- Page 5 Notes on the Documentation Chapter: Document History Beckhoff New Automation Technology CB3263-xxxx page 5...
-
Page 6: Document History
M.2 pinouts for M.2 2280 and M.2 2242 All company names, brand names, and product names referred to in this manual are registered or unregistered trademarks of their respective holders and are, as such, protected by national and international law. page 6 Beckhoff New Automation Technology CB3263-xxxx... -
Page 7: Introduction
1.1.2 Copyright © This documentation is copyrighted. Any reproduction or third party use of this publication, whether in whole or in part, without the written permission of Beckhoff Automation GmbH & Co. KG, is forbidden. Beckhoff New Automation Technology CB3263-xxxx... -
Page 8: Safety Instructions
All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. page 8... -
Page 9: Description Of Safety Symbols
1.4 FCC Approval for Canada FCC: Canadian Notice This equipment does not exceed the Class A limits for radiated emissions as described in the Radio Interference Regulations of the Canadian Department of Communications. Beckhoff New Automation Technology CB3263-xxxx page 9... -
Page 10: Essential Safety Measures
Read the operating instructions All users of the product must have read the operating instructions for the system they work with. System know-how All users must be familiar with all accessible functions of the product. page 10 Beckhoff New Automation Technology CB3263-xxxx... -
Page 11: Functional Range
As far as the described motherboard was acquired as an integral component of an Industrial PC from Beckhoff Automation GmbH & Co. KG, this product description shall be applied only in limited scope. Only the contractually agreed specifications of the corresponding Industrial PC from Beckhoff Automation GmbH &... -
Page 12: Overview
BIOS 1333 1.05V; 1.5V; 1.8V; 3.3V DVI/HDMI/DP NXP® 8x GPIO SMBus (I-PEX) PCA9535 DVI/HDMI Intel® Atom™ SMBus E3840, E3823 USB2-9 USB 2.0 SATA1-2 1.5GB/3.0GB Intel® 10/100/ LAN1-3 1000 i210 USB 3.0 SMSC® SCH3114 page 12 Beckhoff New Automation Technology CB3263-xxxx... -
Page 13: Feature List
BIOS AMI® Aptio V Power Supply 16V - 36V input voltage range Over- and undervoltage protection S-UPS connection Reverse voltage protection not galvanically isolated Format 102 mm x 147 mm Beckhoff New Automation Technology CB3263-xxxx page 13... -
Page 14: Specifications And Documents
Intel® Chip Description i210 Datasheet www.intel.com SMSC® Chip Description SCH3114 Datasheet www.smsc.com (NDA required) American Megatrends® Aptio™ Text Setup Environment (TSE) User Manual www.ami.com American Megatrends® Aptio™ 4.x Status Codes www.ami.com page 14 Beckhoff New Automation Technology CB3263-xxxx... -
Page 15: Detailed Description
M.2 cards can be easily inserted: just plug them into the slot and fix it with a fixing screw. Cards of different types have different keyings. Depending on the supported type, one port can receive add-in cards of one ore various types. Beckhoff New Automation Technology CB3263-xxxx page 15... - Page 16 For optimal driver compatibility we recommend the use of a Microsoft® Windows® 8 operating system. If you use an add-in card, which is not or not fully supported, the BIOS will display Notice an error message. page 16 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 17: Connectors
Restrictions on maximum cable length are also in place for many high Notice speed interfaces and for power supply. Please refer to the respective specifications and use suitable cables at all times. Beckhoff New Automation Technology CB3263-xxxx page 17... -
