAGONFLY Ice Fishing Kit
- Page 1 Ice Fishing Kit Installation instructions...
- Page 2 Trademark and patents notice Raymarine, Tacktick, Clear Pulse, Truzoom, SeaTalk , SeaTalk , SeaTalk , and Micronet, are registered or claimed trademarks of Raymarine Belgium. FLIR, LightHouse, DownVision, SideVision, RealVision, Dragonfly, Quantum, Axiom, Instalert, Infrared Everywhere, The World’s Sixth Sense and ClearCruise are registered or claimed trademarks of FLIR Systems, Inc.
-
Page 3: Table Of Contents
Contents Chapter 1 Important information..................7 Declaration of Conformity......................8 Disclaimer ........................... 8 Warranty ............................8 Warranty registration ......................... 9 Product disposal ........................9 Battery disposal ......................... 9 Technical accuracy ........................9 Chapter 2 Document and product information.............11 2.1 Ice fishing kit overview ....................... 12 2.2 Applicable products...................... - Page 4 Chapter 7 Troubleshooting .................... 37 7.1 Sonar troubleshooting ....................... 38 Chapter 8 Technical support ..................41 8.1 Raymarine product support and servicing ..............42 8.2 Learning resources ......................44 Chapter 9 Technical specification................. 45 9.1 Ice fishing kit specification ....................46 9.2 Transducer specification ....................
-
Page 5: Chapter 1 Important Information
• Cutting the transducer cable will void the warranty and invalidate the European CE mark. Caution: Service and maintenance This product contains no user serviceable components. Please refer all maintenance and repair to authorized Raymarine dealers. Unauthorized repair may affect your warranty. Important information... - Page 6 Warning: Battery warnings Before handling, charging, installing or using your battery please ensure you have read and understood the safety related information provided below. • Always store the battery in a cool and dry area that is well-ventilated and not in direct sunlight.
-
Page 7: Chapter 2 Document And Product Information
Chapter 2: Document and product information Chapter contents • 2.1 Ice fishing kit overview on page 12 • 2.2 Applicable products on page 13 • 2.3 Parts supplied on page 16 Document and product information... -
Page 8: Ice Fishing Kit Overview
2.1 Ice fishing kit overview When combined with a compatible display the Ice fishing kit creates a portable, standalone Fishfinder that can be used for Ice fishing. -
Page 9: Applicable Products
2.2 Applicable products This document is applicable to the products listed below: Part number Description A80580 Dragonfly ice fishing kit Document and product information... -
Page 10: Compatible Displays
Compatible displays The ice fishing kit requires a compatible display to view the sonar image. See the list of compatible displays below: • Dragonfly® 4DVS display • E70292 • Dragonfly® 4PRO display • E70294 • Dragonfly® 5DVS display • E70306 •... - Page 11 • Dragonfly® 6 legacy display • E70085 • Dragonfly® 7 legacy display • E70231 Important: Adaptor cable A80331 is required to connect an ice fishing transducer to a legacy Dragonfly® display that utilizes the one keyway Red connector. Document and product information...
