4. Installation instructions

step 1. Clip the attachment hooks for the body support into the swivel hook.
1
step 2. To suspend the body support from the hooks, lower the
swivel hook to eye level and press the body support against
your body with one hand so the cups touch each other and
you can fit the hooks into the ends of the hollow body
support tubes.
step 3. Attach the thigh support bands through the thigh support fix:
Pull the loose end of the thigh support band through the under-
side of the thigh support fix (in between both legs of the thigh support fix).
Wrap the loose end around the bar and subsequently through the underside of the thigh support fix
again.
Note! The markings on the band and strap should point outwards.
Pull the loose end of the band through the back of the strap.
1
4
SUREHANDS
2
2
5
®
BODY SUPPORT
3
3
6
4
EN p. 7
