REMOTE CONTROL PANEL
INTRODUCTION
The NSI 804CP and 808CP represents a key part of a state of the art, total lighting control system. Combined
with NSI dimmers and optionally, an NSI memory control console, a totally integrated system is achieved.
The 804CP and 808CP can automatically take control and preset the lighting level of up to 100 dimmer channels.
Control is automatically passed between control panels and the memory control console as desired. The 804CP
features 4 zone slide controls while the 808CP features 8 zone slide control. Both units are exceptionally easy to
operate. Remote lockout capability is also included. Installation is a snap with the simple 4 wire digital connection
required.
Programming differs from other Luma-net panels, please read instructions.
Programming of dimmer channels beyond factory defaults requires computer and software interface
package
Luma-net control panels with software release 3.00 and higher are not directly compatible and will
not operate with older 400CP panels with software prior to release 3.00. Contact dealer or factory
for modifications if necessary.
NSI dimming systems used with these release 3.00 panels require the following software releases:
LUMA-NET
804CP / 808CP
INSTALLATION AND OPERATION GUIDE
Software Revision 3.00, Version C
2408CD, 2408CR, 2404CD
DDS 8600/8800/9600/9800
DDS 6000
DDS 5300/5500/5600
* Optional interface kit required for these units.
IMPORTANT
release 2.30 and above.
release 1.30 and above. *
release 1.30 and above. *
release 1.30 and above. *