Page 18: Connector Map
35 P1005 "SATA Interface" p. 37 P1006 "S-UPS" p. 22 P1100/2/4 "LAN" p. 27 P1101/3 "USB" p. 26 P1105 "DVI / HDMI / VGA" p. 24 P1106 "Mainboard Power Supply" p. 19 page 18 Beckhoff New Automation Technology CB3263-xxxx... -
Page 19: Power Supply
2 (PC_AKTIV) is pulled from 24V to 0V. Manufacturer Description Mating Connector Phoenix P20THR-1787014 DFMC 1,5/ 2-ST-3,5-LR- 1790292 Description Name Name Description PC Start PC_START PC_AKTIV PC Status Power Supply 24V Ground Beckhoff New Automation Technology CB3263-xxxx page 19... -
Page 20: Power Supply For Peripherals (I-Pex)
FCI 90311-012LF Pinout power connector 2x6: Description Name Name Description power supply 5V power supply 5V power supply 5V ground ground ground ground ground power supply 12V ground power supply 12V power supply 12V page 20 Beckhoff New Automation Technology CB3263-xxxx... -
Page 21: Power Supply For Peripherals (Sata)
Maximum current is 2 amperes for VCC combined (2A per contact), and also 2 amperes for 12V and 3,3V (2A per contact). Manufacturer Description Mating Connector 98424-G52-08LF 90311-008LF Pinout power connector 2x4: Description Name Name Description battery (Input) BATT_E ground power supply 3,3V 3,3V ground power supply ground power supply ground Beckhoff New Automation Technology CB3263-xxxx page 21... -
Page 22: S-Ups
Molex 43025-1009 Pinout Molex 2x5: Description Name Name Description output voltage Voutreg Voutreg output voltage output voltage Vout Vout output voltage ground ground SUSV SUSV SMBALERT# SMB alert SMB data SMB-DAT SMB-CLK SMB clock page 22 Beckhoff New Automation Technology CB3263-xxxx... -
Page 23: External Cmos Battery
Power Supply Chapter: Connectors 4.2.5 External CMOS Battery The board ships with a CR2032 battery holder (Renata VBH2032-1) and 3V battery. Beckhoff New Automation Technology CB3263-xxxx page 23... -
Page 24: Front Panel Connectors
DVI data 1 - TMDSDAT1 DVI data 1 + ground reserved reserved 5 volt supply ground HP_DETECT hot plug detect TMDSDAT0# DVI data 0 - TMDSDAT0 DVI data 0 + ground reserved reserved ground page 24 Beckhoff New Automation Technology CB3263-xxxx... - Page 25 Front Panel Connectors Chapter: Connectors Name Description TMDS CLK DVI clock TMDS CLK# DVI clock C_RED VGA red C_GREEN VGA green C_BLUE VGA blue C_HSYNC VGA horizontal synchronization ground Beckhoff New Automation Technology CB3263-xxxx page 25...
-
Page 26: Usb
In ACPI state S5 via USB connected devices will not be energized. Manufacturer Description Mating Connectors Foxconn UB11121C-8D1-4F (standard connector) Pinout USB2.0 connector for channel X: Name Description 5 volt for USBX USBX# minus channel USBX USBX plus channel USBX ground page 26 Beckhoff New Automation Technology CB3263-xxxx... -
Page 27: Lan
LAN channel 1 minus LAN-3 LAN channel 3 plus LAN-3# LAN channel 3 minus The LEDs show activity and speed of data transfer: Mbit/s flashing at data transfer permanent 1000 green green green orange green Beckhoff New Automation Technology CB3263-xxxx page 27... -
Page 28: Internal Connectors
DQS1# data mask 1 data strobe 1 + DQS1 RESET# Reset ground ground data 10 DQ10 DQ14 data 14 data 11 DQ11 DQ15 data 15 ground ground data 16 DQ16 DQ20 data 20 page 28 Beckhoff New Automation Technology CB3263-xxxx... - Page 29 4 + DQS4 ground ground DQ38 data 38 data 34 DQ34 DQ39 data 39 data 35 DQ35 ground ground DQ44 data 44 data 40 DQ40 DQ45 data 45 data 41 DQ41 ground Beckhoff New Automation Technology CB3263-xxxx page 29...
