HP Pavilion FX75
Flat Panel Display
User's Guide
Filename: fx75UGrw.doc
Title: Book Title
Template: HP-Print.dot
Author: WASSER, Inc.
Last Saved By: WASSER, Inc.
Revision #: 30
Page: 1 of 43
Printed: 10/16/00 03:31 PM

Advertisement

Table of Contents
loading

Related Manuals for HP Pavilion FX75

Summary of Contents for HP Pavilion FX75

  • Page 1 All manuals and user guides at all-guides.com HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 1 of 43 Printed: 10/16/00 03:31 PM...
  • Page 2 HP assumes no responsibility for the use or reliability of its software on equipment that is not furnished by HP. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of HP.

  • Page 3: Table Of Contents

    FCC Statement..................... 37 Caring For and Cleaning the Display ............15 General Notice .....................38 Contents Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 3 of 43 Printed: 10/16/00 03:31 PM...
  • Page 4 All manuals and user guides at all-guides.com HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 4 of 43 Printed: 10/16/00 03:31 PM...

  • Page 5: Introduction

    FX75 Flat Panel Display. This display has a 15-inch active matrix TFT (thin film transistor) liquid crystal display module. It is designed for use with HP Pavilion PCs and is compatible with other Windows®- based computers. The display’s compact footprint, with the integrated stereo speaker base, provides great space savings on your computer desk.

  • Page 6: For Your Safety

    Microsoft® Windows display to rain or moisture. N Compliance with Swedish MPR II guidelines for reduced electromagnetic emissions HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 7 N The display has been dropped or the cabinet has been damaged. Introduction Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 3 of 43 Printed: 10/16/00 03:31 PM...

  • Page 8: Installation

    Installation N Unpacking the display N Positioning the display N Connecting the power and video cables N Connecting the stereo speaker system HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.

  • Page 9: Unpacking The Display

    All manuals and user guides at all-guides.com Positioning the Display Follow the instructions in this chapter to install your HP Pavilion FX75 Flat Panel Display. Place the display on a flat, sturdy surface. Choose an area free from excessive heat, moisture, and...

  • Page 10: Connecting The Power And Video Cables

    Analog Video Input port Digital Video Input port HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 6 of 43 Printed: 10/16/00 03:31 PM...
  • Page 11 Digital Video Input port on the display. Connect the other end of the video cable into your computer video port. If you have an HP Pavilion PC, the video cable plug is color-coded to match the port label on the PC. (For other PCs, check the computer documentation if you’re not...

  • Page 12: Connecting The Stereo Speaker System

    Note: These speakers are designed to work with sound Speakerbase plug cards that have amplified sound output; most HP Pavilion PCs have this type of sound card. Refer to your PC specifications for information Subwoofer connector about your sound card.
  • Page 13 (The jack is colored blue to match the If you have an HP Pavilion PC, the speaker cable plug.) plug is color-coded to match the port label on the PC.

  • Page 14: Using The Display

    N Tilting the display N Setting the video mode N Setting the refresh rate N Minimizing energy use N Caring for and cleaning the display HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.

  • Page 15: Turning The Display On And Off

    All manuals and user guides at all-guides.com This chapter contains information about using your HP Pavilion FX75 Flat Panel Display. Turning the Display On and Off Use the Power button on the front of the display to turn the display on and off. When the display is on, the light near the Power button is illuminated.

  • Page 16: Tilting The Display

    Grasp here to tilt FX75 display. If the display will not be used for an extended period, be sure to turn it off. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.

  • Page 17: Setting The Video Mode

    Using the Display Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 13 of 43...

  • Page 18: Setting The Refresh Rate

    75 Hz refresh rates for Refresh rate field. best performance. Click OK. Click OK again. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc.

  • Page 19: Minimizing Energy Use

    All manuals and user guides at all-guides.com Minimizing Energy Use Caring For and Cleaning the Display Many computers, including HP Pavilion PCs, support industry standard power-save signaling techniques. To maximize screen life and prevent damage to the Power management features reduce the display’s...
  • Page 20 Make sure the LCD panel is completely dry before you turn the display back on. Plug in the display. Turn on your computer and display. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.