-
Page 12: Parts Supplied
2.3 Parts supplied Unpack your product carefully to prevent damage or loss of parts. Check the box contents against the list above. Retain the packaging and documentation for future reference. Base 2. Bag 3. 12 V dc Battery (supplied fitted to the base) 4. -
Page 13: Additional Fixings And Components
Additional fixings and components Display bracket fixings When mounting the display’s bracket on the base it is recommended that additional, shorter fixing bolts are purchased. • Dragonfly® 4DVS display M5x20mm pan head pozi A4 Stainless steel • Dragonfly® 4PRO display •... -
Page 14: Chapter 3 Installation
Chapter 3: Installation Chapter contents • 3.1 Charging on page 20 • 3.2 Assembly on page 21 Installation... -
Page 15: Charging
The quoted charge time is an approximate time calculated in optimum conditions, based on a new battery. Raymarine will not be liable for batteries that fail to meet this charge time as factors such as battery age, condition, charge cycles and usage all affect the charging time. -
Page 16: Assembly
3.2 Assembly Fitting the handle to the base Once you have unpacked all the items from the box, assemble your ice fishing kit following the instructions below. Note: The battery is supplied already fitted to the base using the battery straps; there is no need to remove the battery from the base. -
Page 17: Fitting The Float
Fitting the float 1. Slide the transducer cable through the slot in the side of the float. 2. Adjust the position of the float so that the transducer will be at the desired depth when submerged. 3. Attach the cable clamp to the transducer cable, above the float. Fitting the suppression ferrite 1. -
Page 18: Mounting The Display
Mounting the display Mounting hole locations Dragonfly®–4, Dragonfly®–5 and Dragonfly®–7 bracket holes 2. Legacy Dragonfly®6 and Dragonfly® 7 bracket holes Important: Take care when tightening the display bracket fixings as over tightening may cause the base or bracket to crack. Installation... -
Page 19: Transducer Placement
1. Using the parts supplied with your display and the relevant, additional fixing bolts (not supplied), attach the display’s bracket to the base using the relevant mounting holes. Important: Additional bolts are required to connect your display to the ice fishing kit’s base. The washers and locking nuts supplied with your display can be used with the new bolts. -
Page 20: Chapter 4 Connections
Chapter 4: Connections Chapter contents • 4.1 Connecting the cable to the display on page 26 • 4.2 Battery connection on page 28 Connections... -
Page 21: Connecting The Cable To The Display
4.1 Connecting the cable to the display With the suppression ferrite and float fitted to the transducer cable, follow the steps below to connect the transducer cable to your display. 1. Rotate the display’s connector locking collar to the unlocked position. 2. -
Page 22: Connecting Cable To Legacy Display Using Adaptor Cable
Connecting Cable To Legacy Display Using Adaptor Cable Adaptor cable A80331 is required to connect an ice fishing transducer to a legacy Dragonfly® display that utilizes the one keyway Red connector. 1. Connect the adaptor cable’s power cable to the battery as follows: i. -
Page 23: Battery Connection
4.2 Battery connection When connecting the power cable to the supplied battery, a waterproof fuse holder and 5 amp fuse (not supplied) must be fitted. Important: Only use the battery supplied with your ice fishing kit to power your display. Display power supply cable (part of the ice fishing transducer’s cable). -
Page 24: Chapter 5 Operations
Chapter 5: Operations Chapter contents • 5.1 Operation on page 30 Operations... -
Page 25: Operation
5.1 Operation Refer to the operation instructions supplied with your display for details on operating the transducer using the Sonar app. Battery operation Guidance for battery operation is provided below. • When used in colder temperatures the battery will discharge more quickly than in warmer conditions. -
Page 26: Transportation
Transportation 1. Before transporting your ice fishing kit, unplug the power terminals from the battery. 2. Close the front flap using the zips provided. 3. Place your hand inside the handle hole located on the back of the bag. Your hand should slide under and grasp the metal handle through the material. Battery storage Prior to storage, the battery should be fully charged and then stored in a cool dry place with the battery terminals disconnected. -
Page 27: Chapter 6 Maintaining Your Display
Chapter 6: Maintaining your display Chapter contents • 6.1 Service and maintenance on page 34 • 6.2 Product cleaning on page 35 Maintaining your display... -
Page 28: Service And Maintenance
6.1 Service and maintenance This product contains no user serviceable components. Please refer all maintenance and repair to authorized Raymarine dealers. Unauthorized repair may affect your warranty. Warning: High voltage This product contains high voltage. Adjustments require specialized service procedures and tools only available to qualified service technicians. There are no user serviceable parts or adjustments. -
Page 29: Product Cleaning
6.2 Product cleaning Best cleaning practices. When cleaning products: • Lightly rinse or flush with clean, cool fresh water. • If your product has a display screen, do NOT wipe the screen with a dry cloth, as this could scratch the screen coating. •... -
Page 30: Chapter 7 Troubleshooting
Chapter 7: Troubleshooting Chapter contents • 7.1 Sonar troubleshooting on page 38 Troubleshooting... -
Page 31: Sonar Troubleshooting
External sonar module: • Check that the unit is correctly connected to the SeaTalkhs ™ / RayNet network multifunction display or Raymarine network switch. If a problem. crossover coupler or other coupler cable / adapter is used, check all connections ensuring connections are secure, clean and free from corrosion, replace if necessary. - Page 32 Possible causes Possible solutions Damaged cables Check the unit’s connector for broken or bent pins. 2. Check that the cable connector is fully inserted into the unit and that the locking collar is in the locked position. 3. Check the cable and connectors for signs of damage or corrosion, replace if necessary.