- Page 30 58 DQ58 DQ62 data 62 data 59 DQ59 DQ63 data 63 ground ground SPD address 0 EVENT# Event 3.3 volt supply 3.3V SMBus data SPD address 1 SMBus clock termination current termination current page 30 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 31: 2280 (Keying B)
CONFIG_0 GPIO6 (not available) GPIO11 GPIO7 (not available) (not available) GPIO10 (not available) ground GND4 GPIO8 (not available) PER1# (not available) USB3RX# UIM_RST (not available) SSICRX# PER1 (not available) UIM_CLK (not available) USB3RX Beckhoff New Automation Technology CB3263-xxxx page 31... - Page 32 (not available) ANTCTL3 Powergood RESET# SUSCLK system clock configuration pin CFG1 3.3V3 Standby power supply S3,3V ground GND10 3.3V4 Standby power supply S3,3V ground GND11 3.3V5 Standby power supply S3,3V configuration pin CFG2 page 32 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 33: 2242 (Keying B)
GPIO6 (not available) GPIO11 GPIO7 (not available) (not available) GPIO10 (not available) ground GND4 GPIO8 (not available) PER1# (not available) (not available) USB3RX# UIM_RST SSICRX# PER1 (not available) USB3RX UIM_CLK (not available) SSICRX Beckhoff New Automation Technology CB3263-xxxx page 33... - Page 34 (not available) ANTCTL3 Powergood RESET# SUSCLK system clock Configuration pin CFG1 3.3V3 Standby power supply S3,3V ground GND10 3.3V4 Standby power supply S3,3V ground GND11 3.3V5 Standby power supply S3,3V configuration pin CFG2 page 34 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 35: Dvi/Hdmi/Displayport And Usb3.0
DVI Clock + / DP Lane 3 + reserved SEL_DVI/DP# DVI-DisplayPort Select DDCK/DPAUX EDID Clock / DP Aux + DDDA/DPAUX# EDID Data / DP Aux - 5V supply ground hot plug detect USBVCC 5V supply for USB Beckhoff New Automation Technology CB3263-xxxx page 35... - Page 36 Super Speed receiver - SSRX Super Speed receiver + USB# USB - USB + SSTX# Super Speed transmitter - SSTX Super Speed transmitter 3.3V 3.3V supply 3.3V 3.3V supply 5V supply 5V supply 5V supply page 36 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 37: Sata Interface
SATA connector. The required settings are made in the BIOS setup. Manufacturer Description Mating Connector Amphenol SATA-001-22223-CTR (standard connector) Pinout SATA: Name Description ground SATATX SATA transmit + SATATX# SATA transmit - ground SATARX SATA receive - SATARX# SATA receive + ground Beckhoff New Automation Technology CB3263-xxxx page 37... -
Page 38: Bios Settings
They do not represent the recommended settings or the default settings. Determination of the appropriate settings is dependent upon the Notice particular application scenario in which the board is used. page 38 Beckhoff New Automation Technology CB3263-xxxx... -
Page 39: Main
BayTrail SoC Options: none Total Memory Options: none System Date Options: The system date can be adjusted here. System Time Options: The system time can be adjusted here. Beckhoff New Automation Technology CB3263-xxxx page 39... -
Page 40: Advanced
Sub menu: see "Miscellaneous Configuration" (page 49) Network Stack Sub menu: see "Network Stack" (page 50) Power Controller Options Sub menu: see "Power Controller Options" (page 51) CSM Configuration Sub menu: see "CSM Configuration" (page 52) page 40 Beckhoff New Automation Technology CB3263-xxxx... - Page 41 Security Configuration Sub menu: see "Security Configuration" (page 56) Intel(R) Gigabit Network Connection Sub menu: see "Intel(R) I210 Gigabit Network Connection" (page 57) Driver Health Sub menu: see "Driver Health" (page 59) Beckhoff New Automation Technology CB3263-xxxx page 41...
