Cambro Camshelving GN 1/1 Assembly Manual

Food pan trolley

Advertisement

ASSEMBLY
Camshelving
®
GN Food Pan Trolley
MANUAL
IMPORTANT! DO NOT REMOVE
STOP!
elastic bands on rail panels
until after bottom post
connector frame is installed.
SCAN HERE to watch short
assembly video.
www.cambro.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Camshelving GN 1/1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cambro Camshelving GN 1/1

  • Page 1 ASSEMBLY Camshelving ® GN Food Pan Trolley MANUAL IMPORTANT! DO NOT REMOVE STOP! elastic bands on rail panels until after bottom post connector frame is installed. SCAN HERE to watch short assembly video. www.cambro.com...
  • Page 2: Parts And Tools

    SHEET 1 OF 1 TOLERANCES: FINISH APPROX. WEIGHT 0.063 ALL DIMENSIONS ARE IN INCHES. DO NOT SCALE DRAWING! 0.031 0.015 www.cambro.com TITLE MANUFACTURING COMPANY DRAWN FILE NAME E. Freeman Cart Half size Food Pan Rack EXP 2 Assem2 ISSUED 4/28/2020 DRAWING No.
  • Page 3 Step 1: Install Bottom Post Connector Frame Match lock tab on post wedge (B close up) to lock opening (A close up) on frame. Slide each post up through bottom post connector opening. Move frame down evenly onto wedges (C close up). Stand trolley upright on casters.
  • Page 4: Incorrect Installation

    DESCRIPTION DATE REV. APPR'D Step 2: Install Side Rail Panels REV. DESCRIPTION DATE APPROVED BOTTOM Identify top and bottom of rail panel (A close up). Hold each side/end and carefully remove elastic band. REV. DESCRIPTION DATE APPROVED Hold panel with rails facing into the inside of the trolley (B close up).
  • Page 5 Step 3: Install Top Post Connector Frame Install wedges as shown (A close up). Place Top Post Connector Frame down onto wedges. Mallet frame down onto each corner (B close up). Frame lock opening should be fully engaged on wedge lock tab.
  • Page 6: Care And Maintenance