- Page 33 Possible causes Possible solutions Transducer location • Check that the transducer has been installed in accordance with the instructions provided with the transducer. • If a transom mount transducer is mounted too high on the transom it may be lifting out of the water, check that the transducer face is fully submerged when planing and turning.
-
Page 34: Chapter 8 Technical Support
Chapter 8: Technical support Chapter contents • 8.1 Raymarine product support and servicing on page 42 • 8.2 Learning resources on page 44 Technical support... -
Page 35: Raymarine Product Support And Servicing
8.1 Raymarine product support and servicing Raymarine provides a comprehensive product support service, as well as warranty, service, and repairs. You can access these services through the Raymarine website, telephone, and e-mail. Product information If you need to request service or support, please have the following information to hand: •... -
Page 36: Chapter 9 Technical Specification
Chapter 9: Technical specification Chapter contents • 9.1 Ice fishing kit specification on page 46 • 9.2 Transducer specification on page 47 • 9.3 Sonar specification on page 48 • 9.4 Charger specification on page 49 • 9.5 Battery specification on page 50 Technical specification... -
Page 37: Ice Fishing Kit Specification
9.1 Ice fishing kit specification Included Transducer: CPT-S ice fishing transducer (with 2.5 m (8.2 ft) transducer cable and display 0.5 m (1.64 ft) power supply cable) Bag dimensions (approximate): • Width: 290 mm (11.42 in) • Height: 270 mm (10.63 in)) •... -
Page 38: Transducer Specification
9.2 Transducer specification Operating temperature range: -2°C (28.4°F) to +35°C (95°F) Storage temperature range: -20°C (-4°F) to +70°C (158°F) Display power supply: 12 V dc, 7 Ah (amp hour) or greater Power: 90 W Depth: 0.6 m (1.97 ft) to 274 m (898.95 ft) Offset angle: 0°... -
Page 39: Sonar Specification
9.3 Sonar specification Channels 1 x CHIRP sonar Beam coverage Conical beam Depth range 0.6 m (2 ft) to 274 m (900 ft) depending on water conditions Power 90 W... -
Page 40: Charger Specification
9.4 Charger specification Type: Class 2 power supply, suitable for indoor use only. Input voltage: 100 V ac to 240 V ac Input current: 0.4 A Input frequency: 50/60 Hz Output voltage: 13 V dc Output current: 0.8 A Output power: 15.0 W max Included adaptors: •... -
Page 41: Battery Specification
9.5 Battery specification Battery type: Sealed, valve regulated lead-acid (VRLA), rechargeable Nominal voltage: 12 V dc Capacity 20 hours @ 25°C (77°F): 7.0 Ah (7000 mAh) Internal resistance: 22 m Ω Approximate usage time — from fully charged Examples: @ -20°C (-4°F): •... -
Page 42: Chapter 10 Spares And Accessories
Chapter 10: Spares and accessories Chapter contents • 10.1 Spares on page 52 Spares and accessories... -
Page 43: Spares
10.1 Spares A80582 CPT-S ice fishing transducers (with 2.5 m cable) R70671 Ice fishing bag R70672 Ice fishing mount R70673 Ice fishing float and clips R70674 Ice fishing battery and charger... - Page 44 Index Support forum ............44 Battery charger, charging status ......20 Technical specification ..........45 Battery disposal............9 Technical support..........42, 44 Battery, connection ..........28 Training courses ............44 Cable ...............26 Video Gallery............44 Cleaning ..............35 Compatible displays ..........14 connection...............26 Connection Display ..............26 Warranty ..............42 Connections, legacy Dragonfly displays ....
