Monitor Desk mount
SA-D29
Product Information
Thank you for choosing our p roduct. ShoppingAll is
dedicated to providing the highest level of quality and
service to our customers. If you are satisfied with the item ,
would you kindly share your feedback on Amazon ?
Please do not hesitate to contact us if you have any issue.
Call: +1 (855) 266-9166
Mon-Fri 8:00am – 9:00pm (Eastern Time) (Canada/USA)
Email: Support@ShoppingAll.com
Website: www.ShoppingAll.com
8kg(17.6lbs) max.
13" - 32"(33-81cm) .
WARNING STATEMENTS
Warning
Prior to the installation of this product, the
installation instruction must be read and
completely understood.
Failure to do so may result in personal
injury, property damage or voiding of
manufacturer warranty.
Do not install on a structure that is prone to
vibration, or movement. Reinforce the
structure as required before installation.
Recommended mounting surfaces: Wooden
studs or solid-flat concrete. If the mount is to
be installed on any surface other than wooden
studs, use suitable hardware.
Pay attention to the weight capacity of the
mount. Exceeding the limitation can result
in impairment or serious injury and property
damage.
Never operate the mount if parts are
missing or damaged. Contact your local
service center for warranty service.
Do not use this product for any purpose or
in any configuration not explicitly specified
in this instruction. We hereby disclaim any
and all liability for injury or damage arising
from incorrect assembly, Incorrect
mounting, or incorrect use of this product.
PARTS INCLUDED
A
M4x8 (x8)
M4x12 (x8)
M4x30 (x8)
B
12X5.8X16 (x8)
S=4mm
(x1)
C
(x1)
D
(x4)
E
M6x70(x2)
M6x15(x3)
F
(x2)
G
(x1)
H
I
UP
J
S=5mm
(x1)
UP