-
Page 42: Acpi Settings
Enable ACPI Auto Configuration Options: Enabled / Disabled Enable Hibernation Options: Enabled / Disabled ACPI Sleep State Options: Suspend Disabled / S1 (CPU Stop Clock) Lock Legacy Resources Options: Enabled / Disabled page 42 Beckhoff New Automation Technology CB3263-xxxx... -
Page 43: H/W Monitor
│ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. CPU dig. Options: none MB Temp Options: none PwrCtrlVCC Options: none Beckhoff New Automation Technology CB3263-xxxx page 43... -
Page 44: Cpu Configuration
CPU Speed Options: none 64-bit Options: none Limit CPUID Maximum Options: Enabled / Disabled Execute Disable Bit Options: Enabled / Disabled Intel Virtualization Technology Options: Enabled / Disabled page 44 Beckhoff New Automation Technology CB3263-xxxx... - Page 45 Intel HT Technology Options: none Intel VT-x Technology Options: none L1 Data Cache Options: none L1 Code Cache Options: none L2 Cache Options: none L3 Cache Options: none Beckhoff New Automation Technology CB3263-xxxx page 45...
- Page 46 │F4: Save & Exit │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. DTS Options: Enabled / Disabled page 46 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 47: Ppm Configuration
Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. CPU C state Report Options: Disabled / Enabled Max CPU C-state Options: C7 / C6 / C1 S0ix Options: Disabled / Enabled Beckhoff New Automation Technology CB3263-xxxx page 47... -
Page 48: Sata Configuration
Gen1 / Gen2 SATA ODD Port Options: Port0 ODD / Port1 ODD / No ODD SATA Mode Options: IDE Mode / AHCI Mode Serial-ATA Port X Options: Enabled / Disabled page 48 Beckhoff New Automation Technology CB3263-xxxx... -
Page 49: Miscellaneous Configuration
Options: Disabled / Enabled Boot Timer with HPET Timer Options: Enabled / Disabled PCI Express Dynamic Clock Gating Options: Enabled / Disabled OS Selection Options: Windows 8.X / Windows 7 Beckhoff New Automation Technology CB3263-xxxx page 49... -
Page 50: Network Stack
Options: Disabled / Enabled IPv4 PXE Support Options: Disabled / Enabled IPv6 PXE Support Options: Disabled / Enabled PXE boot wait time Options: 0..5 Media detect count Options: none page 50 Beckhoff New Automation Technology CB3263-xxxx... -
Page 51: Power Controller Options
Mainboard Serial No Options: none Mainboard Prod. Date (Week.Year) Options: none Mainboard Boot Count Options: none Mainboard Operation Time Options: none Voltage (Min/Max) Options: none Temperature (Min/Max) Options: none Beckhoff New Automation Technology CB3263-xxxx page 51... -
Page 52: Csm Configuration
Storage Options: Do not launch / UEFI only / Legacy only Video Options: Do not launch / UEFI only / Legacy only Other PCI devices Options: UEFI only / Legacy only page 52 Beckhoff New Automation Technology CB3263-xxxx... -
Page 53: Advanced-Menü-Nvme Configuration
│ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. NVMe controller and Drive information Options: none Beckhoff New Automation Technology CB3263-xxxx page 53... -
Page 54: Sdio Configuration
│ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. SDIO Access Mode Options: Auto / DMA / PIO page 54 Beckhoff New Automation Technology CB3263-xxxx... -
Page 55: Usb Configuration
5 sec / 10 sec / 20 sec Device reset time-out Options: 10 sec / 20 sec / 30 sec / 40 sec Device power-up delay Options: Auto / Manual Device power-up delay in seconds Options: 1..40 Beckhoff New Automation Technology CB3263-xxxx page 55... -
