Lexicon CP-1 Digital Audio Environment Processor Quick Reference Guide

The Rear Panel

Push Phantom/In if you have no center channel; leave it out if a center speaker is connected.
Leaving this button out with no center channel will cause the Surround programs to malfunction.
Configuration
Center Phantom
Button IN
1
Center Phantom
Button IN
4
7
10
Choose the diagram that most closely corresponds
to your room and note its number.
3 Oak Park
Bedford, MA 01730 USA
Lexicon Part # 070-06620 Rev. 1.0
Center Phantom
2
Center Phantom
Button IN
5
Center Phantom
8
Center Phantom
11
LEVEL
REAR SIDE MAIN CENTER
L L
OUTPUTS
R R
SUB WOOFER
Press BANK and hold for five seconds. The
display will read: LCD CONTRAST ADJ. The CP-
1 is now in Configuration mode.
Button IN
• Use PARAM UP or DOWN to adjust display
contrast.
Push PARAM to select the Speaker Configuration
3
menu.
• Push PARAM UP or DOWN until the configura-
tion you have chosen and the description in the
display match.
6
Button IN
9
Button IN
If you are using only one rear speaker it may be
hooked up to either the left or right rear output, as
long as you use the correct Configuration number.
12
Subwoofers are not shown in any of these configu-
rations. Consult the subwoofer owner's manual or
your dealer for proper placement of subwoofers.
TAPE TAPE
SUB INPUTS
II I
OUT IN
L
L
CENTER/OUT
PHANTOM/IN
R
R
speaker connected to
center output
speakers connected to
Main outputs
speakers connected to
Side outputs
speakers connected to
Rear outputs
Patents are pending on the CP-1
© 1988 Lexicon, Inc.
