INOGENI U-CAM
User guide
Version 1.3
9/30/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-CAM and is the answer not in the manual?

Questions and answers

Related Manuals for inogeni U-CAM

Summary of Contents for inogeni U-CAM

  • Page 1 INOGENI U-CAM User guide Version 1.3 9/30/22...

  • Page 2: Table Of Contents

    Device interfaces ................................3 Leds behavior ................................4 Specifications ................................. 5 Serial communication protocol ............................6 LAN communication protocol ............................7 CDC-NCM communication protocol ..........................7 Webpage ..................................7 REST API ..................................8 INOGENI Control App ..............................10 Support..................................11...

  • Page 3: Typical Application

    TYPICAL APPLICATION Here is a typical connection diagram used for the U-CAM device in a videoconferencing setup.

  • Page 4: Device Interfaces

    DEVICE INTERFACES Here are the devices interfaces. USB input #1 USB input #2 LAN port USB 2.0 output HDMI output RS232 port +12V power input USB device detection leds Factory upgrade switch System activity led...

  • Page 5: Leds Behavior

    LEDS BEHAVIOR Here are the leds behavior: USB input No USB camera/device connected. SOLID USB camera/device connected. System activity led No power present on board. BLINK System firmware running correctly.

  • Page 6: Specifications

    SPECIFICATIONS Here is the complete specification. Physical details Dimensions (W x L x H) 70 x 83 x 23 mm Power supply Power consumption Up to 1.2A Weight 136 g 1 x USB 2.0 Type-B to Type-A cable. Package content 1 x terminal block connection.

  • Page 7: Serial Communication Protocol

    SERIAL COMMUNICATION PROTOCOL Here is the complete list of commands provided through the serial connection. Pinout is indicated on the enclosure. Typically, commands will return ACK in case of success and NACK in case of failure. Note that if serial interface was disabled using REST API, commands will not be parsed, and no response will be provided.

  • Page 8: Lan Communication Protocol

    LAN COMMUNICATION PROTOCOL You can access the device settings through its LAN interface. The LAN interface use DHCP. You can obtain the IP from the Inogeni Control App or from the serial port IP command. CDC-NCM COMMUNICATION PROTOCOL The device can also be controlled through CDC-NCM interface exposed on the USB2.0 device port.

  • Page 9: Rest Api

    REST API The REST API need to have Autorization: Bearer <REST API access token> in the HTTP header. The response will be JSON formatted with a “message” field containing a JSON string explaining the cause of the error if any. Note that we are using self-signed certificate.
  • Page 10 we go as fast as the camera allow. We recommend using values between -10 and 10. POST <Integer> 200 => success JSON object https://<IP>/api/v1/zoom The sign specifies the 400 => error with message direction. 401 => authorization error field We multiply the argument by explaining the camera smallest step, error if any...

  • Page 11: Inogeni Control App

    INOGENI CONTROL APP You can use our Control App to monitor firmware information, upgrade and configure your unit. NOTE: You need to use the USB-B to USB-A cable provided with the box for the Control App to detect the unit.

  • Page 12: Support

    © Copyright 2022 by INOGENI INC. All Rights Reserved. INOGENI name and logo are trademarks or registered trademark of INOGENI. Use of this product is subject to the terms and conditions of the license and limited warranty in effect at the time of purchase. Product specifications can change without notice.