Page 56: Security Configuration
Options: Enabled / Disabled TXE HMRFPO Options: Enabled / Disabled TXE Firmware Update Options: Enabled / Disabled TXE EOP Message Options: Enabled / Disabled TXE Unconfiguration Perform Options: none page 56 Beckhoff New Automation Technology CB3263-xxxx... -
Page 57: Intel(R) I210 Gigabit Network Connection
Chip Type Options: none PCI Device ID Options: none PCI Address Options: none Link Status Options: none MAC Address Options: none Virtual MAC Address Options: none Beckhoff New Automation Technology CB3263-xxxx page 57... - Page 58 Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. Link Speed Options: Auto Negotiated / 10Mbps Half / 10Mbps full / 100Mbps Half / 100Mbps Full Wake On LAN Options: Enabled / Disabled page 58 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 59: Driver Health
│ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. Intel(R) PRO/1000 5.7.06 PCI-E Sub menu: see "Intel(R) PRO/1000 PCI-E" (page 60) Beckhoff New Automation Technology CB3263-xxxx page 59... - Page 60 │ │ │ESC: Exit │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. Controller x Child n Options: none page 60 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 61: Chipset
│ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. North Bridge Sub menu: see "North Bridge" (page 62) South Bridge Sub menu: see "South Bridge" (page 66) Beckhoff New Automation Technology CB3263-xxxx page 61... -
Page 62: North Bridge
Graphics Power Management Control Sub menu: see "Graphics Power Management Control" (page 65) Total Memory Options: none Memory SlotX Options: none Max TOLUD Options: Dynamic / 1GB / 1.25GB / .. / 3GB page 62 Beckhoff New Automation Technology CB3263-xxxx... - Page 63 128MB / 256MB / 512MB DOP CG Options: Enabled / Disabled GTT Size Options: 1MB / 2MB Spread Spectrum clock Options: Enabled / Disabled ISP Enable/ Disable Options: Enabled / Disabled Beckhoff New Automation Technology CB3263-xxxx page 63...
- Page 64 Chapter: BIOS Settings Chipset ISP PCI Device Selection Options: Disabled / ISP PCI Device as B0D2F0 / ISP PCI Device as B0D3F0 Vcc_Vnn Config for Power state2 Options: Enabled / Disabled page 64 Beckhoff New Automation Technology CB3263-xxxx...
- Page 65 │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. RC6 (Render Standby) Options: Enabled / Disabled Beckhoff New Automation Technology CB3263-xxxx page 65...
-
Page 66: South Bridge
Restore AC Power Loss Options: Power Off / Power On / Last State Onboard Gigabit LAN X Options: Enabled / Disabled M.2-PCIe Configuration Pins Options: none M.2-SATA Configuration Pins Options: none page 66 Beckhoff New Automation Technology CB3263-xxxx... - Page 67 Disabled / Enabled Azalia VCi Enable Options: Disabled / Enabled Azalia PME Enable Options: Disabled / Enabled Azalia HDMI Codec Options: Disabled / Enabled HDMI Port X Options: Disabled / Enabled Beckhoff New Automation Technology CB3263-xxxx page 67...
- Page 68 └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. USB Mode Options: EHCI / XHCI USB Per Port Control Options: Enabled / Disabled USB Port x Options: Disabled / Enabled page 68 Beckhoff New Automation Technology CB3263-xxxx...
- Page 69 │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. PCIe Port x is assigned to Options: none Beckhoff New Automation Technology CB3263-xxxx page 69...
