- Page 1 CANEO CANEO Original operating instructions Original operating instructions series43 Hygienic series43 Hygienic series43 Hygienic Display series43 Hygienic Display...
-
Page 2: Table Of Contents
Table of Contents Foreword..................3 Safety................... 3 General safety................3 Notes and symbols used............3 Personnel qualifications............4 Intended use................5 Reasonably foreseeable misuse..........5 General description..............6 Assembly..................6 Prepare for assembly............... 6 Attaching the SENSORswitch..........6 Maintenance................. 7 Maintenance operations............7 Disassembly................. -
Page 3: Foreword
Foreword These operating instructions are intended for technicians/installers and operators and should be kept for future reference. Read these operating instructions carefully and make sure that you have fully understood the contents before installing or working with the SENSORswitches. Metric and imperial measurements are used in drawings. Imperial measurements are marked with [ ]. -
Page 4: Personnel Qualifications
WARNING Warning designates a hazardous situation, which, if ignored, may lead to death or serious injury. The symbol next to the warning indicates the type and source of the danger. CAUTION Caution designates a hazardous situation, which, if ignored, may lead to injury. The symbol next to the warning indicates the type and source of the danger. -
Page 5: Intended Use
standards, who can evaluate the work assigned to them correspondingly and recognize potential risks. WARNING Improper work on electrical systems! Electric shock can result in death or life- threatening injuries. Before working on electrical systems, disconnect them from their voltage supply and secure them against being switched on again. -
Page 6: General Description
General description The supplied SENSORswitch can have options that differ from those shown in this manual. This does not affect the function. The SENSORswitch is equipped with different color LEDs to indicate operating conditions. The LEDs are actuated differently depending on the pin configuration. -
Page 7: Maintenance
► Clean the surface with cleaning cloth A. ► Dry the surface with a lint-free cloth. ► Clean the surface with cleaning cloth B. ► Dry the surface with a lint-free cloth. ► Depending on the installation position, you now need to connect the SENSORswitch electrically to connection (B). -
Page 8: Disposal
► Disconnect the system from its voltage supply and secure it against being switched on again. ► Evenly heat the SENSORswitch and the subsurface using a hot air fan. ► Remove the SENSORswitch from the subsurface using a glass scraper. ►... -
Page 9: Connection Options
Connection options Plug M12, 3-pin Plug M12, 4-pin Plug M12, 5-pin Connection plan 3-pin brown +VDC black IO - Link Communication (NPN / PNP NO / NC) blue The product description will indicate the configuration. - Page 10 4-pin white brown +VDC black IO - Link Communication (NPN / PNP NO / NC) blue The product description will indicate the configuration. 5-pin white gray brown +VDC black IO-Link communication (NPN / PNP NO / NC) blue The product description will indicate the configuration.
-
Page 11: Drilling Pattern
Drilling pattern ±0,50 3,15 ±0,02 Metric and imperial measurements are used in drawings. Imperial measurements are marked with [ ]. -
Page 12: Dimensional Drawing
Dimensional drawing M12 x 1 3,94 Metric and imperial measurements are used in drawings. Imperial measurements are marked with [ ]. -
Page 13: Manual Updates
Manual updates CAPTRON reserves the right to make changes to the contents of this manual as needed. The most current version can be found on our website www.captron.com Imprint The operating instructions have been authored and published by CAPTRON Electronic GmbH Johann-G.-Gutenberg-Straße 7... - Page 14 Product description / Product description...