  • Page 21: Changing Display Settings

    N Selecting options in the OSD window N Using Auto Setup N Adjusting the image Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 17 of 43 Printed: 10/16/00 03:31 PM...

  • Page 22: Using The Control Buttons

    Displaying the OSD Window Use the OSD feature to change the screen settings. To display the OSD window: N Press the Select button under the display. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 23 Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 19 of 43...

  • Page 24: Selecting Options In The Osd Window

    The other options display either another window of choices or an adjustment bar at the bottom of the OSD main window as shown. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.

  • Page 25: Using Auto Setup

    Press the Select button under the display to open the OSD main window. Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 21 of 43 Printed: 10/16/00 03:31 PM...

  • Page 26: Adjusting The Image

    Select button. For more information about adjusting the phase, see “Adjusting the Phase and Clock” on page 30. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 27 An adjustment bar appears at the bottom of Advanced Settings” on page 30. the window. Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 23 of 43 Printed: 10/16/00 03:31 PM...
  • Page 28 Full screen is the default mode. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 29 There are three degrees of sharpening: High, Medium, and Low. Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 25 of 43...
  • Page 30 RGB Adjust, and Black Level Adjust. Press the Select button. Press the + or — buttons until the Color function is highlighted. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 31 Press the + or — buttons to highlight Color Temp. Press the Select button. Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 27 of 43 Printed: 10/16/00 03:31 PM...
  • Page 32 Highlight the color you want to adjust: Red, The Black Level Adjust option sets the black level for Green, or Blue. red, green, and blue. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 33 See “Saving and Restoring Color Settings” on page 29. Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 29 of 43 Printed: 10/16/00 03:31 PM...
  • Page 34 If you need to adjust both the clock and the vertical screen distortion. To adjust the apparent phase, make sure you adjust the clock first. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.
  • Page 35 To exit the OSD, select Exit on each OSD window or wait for the OSD to close automatically. Changing Display Settings Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 31 of 43...

  • Page 36: Troubleshooting

    Try the next item on this list.) N Make sure the other end of your video cable is plugged into the computer’s video port. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot...
  • Page 37 N Run the Auto Setup routine. See “Using Auto to increase the volume. Setup” on page 21. Troubleshooting Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 33 of 43 Printed: 10/16/00 03:31 PM...

  • Page 38: Technical Information

    5 watts RMS (maximum) Input jack stereo 1/8-inch mini-jack input Maximum power 42 W consumption HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30...

  • Page 39: Fx75 Video Modes

    For optimal performance, set your PC to a screen standard display modes. resolution of 1024 x 768 at a 75 Hz refresh rate. Your HP Pavilion FX75 display has state-of-the-art Supported Resolution Vertical Frequency technology which is designed to synchronize to any...

  • Page 40: Regulatory Information

    Cupertino, CA 95015-4010 Supplementary Information: (Phone: 408-343-5000) The product herewith complies with the requirements of the following Directives and carries the CE marking accordingly. HP Pavilion FX75 Flat Panel Display User’s Guide Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc.

  • Page 41: Fcc Statement

    If this equipment tests were conducted with HP-supported peripheral does cause harmful interference to radio or television devices and HP shielded cables, such as those you reception, which can be determined by turning the received with your system. Cables used with this...

  • Page 42: General Notice

    All manuals and user guides at all-guides.com General Notice The HP Pavilion FX75 Flat Panel Display has been tested according to MPR 1990:8 for emission properties, and meets the guidelines as given by MPR 1990:10 (2.01 — 2.04). Note: This display is a Class 1 LED product.
  • Page 43 All manuals and user guides at all-guides.com Filename: fx75UGrw.doc Title: Book Title Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc. Revision #: 30 Page: 39 of 43 Printed: 10/16/00 03:31 PM...
