Cambro IBSD37 Setup Manual And User Manual

SET UP GUIDE

AND USER MANUAL

IBSD37

Capacity: 37 Gallon (140 L)

Bin Colors: White (148), Yellow (229)

Unit ships complete with 18" (45,7 cm)*

long clear drain hose made of FDA

approved PVC material. Can be used

with or without hose based on access to

floor drain.

* Available hose length when attached

to the drain elbow is 16

⁄

" (42 cm).

Set Up Guide and Usage Instructions

1. Remove the tank from the carton and locate the

drain elbow hose assembly.

SOAK AND BRINE TANK

2. Verify the presence of the black O-ring on the

plumbing union.

3. Attach the drain elbow hose assembly by engaging

the threaded ring and rotating it counterclockwise

until tight.

4. To re-position the drain elbow, loosen the threaded

ring slightly, turn drain elbow to the desired

position, then tighten to keep it in place.

www.cambro.com

CA PROP 65

Table of Contents

Do you have a question about the IBSD37 and is the answer not in the manual?

Page 1 SET UP GUIDE SOAK AND BRINE TANK AND USER MANUAL IBSD37 Capacity: 37 Gallon (140 L) Bin Colors: White (148), Yellow (229) Unit ships complete with 18" (45,7 cm)* long clear drain hose made of FDA approved PVC material. Can be used with or without hose based on access to floor drain.
Page 2 Set Up Guide and Usage Instructions Cont. Recommended Safe Fill Line 5. Before filling tank, ensure blue valve handle is in 6. Fill tank. Caution: Do not fill to the rim with 7. To drain directly over a floor drain, remove drain the closed position and drain elbow is facing up.
Page 3 How to Replace the Drain Valve Assembly 1. Remove hex nut from inside the bin. Requires 1 ⁄ " 2. Remove hex bolts and washers from front mounting Ensure valve handle is turned in the closed (4,5 cm) wrench or large pliers. support bracket.
Page 4 • After 1 year and up to 2 years from the date of manufacture, Cambro will grant a credit of 2/3 off replacement product; or, • After 2 years and up to 3 years from the date of manufacture, Cambro will grant a credit of 1/3 of the original price towards a replacement product.
