Satco Nuvo S8030 Installation And Safety Instructions

24' & 60' LED STRING LIGHT SETS
Model: S8030, S8032, S8034, S8035, S8036, S8037, S8038, S8039
INSTALLATION AND SAFETY INSTRUCTIONS
IMPORTANT: Read before installing fixture. Retain for future reference.
PACKAGE CONTENTS:
• 24 or 60 ft. heavy duty string light with 12 or 24 sockets.
WARNING – SAFETY INFORMATION:
• NEVER use with an extension cord unless the plug can
be fully inserted. DO NOT alter the plug.
• To reduce the risk of electric shock, DO NOT use the product
if power cord is frayed or broken.
• Always unplug this product before replacing bulbs.
• Do not overload. Each string light set is rated for wattage and number of sets
connectable end-to-end. Please see chart for maximum wattage per set and
number of sets of the same type that can be connected end-to-end.
• Risk of Fire: DO NOT use bulbs having a wattage greater than the maximum
value stated on the product.
• If replacing bulbs, please contact Satco customer service at Satco.com/support.
• For indoor and outdoor use.
• To reduce the likelihood of excessive heat and possible damage, use only
decorative LED lamps packaged with this product.
• Always unplug this product before installing or replacing fused and/or lamps.
• This is an electric product – not a toy! To avoid risk of fire, burns, personal injury
and electric shock, it should not be played with or placed where small children
can reach it.
INSTALLATION:
NOTE: DO NOT DRAPE CORD. KEEP AWAY FROM CHILDREN.
Before beginning installation of product, make sure all parts
are present. If any part is missing or damaged, do not attempt
to install the product. No tools are required for installation.
1. Carefully unpack string lights from box.
2. Straighten string lights, eliminating any kinks before using.
3. Each string light is designed with a universal keyhole for mounting with lights hanging
downward. Hardware options (not included) screws, nails, zip ties, hooks and more.
4. Before plugging power cord of lights into a wall outlet, make sure each light bulb is
securely fastened.To ensure the lamp, socket, and rubber gasket make a water tight
seal, screw the lamp in secure enough for all components to make contact.
If a bulb does not light when energized, apply another ½ turn until it does.
DANGER: If using this light in a WET or DAMP location, connect this product to a
Ground Fault Circuit interrupting (GFCI) outlet to reduce the risk of personal injury, electrical shock
or death. If one is not provided, contact a qualified electrician for proper installation.
INSTALLING MULTIPLE STRING LIGHT SETS:
NOTE: Always unplug string light from outlet before connecting additional string lights.
Extend the length of your lights by connecting more than one strand together to form one continuous string up to 720 feet (30 sets)!
Simply follow the above installation steps making sure each connection between strands is secured and the end female receptacle is
securely covered using the receptacle cover when done.
Connection Jack
CARE AND MAINTENANCE: Clean only with a dry, soft cloth. Do NOT use abrasive cleaners.
Problem: Light does not come on initially or no longer comes on.
Possible Causes: Bulb is burned out. Power is OFF. Lamp is not plugged in.
Corrective Actions: Replace bulb. Make sure power supply in ON. Plug lamp into outlet.
© Copyright 2022 Satco Products, Inc. 3/22
Female Male
Before Connecting
Max
Item Max Connectable sets
Wattage/set
S8030 12W CONNECT UP TO 240 FEET (10 SETS)
S8032 24W CONNECT UP TO 300 FEET (5 SETS)
S8034 24W
CONNECT UP TO 168 FEET (7 SETS)
S8035 132W CONNECT UP TO 72 FEET (3 SETS)
S8036 24W CONNECT UP TO 168 FEET (7 SETS)
S8037 24W CONNECT UP TO 240 FEET (10 SETS)
S8038 12W CONNECT UP TO 240 FEET (10 SETS)
S8039 132W
CONNECT UP TO 240 FEET
(10 SETS LED)
(3 SETS INCANDESCENT)
Female Male
After Connecting
Satco Products, Inc.
Brentwood, NY 11717