-
Page 70: Security
│ │ │ │ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. Secure Boot menu Sub menu: see "Secure Boot menu" (page 71) page 70 Beckhoff New Automation Technology CB3263-xxxx... -
Page 71: Secure Boot Menu
System Mode Options: none Secure Boot Options: none Vendor Keys Options: none Secure Boot Mode Options: Standard / Custom Key Management Sub menu: see "Key Management" (page 72) Beckhoff New Automation Technology CB3263-xxxx page 71... - Page 72 Set New Key / Append Key Authorized Signatures Options: Set New Key / Append Key Forbidden Signatures Options: Set New Key / Append Key Authorized TimeStamps Options: Set New Key / Append Key page 72 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 73: Boot
Legacy / UEFI / DUAL Fixed Boot Order Priorities Options: Review or change the sequence of available boot devices Advanced Fixed Boot Order Parameters Sub menu: see "Advanced Fixed Boot Order Parameters" (page 74) Beckhoff New Automation Technology CB3263-xxxx page 73... -
Page 74: Advanced Fixed Boot Order Parameters
│ │ │ │ │ │ │ │ │ └─────────────────────────────────────────────────────────────────┴────────────────────────────────┘ Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. Max. CFast/SSD capacity (GB) Options: none Max USB Stick capacity (GB) Options: none page 74 Beckhoff New Automation Technology CB3263-xxxx... -
Page 75: Save & Exit
Version 2.17.1249. Copyright (C) 2016 American Megatrends, Inc. Save Changes and Reset Options: Press [Enter] Discard Changes and Reset Options: Press [Enter] Restore Defaults Options: Press [Enter] Reset System with ME disable ModeMEUD000 Options: Press [Enter] Beckhoff New Automation Technology CB3263-xxxx page 75... -
Page 76: Bios-Update
BIOS file which was issued for the exact board and exact board revision that you wish to update. If you try to update the BIOS using the wrong file the board will not start up again. page 76 Beckhoff New Automation Technology CB3263-xxxx... -
Page 77: Mechanical Drawings
6 Mechanical Drawings All dimensions are in mil (1 mil = 0,0254 mm). Notice 6.1 PCB: Mounting Holes A true dimensioned drawing can be found in the PC/104 specification. 1102 1300 2750 3858 Beckhoff New Automation Technology CB3263-xxxx page 77... -
Page 78: Pcb: Die Center
Chapter: Mechanical Drawings PCB: Die Center 6.2 PCB: Die Center page 78 Beckhoff New Automation Technology CB3263-xxxx... -
Page 79: Pcb: Pin 1 Dimensions
PCB: Pin 1 Dimensions Chapter: Mechanical Drawings 6.3 PCB: Pin 1 Dimensions 2465 1761 Beckhoff New Automation Technology CB3263-xxxx page 79... -
Page 80: Pcb: Outlines
Chapter: Mechanical Drawings PCB: Outlines 6.4 PCB: Outlines 4016 page 80 Beckhoff New Automation Technology CB3263-xxxx... -
Page 81: Technical Data
9 up to 500Hz, 10m/s , for packaged boards Shock and vibration Shock and vibration figures pertain to the motherboard alone and do not include additional components such as heat sinks, memory modules, cables etc. Notice Beckhoff New Automation Technology CB3263-xxxx page 81... -
Page 82: Thermal Specifications
100°C. Permanent overheating may destroy the board! CAUTION In case the temperature exceeds 100°C the environmental temperature must be reduced. Under certain circumstances sufficient air circulation must be provided. page 82 Beckhoff New Automation Technology CB3263-xxxx... -
Page 83: Support And Service
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products. The addresses of Beckhoff's branch offices and representatives around the world can be found on her internet pages: http://www.beckhoff.com You will also find further documentation for Beckhoff components there. - Page 84 Annex: Post-Codes page 84 Beckhoff New Automation Technology CB3263-xxxx...
-
Page 85: I Annex: Post-Codes
(POST code card). The meaning of these codes is described in the document "Aptio™ 4.x Status Codes" by American Megatrends®, which can be downloaded from their website http://www.ami.com. The following additional OEM POST codes are generated: Code Description BIOS-API started PCA9535 started PWRCTRL-Firmware started Beckhoff New Automation Technology CB3263-xxxx page 85... -
Page 86: Annex: Resources
The exclusivity is not given and not possible on the PCI side. Adress Function IRQ0 Timer IRQ1 PS/2 Keyboard IRQ2 (8) IRQ3 COM2 IRQ4 COM1 IRQ5 IRQ6 IRQ7 IRQ8 IRQ9 IRQ10 IRQ11 IRQ12 IRQ13 page 86 Beckhoff New Automation Technology CB3263-xxxx... -
Page 87: Pci Devices
Address Function 10-11 Standard slave address 40-41 GPIO 60-61 BIOS internal 70-73 POST code output 88-89 BIOS-defined slave address A0-A1 DIMM 1 A2-A3 DIMM 2 A4-AF BIOS internal B0-BF BIOS internal D2-D3 Clock Beckhoff New Automation Technology CB3263-xxxx page 87...
