- Page 1 ASSEMBLY INSTRUCTIONS indi doublewide dresser/changer a how-to guide that won’t leave you in tears...
- Page 2 parenting is hard. this is easy. no really, it is. MADE HERE™ MADE WELL™ MADE SAFE MADE SMART...
- Page 3 want to watch this assembly IRL? (acronym challenged? that means “in real life”.) open the camera on your phone and place it over the QR code below to see our NYC studio dream team do all the heavy lifting (just kidding, there is none!) or go to ducducnyc.com/pages/assembly-instructions...
- Page 4 thank you for selecting a studio duc product!
-
Page 5: Care And Cleaning
If any components are missing or We recommend the use of a Colgate 3-Sided contour Pad (CR300-S80) if this you find any damage, please contact ducduc before continuing. dresser is to be used as a changing table. -
Page 6: What's In The Box
WHAT’S IN THE BOX: L side panel R side panel center partition back upper panel F (x4) G (x4) foot JCB bolt (25mm) back lower panel tray stretcher hammer cap allen key (4mm) block foot bottom... - Page 7 DB1 (x6) drawer face safety strap kit (with hardware) DB2 (x6) drawer box back allen key (3mm) DB3 (x6) DB4 (x6) L drawer box side R drawer box side M (x2) confirmat screw for stretcher DB5 (x6) drawer box bottom DB6 (x6) DB7 (x12) indi pull...
-
Page 8: What You'll Need
WHAT YOU’LL NEED: household hammer or phillips head screwdriver rubber mallet 20 minutes a soft surface to assemble on (or less) (like a rug or some of the corrugate box your piece arrived in) 2 people plus a dog for moral support (unless you’re a cat person) - Page 9 lean bottom (D) against a wall as shown. important! be sure the 2 small holes on the bottom are facing away from the wall using the provided allen key (I) and JCB bolts (G), attach feet (F) to bottom (D). important! be sure the JBC bolts are attached to the side of the...
- Page 10 insert connectors on block foot (J) into holes on bottom (D). tap with hammer and hammer cap (H) to lock into place. flip the assembled base around so the feet are facing the wall. insert connectors on center partition (A3) into slots on bottom (D) and push down to lock into place. important! when attaching the bottom and center...
- Page 11 insert remaining connectors on center partition (A3) into slots on top (E) and push down at the connection to lock into place. set assembled pieces aside for now. important! follow stickers on top panel (E) to install panel in the correct orientation. lean L side panel (A1) against a wall as shown.
- Page 12 insert connectors on back lower panel (B2) lower 2 slots on L side panel (A1). push down at the connection to lock into place. important! follow stickers on both back upper panel (B1) and back lower panel (B2) to install panels in the correct orientation.
- Page 13 insert connectors on both back panels (B1 + B2) into slots on R side panel (A2). push down at the connection to lock into place. gently lay the partially assembled case on its back and have a friend gently flare the side panels (A1 + A2) outward as shown.
- Page 14 with the side panels flared outward, insert connectors of assembled base (D, F, +J) and top (E) into slots on R side panel (A2). important! follow stickers on components A3, E, + D to install panels in the correct orientation. important! when attaching these components, make sure...
- Page 15 insert remaining connectors insert connectors of assembled base (D, F, +J) and top (E) into slots on L side panel (A1). once all connectors and slots are lined up and side panels are back to square position, apply hammer cap (H) to the head of a household hammer and tap bottom (D) and top (E) until there is no gap at the connection to back panels (B1 + B2).
- Page 16 with a friend, rotate the assembled case into upright position. position tray stretcher (C) between two side panels (A1 + A2) as shown. once the connectors on tray stretch- er (C) are lined up with the holes on top (E), use hammer with hammer cap (G) to tap until secure.
- Page 17 now we build the drawers! starting with drawer face (DB1) facing down, insert connectors of both drawer box side panels (DB3 + DB4) into slots on drawer face (DB1). push down at the connections to lock into place. rotate the partially assembled drawer box as shown. slide drawer box bottom (DB5) into place using grooves on the drawer box side panels (DB3 + DB4) as guides.
- Page 18 using a phillips screwdriver and screws (DB7), attach the pull hardware (DB6) to the front of each drawer face. build remaining drawers using steps 11a, 11b, 11c, and 11d.
- Page 19 starting at the top, pull drawer glides out to extended position as shown.
- Page 20 place one assembled drawer box onto extended glides as shown. from underside of drawer, use hands to pull each glide forward until it locks into connection with glide hardware attached to drawer box bottom (DB5). the drawer will be secure when you hear a click on each connection.
- Page 21 repeat steps 13a + 13b to install the remaining drawers.
- Page 22 safety strap installation Important! Do not skip this step. Furniture tipping over is a serious threat to children’s safety. the last step for your dresser/changer is to install the safety strap included in the box. ref- erence the separate instructions enclosed in the envelope.
- Page 23 yippee! you did it! give yourself a pat on the back, take a bow, or go house a pint of ice cream…we don’t judge.
- Page 24 prefer to talk to a human instead? we’re here for you! contact our customer advocate team below: 212.226.1868 quack@ducducnyc.com live chat at 200 lexington, avenue ducducnyc.com ny, ny 10016...
