Gas Spring Monitor Desk mount
SA-GM112D
Installation Video
Thank you for choosing our p roduct. ShoppingAll is dedicated to providing
the highest level of quality and service to our customers. If you are satisfied
with the item , would you kindly share your feedback on Amazon ?
Please do not hesitate to contact us if you have any issue.
Call: +1 (855) 266-9166
Mon-Fri 8:00am – 9:00pm (Eastern Time) (Canada/USA)
Email: Support@ShoppingAll.com
Website: www.ShoppingAll.com
Tilt
VESA
Rotate
Swivel
Load
15" - 32"
0-8kgs/0-17.6lbs
75x75, 100x100
-90°/+85°
180°
360°
Advertisement
Table of Contents
Related Manuals for SHOPPINGALL SA-GM112D
Summary of Contents for SHOPPINGALL SA-GM112D
- Page 1 SA-GM112D Installation Video Thank you for choosing our p roduct. ShoppingAll is dedicated to providing the highest level of quality and service to our customers. If you are satisfied with the item , would you kindly share your feedback on Amazon ? Please do not hesitate to contact us if you have any issue.
- Page 2 WARNING STATEMENTS Warning Prior to the installation of this product, the installation instruction must be read and completely understood. Failure to do so may result in personal injury, property damage or voiding of manufacturer warranty. Do not install on a structure that is prone to vibration, or movement. Reinforce the structure as required before installation.
- Page 3 PARTS INCLUDED M4x8 (x4) M4x12 (x4) M4x30 (x4) 12X5.8X16 (x4) (x1) M6x25 (x1) (x1) (x1) (x1) (x1) S=3mm S=4mm S=5mm Extra screw (x2) (x1)
- Page 4 Clamp Installation Steps S=3mm ① ② S=4mm S=5mm ③ ④ For desk thickness more than 2.36"(60mm) but within 3.35"(85mm), remove clamp screw and attachment entirely and reattach clamp screw with bottom plate upside-down. ① ② ③ S=4mm S=4mm ④ S=5mm...
- Page 5 Grommet Installation Steps S=4mm S=3mm S=4mm ① ② S=5mm S=5mm ③ ④ Remove Clamp from the base Install Grommet (Part E) to the base S=4mm S=4mm ⑤ ⑥ S=5mm...
- Page 6 Arm Installation Adjust the height adjustment ring at proper height and screw uptight to the pole. Put on the spring arm to the pole. Insert and fasten the screw from the bottom of the arm joint to the plastic Connection Cap . M6x25 S=4mm Adjust the Height Adjustment Ring at proper height and screw uptight to...
- Page 7 Monitor Installation M4x8 12X5.8X16 M4x12 M4x30 S=4mm S=4mm S=4mm Gas Spring Tension Adjustment Press down the arm to a horizontal position S=5mm 1 turn ≈ 1 lbs ≈ 0.4kg NOTE: Turn clockwise to reduce tension for lighter monitors and counter-clockwise to increase tension for heavier monitors.
- Page 8 Tilt & Swivel Adjustment VESA Tilt Adjustment VESA Swivel Adjustment S=3mm S=5mm S=5mm S=5mm Arm Swivel S=3mm Adjustment Tighten the bolt with the Allen Key to make the tilt and swivel adjustment. Cable Management Installation S=3mm S=4mm S=5mm S=3mm S=4mm S=5mm Use the cable clip to manage the wrenches when not used.
